Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 420912203 | Fan Housing Touring LE. Touring SLE. | 1 |
| 1 | 420945880 | Lock Ring Touring LE. Touring SLE. | 1 |
| 2 | 420244585 | Shim Touring LE. Touring SLE. | 2 |
| 2 | 405406100 | Ball Bearing 6203 Touring LE. Touring SLE. | 2 |
| 1 | 420937940 | Fan Axle Touring LE. Touring SLE. | 1 |
| 1 | 420246015 | Woodruff Key Touring LE. Touring SLE. | 1 |
| 1 | 420827650 | Spacer Bushing Touring LE. Touring SLE. | 1 |
| 1 | 420980496 | Flange Touring LE. Touring SLE. | 1 |
| 1 | 420827080 | Shim 0.5 mm Touring LE. Touring SLE. | 1 |
| 1 | 420827082 | Shim 0.2 mm Touring LE. Touring SLE. | 1 |
| 1 | 420980523 | Protection Washer Touring LE. Touring SLE. | 1 |
| 420866292 | FAN Touring LE. Touring SLE. | ||
| 1 | 420945756 | Lock Washer Touring LE. Touring SLE. | 1 |
| 1 | 420942285 | Hex. Nut M16 X 1.5 Touring LE. Touring SLE. | 1 |
| 1 | 414630800 | V-Belt Touring LE. Touring SLE. | 1 |
| 420945751 | WASHER-LOCK DIN.128 Touring LE. Touring SLE. | ||
| 4 | 205063044 | Socket Head Screw M6 X 30 Touring LE. Touring SLE. | 4 |
| 1 | 420975695 | FAN COVER Touring LE. Touring SLE. | 1 |
| 570068200 | Rubber Adaptor Touring LE. | ||
| 408803700 | Tridon Gear Clamp Touring LE. | ||
| 1 | 420810764 | CYLINDER COWL Touring LE. | 1 |
| 1 | 420811390 | Cylinder Cowl, Exhaust Side Touring SLE. | 1 |
| 1 | 420810792 | CYLINDER COWL Touring LE. | 1 |
| 420811395 | Cylinder Cowl (Intake Side) Touring SLE. | ||
| 5 | 420240580 | TAPTITE SCREW M6 X 16 Touring LE. | 5 |
| 8 | 420240385 | TAPTITE SCREW M6 X 12 Touring SLE. | 8 |
| 8 | 417300005 | SPRING NUT U #10-24 Touring LE. Touring SLE. | 8 |
| 1 | 420810776 | CYLINDER COWL Touring LE. | 1 |
| 420810603 | Cylinder Cowl Touring SLE. | ||
| 4 | 420827817 | Cup Washer Touring LE. Touring SLE. | 4 |
| 4 | 420960865 | Rubber Washer Touring LE. Touring SLE. | 4 |
| 4 | 420227935 | Washer Touring LE. Touring SLE. | 4 |
| 4 | 420945752 | Lock Washer 8 mm Touring LE. Touring SLE. | 4 |
| 4 | 207181644 | Hex. Screw M8 x 16 Touring LE. Touring SLE. | 4 |
| 6 | 420926180 | FLAT WASHER Touring LE. Touring SLE. | 6 |
| 6 | 417300006 | Tapping Screw M4.8 X 16 Touring LE. Touring SLE. | 6 |
| 1 | 420860940 | CLAMP Touring LE. Touring SLE. | 1 |
| 1 | 420941250 | Hex. Tapping Screw M6 X 20 Touring LE. Touring SLE. | 1 |
| 572097800 | Inlet Duct Touring LE. Touring SLE. | ||
| 4 | 517124300 | Washer Touring LE. Touring SLE. | 4 |
| 2 | 232551414 | Elastic Stop Nut M5 Touring LE. Touring SLE. | 2 |
| 2 | 207151644 | Hex. Screw M5 X 16 Touring LE. Touring SLE. | 2 |
| 732601292 | Tapping Screw Touring LE. Touring SLE. | ||
| 415036500 | Seal Touring LE. Touring SLE. | ||
| 4 | 414479100 | Clip Touring LE. Touring SLE. | 4 |
| 509000058 | Air Deflector Touring LE. Touring SLE. | ||
| 1 | 572083700 | OUTLET DUCT Touring LE. | 1 |
| 572083900 | Outlet Duct Touring SLE. | ||
| 4 | 732900047 | SERRATED LOCK WASHER M5 Touring LE. Touring SLE. | 4 |
| 4 | 365901100 | HEX. SCREW 12 X 3/4 Touring LE. Touring SLE. | 4 |
