Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 278000231 | Insulation Sheath | 1 |
| 278000606 | Harness-Accessories (Not Shown) | ||
| 278000588 | <<Y>> Wire (Not Shown) (Incl. It.8, 9) Includes 2, 21c | ||
| 1 | 278000552 | Safety Switch Includes 29, 30 | 1 |
| 278000470 | Buzzer-On/Off Switch Wiring Includes 2, 19b, 21c, 22b, 23a, 29, 32 | ||
| 1 | 278000501 | S top / Start Switch Ass‘y Includes 21b, 23a | 1 |
| 278000881 | BUZZER ASS?Y Includes 21b, 23a | ||
| 278000099 | Safety Switch Nut | ||
| 1 | 295500059 | Safety Landyard (Green) | 1 |
| 278000496 | Oil / Fuel Level Gauge Includes 19e, 22b, 23a | ||
| 278000605 | Light Switch Ass'y (Incl. It. 2 4) | ||
| 278000085 | Gauge Nut | ||
| 278000259 | Gasket | ||
| 278000589 | 6 Ways Harness (Gauge) Includes 19b, 20b, 21b, 22b, 23a | ||
| 278000634 | 2 Ways Harness Front Lamp | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 293720015 | GROMMET | 1 |
| 278000219 | MALE HOUSING, 1 CIRCUIT | ||
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 1 | 278000395 | Male Housing, 4 Circuits | 1 |
| 278000221 | MALE CONNECTOR, 6 CIRCUITS | ||
| 1 | 278000161 | Female Housing, 1 Circuit | 1 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 1 | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| 278000394 | FEMALE HOUSING, 4 CIRCUITS | ||
| 278000156 | FEMALE CONNECTOR, 6 CIRCUITS | ||
| 1 | 409004300 | Male Terminal | 1 |
| 1 | 278000222 | Male Terminal | 1 |
| 1 | 278000230 | Male Terminal | 1 |
| 1 | 409007300 | Female Terminal | 1 |
| 1 | 278000223 | Female Terminal | 1 |
| 1 | 278000218 | Wire Seal | 1 |
| 1 | 278000585 | Wire Seal (20 Gauge) (Purple) (Packard) | 1 |
| 1 | 278000216 | Wire Seal | 1 |
| 1 | 278000739 | Male Connector, 4 Circuits | 1 |
| 1 | 278000738 | Male Lock, 4 Circuits | 1 |
| 1 | 278000632 | Female Terminal | 1 |
| 278000390 | Ventilation Harness Includes 29, 30 | ||
| 278000100 | Electric Wire Cap | ||
| 293720025 | GROMMET, 2 CIRCUIT, GRAY | ||
| 278000564 | Light Harness Includes 19b, 19d, 20b, 21b, 23a, 24, 29, 32 | ||
| 570026800 | Grommet, 4 Circuit, Red | ||
| 2 | 218041600 | Elastic Stop Nut M4 | 2 |
| 278000478 | Oil Level Sensor Includes 20b, 21b, 23a | ||
| 278000581 | Harness (3 Wires) Speed Sensor | ||
| 204000011 | Cap-Fan Switch/Lights | ||
| 278000538 | Terminal 45°, Big Hole Includes 19b, 22b, 23a | ||
| 278000603 | Rear Lamp Ass'y (Incl. It. 2,3) Includes 38 to 40 | ||
| 278000677 | Rear Lamp Base | ||
| 278000678 | Rear Lamp Pole | ||
| 278000691 | 2 Ways Harness (Rear Light) | ||
| 278000652 | Retainer Plate | ||
| 1 | 293710031 | ELECTRIC CONNECTION | 1 |
| 3 | 216141260 | SCREW M4 X 12 | 3 |
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 293750015 | TIE RAP MOUNT | ||
| 2 | 217041600 | Washer 4 mm | 2 |
| 1 | 293150016 | Rivet 1/8" | 1 |
| 1 | 213200018 | Washer 3 mm | 1 |
| 278000604 | Front Lamp Ass'y Includes 50 to 51 and 2, 21c | ||
| 278000765 | Bulb Front Lamp |
