Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 277000260 | Steering Cover | ||
| 1 | 277000145 | TOP FOAM | 1 |
| 277000146 | Bottom Foam | ||
| 5 | 212000002 | Elastic Stop Nut M8 | 5 |
| 277000142 | STEERING CLAMP | ||
| 4 | 210000018 | Hexagonal Screw M8 x 55 | 4 |
| 277000341 | LH Adapter | ||
| 216561060 | Set Screw M6 x 10 | ||
| 1 | 277000221 | LH HOUSING ASS'Y | 1 |
| 211200001 | Washer | ||
| 277000223 | Steering Stem | ||
| 1 | 293350006 | SHIM | 1 |
| 293900002 | Bushing | ||
| 4 | 210000002 | Hexagonal Screw M8 x 25 | 4 |
| 277000100 | Plastic Washer | ||
| 277000091 | Collar (Black) | ||
| 1 | 212100001 | Hexagonal Nut M8 | 1 |
| 2 | 213000001 | Lock-Washer 8 mm | 2 |
| 277000247 | Steering Stem Arm | ||
| 1 | 215684560 | Hex. Screw M8 x 45 | 1 |
| 277000305 | Handle bar | ||
| 2 | 295500112 | Handle Grip-Kit (Magenta) Includes 60,61,62,69 | 2 |
| 277000097 | Stopper Bushing | ||
| 277000115400 | Steering Support | ||
| 1 | 210000002 | Hexagonal Screw M8 x 25 | 1 |
| 4 | 213200011 | Flat Washer 8 mm | 4 |
| 293720014 | Grommet | ||
| 277000038 | Small Boot | ||
| 1 | 293370002 | Circlip 5 mm | 1 |
| 1 | 277000039 | LARGE BOOT | 1 |
| 277000168 | Half-Ring | ||
| 277000381 | PIN | ||
| 277000472 | Throttle Handle | ||
| 277000222 | THROTTLE HANDLE HOUSING | ||
| 277000084 | Throttle Adapter | ||
| 277000096 | Retaining Washer | ||
| 2 | 277000153 | BALL JOINT | 2 |
| 2 | 212100005 | Hex. Nut | 2 |
| 211100009 | RUBBER WASHER | ||
| 211100010 | Retaining Ring | ||
| 277000283 | Steering Cable Ass'y | ||
| 1 | 211200006 | FLAT WASHER, STAINLESS | 1 |
| 277000436 | Spacer | ||
| 2 | 212000001 | Elastic Stop Nut M6 | 2 |
| 2 | 212100003 | Lock Nut M6 | 2 |
| 3 | 213200002 | Flat Washer 8 mm | 3 |
| 2 | 210000006 | Hex. Screw M6 x 30 | 2 |
| 293750003 | TIE RAP MOUNT | ||
| 210000019 | Snap Cap | ||
| 277000248 | Cable Support | ||
| 215681660 | Hex. Screw M8 x 16 | ||
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 211100011 | Hex. Jam Nut 1/2-20 | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 2 | 211000021 | PHILLIPS SCREW #10 X 7/8 | 2 |
| XXXX | Not Available As Spare Part - Insert Grip | ||
| 2 | 211000031 | Hex. Screw M6 x 45 | 2 |
| 2 | 277000205 | Grip Cap (Magenta) | 2 |
| 277000201 | Lock Plate | ||
| 1 | 277000167 | KNOB ADJUSTER | 1 |
| 2 | 277000162 | Support Thrust | 2 |
| 215266060 | Bolt-Carriage M6 x 60 | ||
| 2 | 213200001 | Flat Washer 6 mm | 2 |
| 2 | 213200007 | Washer 6 mm | 2 |
| 4 | 213200004 | Flat Washer 5 mm | 4 |
| 2 | 211000032 | Tapping Screw | 2 |
| 211200008 | Spring Washer | ||
| 211000037 | Phillips Screw 10-14 X 7/8” |
