Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 271000821 | STAINLESS STEEL IMPELLER ASS'Y | ||
| 204120127 | Pump Support | ||
| 2 | 271000516 | Impeller Boot | 2 |
| 271000291 | IMPELLER SHAFT | ||
| 204120078 | Spacer | ||
| 204120094 | RH Shoe | ||
| 204120095 | LH Shoe | ||
| 204120084 | RH MOBIL GRATE | ||
| 204120087 | LH Mobil Grate | ||
| 295500429 | IMPELLER HOUSING ASS'Y Includes 8 - 10. | ||
| 8 | 211100033 | Square Nut M8 | 8 |
| 2 | 271000290 | Wear Ring | 2 |
| 4 | 293350017 | Needle Bearing | 4 |
| 2 | 293200065 | Oil Seal | 2 |
| 2 | 293300011 | O-Ring | 2 |
| 2 | 211500001 | Pipe Plug Socket Head 1/8-27 Npt | 2 |
| 271000670 | IMPELLER COVER | ||
| 6 | 207152060 | Hex. Screw M5 X 20 | 6 |
| 2 | 293250084 | Watertight Seal | 2 |
| 293350020 | THRUST WASHER | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 8 | 250300010 | Square Stud | 8 |
| 8 | 234001600 | Flat Washer 10 mm, Stainless | 8 |
| 16 | 234101601 | Helicoidal Lock Washer M10 | 16 |
| 232001600 | HEX. NUT M10 | ||
| 2 | 271000509 | VENTURI | 2 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 2 | 271000978 | PUSHER | 2 |
| 1 | 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz | 1 |
| 12 | 208564060 | PHILLIPS SCREW M6 X 40 | 12 |
| 204120057 | STEERING NOZZLE (BLACK) Includes 29 - 30. | ||
| 211400014 | Rolled Pin | ||
| 8 | 234081600 | Stainless, Flat Washer 8 mm | 8 |
| 4 | 293900001 | Venturi Bushing | 4 |
| 8 | 234181601 | Lock Washer 8 mm, Stainless | 8 |
| 207087060 | HEX. SCREW M8 X 70 | ||
| 2 | 271000517 | Impeller Ring | 2 |
| 4 | 208563060 | OVAL HEAD PHILLIPS COUNTERSUNK SCREW M6 | 4 |
| 6 | 234051600 | Flat Washer M5, Stainless | 6 |
| 204120075 | BALL JOINT | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 271000704 | SPRING | ||
| 1 | 219704455 | Was 293800018 Loctite 592, 50 ml | 1 |
| 1 | 219704458 | Was 293800041 Loctite Primer 7649 | 1 |
| 1 | 211100034 | HEX. NUT 5/16-24 | 1 |
| 204120083 | Grate Support, Starboard | ||
| 1 | 204120086 | GRATE SUPPORT, PORT SIDE | 1 |
| 4 | 204390001 | PLASTIC BUSHING | 4 |
| 4 | 211000099 | SOCKET SCREW M6 X 8 | 4 |
| 12 | 232561600 | Hex. Elastic Stop Nut M6 | 12 |
| 1 | 204120074 | BALL JOINT | 1 |
| 12 | 234062600 | Flat Washer M6, Stainless | 12 |
| 1 | 277000439 | HEX. NUT 5/16-24 | 1 |
| 8 | 234002600 | Flat Washer 10 mm, Stainless | 8 |
| 1 | 204120067 | Shim 0.9 mm | 1 |
| 4 | 211000047 | SCREW-SPECIAL M8 | 4 |
| 204120076 | Link Rod | ||
| 4 | 211200019 | FLAT WASHER | 4 |
| 2 | 212000005 | NUT-STOP ELASTIC MS-17830 | 2 |
| 1 | 293800088 | Adchem Sealant | 1 |
| 4 | 234180602 | Lock Spring Washer 8 mm, Stainless | 4 |
| 413705200 | Loctite 262, 50 ml | ||
| 272000019 | DRIVE SHAFT PLUG | ||
| 293350019 | BEARING THRUST |
