Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 204470610 | FUSE BLOCK Includes 1 To 11 | 1 |
| 2 | 278001442 | FUSE, 2 AMPERES | 2 |
| 278001196 | FUSE, 3 AMPERES | ||
| XXXX | Not Available As Spare Part - Fuse, 4 Amperes | ||
| 3 | 278000344 | Fuse, 5 Amperes | 3 |
| 4 | 278001197 | Fuse, 10 Amperes | 4 |
| XXXX | Not Available As Spare Part - Female Terminal Housing, 1 Circuit | ||
| 1 | 409012900 | Male Terminal | 1 |
| XXXX | Not Available As Spare Part - Wire Seal | ||
| 278001321 | MALE TERMINAL HOUSING, 8 CIRCUITS | ||
| XXXX | Not Available As Spare Part - Female Terminal | ||
| 4 | 207161260 | Hex. Cap Screw M6 X 12 | 4 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 204470832 | Harness | ||
| 204470715 | Ground Post | ||
| 1 | 204100032 | HEX. ELASTIC NUT 3/8 | 1 |
| 204470800 | Instrument Harness, Mercury | ||
| 204130033 | RUBBER CAP | ||
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 204470631 | LOW SPEED CONTROL SENSOR ASS'Y Includes 21 To 25 | ||
| 204470634 | Female Terminal Housing | ||
| 204470635 | Terminal Support | ||
| 204470641 | Wire Seal | ||
| 2 | 278001481 | Female Terminal | 2 |
| 2 | 204470632 | Low Speed Control Actuator | 2 |
| 204470867 | SAFETY SWITCH ASS'Y Includes 27 To 30 | ||
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 2 | 278000218 | Wire Seal | 2 |
| 2 | 278000222 | Male Terminal | 2 |
| 278000099 | Safety Switch Nut | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 278001431 | Safety Lanyard | 1 |
| 204470793 | Switch Panel | ||
| 1 | 204470544 | BATTERY SWITCH Includes 35 To 36 | 1 |
| 204470132 | Gasket | ||
| 1 | 204470402 | LIGHT SWITCH Includes 37 To 38 | 1 |
| 204470403 | LIGHT SWITCH, BOARDING Includes 39 To 40 | ||
| 204470404 | LIGHT SWITCH, DOCKING Includes 41 To 42 | ||
| 1 | 204470405 | SWITCH, SMALL POOL PUMP Includes 43 To 44 | 1 |
| 204470406 | SWITCH, PASSENGER WATER PUMP Includes 45 To 46 | ||
| 204470011 | VENTILATION SWITCH ASS'Y Includes 47 To 48 | ||
| 204470099 | BILGE PUMP SWITCH ASS'Y Includes 49 To 50 | ||
| 1 | 204470100 | LIGHT SWITCH ASS'Y Includes 51 To 52 | 1 |
| 1 | 204470101 | HORN SWITCH ASS'Y Includes 53 To 54 | 1 |
| 204470102 | COURTESY LIGHT SWITCH ASS'Y Includes 55 To 56 | ||
| 4 | 204470343 | LOCKING PLATE | 4 |
| 1 | 204470907 | Receptacle, 12 Volt | 1 |
| 204470929 | Fuel/oil Gauge | ||
| 204470943 | Speedometer | ||
| 204470944 | Tachometer | ||
| 204470782 | Fascia Ass’y |
