Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 503193274 | Front Arm Ass'y | 1 |
| 1 | 503191391 | Upper Shaft | 1 |
| 4 | 503189324 | Bushing | 4 |
| 4 | 503189564 | Washer | 4 |
| 207005546 | HEX SCREW M10 X 55 | ||
| 1 | 503191390 | Lower Shaft | 1 |
| 2 | 503190113 | Bar Axle (Short) | 2 |
| 1 | 230083044 | Hex. Screw M8 X 130 | 1 |
| 2 | 503191555 | Swivel Bushing | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 503193026 | ROD_LINK | ||
| 2 | 503190114 | Spacer | 2 |
| 1 | 503192211 | Rocker | 1 |
| 1 | 503193037 | Bushing | 1 |
| 1 | 503189282 | Bushing | 1 |
| 1 | 207005044 | Hex. Screw M10 X 1.5 X 50 | 1 |
| 1 | 233601416 | Elastic Locking Nut M10 X 1.5 | 1 |
| 1 | 503193000 | Rear Shock Ass'y | 1 |
| 2 | 414936000 | Bushing | 2 |
| 2 | 207684044 | Hex. Flange Screw M8 X 40 | 2 |
| 1 | 503192266 | Center Shock | 1 |
| 1 | 503183700 | Cam 45° | 1 |
| 1 | 503187500 | Spring Guide | 1 |
| 1 | 503191880 | Black, Spring 242MM SE 600 ETEC | 1 |
| 1 | 503191126 | Protector | 1 |
| 1 | 706200881 | Spring Stopper | 1 |
| 2 | 503189117 | Urethane Bushing | 2 |
| 1 | 503192377 | Black RH Square Spring | 1 |
| 1 | 503192378 | Black LH Square Spring | 1 |
| 1 | 503191398 | Rear Arm | 1 |
| 1 | 503191405 | Upper Shaft | 1 |
| 2 | 503191738 | Black, Wheel Ass'y 155 mm | 2 |
| 2 | 503191099 | Retaining Ring | 2 |
| 2 | 503190619 | CUSHION | 2 |
| 2 | 503190328 | Washer | 2 |
| 2 | 503191183 | Spring Support | 2 |
| 2 | 503190754 | Retainer Cushion | 2 |
| 2 | 205082544 | Socket Head Screw M8 X 25 | 2 |
| 2 | 205523544 | Socket Head Screw M12 X 35, Scotch Grip | 2 |
| 2 | 503189276 | Washer | 2 |
| 1 | 503191565 | LH Cam Adjuster | 1 |
| 1 | 503191566 | RH Cam Adjuster | 1 |
| 2 | 293370013 | E-Circlip | 2 |
| 1 | 503191393 | Welded Arm Pivot | 1 |
| 1 | 408200700 | Grease Fitting | 1 |
| 1 | 503191396 | Axle Pivot | 1 |
| 1 | 503191397 | Bolt 369mm | 1 |
| 4 | 503189157 | Washer | 4 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 503192330 | Lower Shaft | 1 |
| 2 | 503191640 | Cushion | 2 |
| 293550033 | SUSPENSION GREASE, 10 X 400 G | ||
| 1 | 503190643 | Axle Bar (Long) | 1 |
| 1 | 207086044 | HEX. SCREW M8 X 60 | 1 |
| 1 | 503192517 | Compressor | 1 |
| 1 | 219704415 | Hose 4.32Mm 3000Mm Long | 1 |
| 2 | 503193103 | Compressor Bracket | 2 |
| 503193484 | SUPPORT | ||
| 2 | 503193009 | Air manifold Ass'y | 2 |
| 2 | 205562044 | Socket Head Screw M6 X 20, Scotch Grip | 2 |
| 4 | 605636003 | Clinch Nut M6 Hexsert | 4 |
| 4 | 250000128 | Torx Truss Screw M6 X 20 | 4 |
| 1 | 705600459 | Clamp | 1 |
| 1 | 235551494 | Torx Screw M5 X 14 | 1 |
| 1 | 233251414 | Hex. Flange Elastic Nut M5 | 1 |
| 5 | 293150102 | Rivet 3/16" | 5 |
| 503193004 | BRACKET | ||
| 1 | 503193006 | HOSE PROTECTOR | 1 |
| 1 | 503193007 | HOSE PROTECTOR | 1 |
| 503193011 | HOSE PROTECTOR PAINTED | ||
| 1 | 706000869 | Connector | 1 |
| 1 | 706000940 | Check Valve | 1 |
| 1 | 503191933 | PNEUMATIC HOSE ASS'Y | 1 |
| 1 | 706000631 | Compressor Isolator | 1 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 219704455 | Was 293800018 Loctite 592, 50 ml | 1 |
