Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 293720030 | Grommet, 1 Circuit, Blue | ||
| 215461350 | Hex. Screw M6.3 x 13 | ||
| 278000401 | Support Bracket | ||
| 278000586 | IGNITION COIL | ||
| 278000235 | SPACER | ||
| 1 | 278000712 | Battery Includes 6 to 9 | 1 |
| 2 | 211200018 | FLAT WASHER 6 MM | 2 |
| 2 | 211000045 | Battery Screw | 2 |
| 2 | 211100022 | Battery Nut M6 | 2 |
| 2 | 293850021 | Rubber Strap | 2 |
| 1 | 293750009 | Tie-Rap 173 mm | 1 |
| 278000492 | Battery Lower Pad | ||
| 278000476 | Battery Support | ||
| 278000236 | 4 Wire Support | ||
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 278000391 | Fuse Block | ||
| 2 | 217361500 | Washer Lock 6 | 2 |
| 293830012 | Rubber Strip | ||
| 2 | 278000704 | FUSE, 7.5 AMPERES | 2 |
| 278000514 | Battery Cable (Red) Includes 52, 53 | ||
| 278000229 | Open Barrel | ||
| 278000515 | Battery Ground Cable | ||
| 2 | 278000609 | Spark Plug, NGK BR8-ES | 2 |
| 1 | 212000001 | Elastic Stop Nut M6 | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 278000379 | Fuse Holder | ||
| 215462550 | Self Tapping Screw M6.3 x 25 | ||
| 1 | 213200001 | Flat Washer 6 mm | 1 |
| 1 | 293150037 | Avdel Rivet 3/16" | 1 |
| 278000098 | GROMMET | ||
| 278000181 | Gasket | ||
| 278000615 | Mounting Plate | ||
| 278000786 | Electric Box Cover | ||
| 278000780 | Box Support | ||
| 278000194 | Temperature Sensor | ||
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 1 | 278002198 | SPARK PLUG WIRE | 1 |
| 278000322 | Spark Plug Wire 530 (MAG) | ||
| 4 | 278000020 | PROTECTION CAP | 4 |
| 278000781 | Electric Box Base | ||
| 278000682 | Grommet | ||
| 1 | 278000123 | RECTIFIER ASS'Y | 1 |
| 1 | 278000513 | Starter Relay | 1 |
| 3 | 212000001 | Elastic Stop Nut M6 | 3 |
| 293720025 | GROMMET, 2 CIRCUIT, GRAY | ||
| 2 | 278000344 | Fuse, 5 Amperes | 2 |
| 3 | 212100004 | Elastic Stop Nut M6 | 3 |
| 2 | 211000035 | Self Tapping Screw M6 x 10 | 2 |
| 278000472 | Engine Harness Includes 52, 54, 64, 66, 67, 68 | ||
| 278000192 | Starter Cable (Red) Includes 51 to 53 | ||
| 278000100 | Electric Wire Cap | ||
| 570026800 | Grommet, 4 Circuit, Red | ||
| 278000193 | GROMMET, 3 CIRCUIT, BLACK | ||
| 278000489 | Temperature Harness Ass'y Includes 52,64,65 | ||
| 1 | 278000378 | FUSE CAP | 1 |
| 278000237 | Spark Plug Cap | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 2 | 278000343 | Fuse, 15 Amperes | 2 |
| 278000423 | Electronic Module Ass'y Includes 26,47,57,60,62,64,65 | ||
| 1 | 278000345 | Fuse Cap | 1 |
| 278000607 | 3 Ways Harness Fuel / Oil Gauge | ||
| 3 | 278000230 | Male Terminal | 3 |
| 3 | 278000231 | Insulation Sheath | 3 |
| 1 | 278000738 | Male Lock, 4 Circuits | 1 |
| 1 | 278000739 | Male Connector, 4 Circuits | 1 |
| 4 | 278000632 | Female Terminal | 4 |
