Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204072269 | GLOVE BOX DOOR | ||
| 204071945 | Hinge, Black | ||
| 3 | 293150088 | Pop Rivet 3/16" | 3 |
| 3 | 250000169 | Phillips Pan Head Screw M4 X 40 | 3 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 293200032 | TRAY SEAL, METER | ||
| 1 | 293150008 | Pop Rivet 3/16" | 1 |
| 1 | 234052600 | Flat Washer 5 mm, Stainless | 1 |
| 1 | 204071498 | RETAINER CABLE | 1 |
| 1 | 204070060 | KEEPER | 1 |
| 2 | 232541600 | Elastic Stop Nut M4 | 2 |
| 2 | 208641660 | Phillips Screw M4 X 16 | 2 |
| 2 | 234040600 | Flat Washer 4 mm | 2 |
| 1 | 204050326 | SPLIT LOOM 3/8, METER | 1 |
| 204071838 | LATCH KIT, 3 LATCHES | ||
| 204130080 | RIVET_PLASTIC | ||
| 2 | 204070304 | LATCH PLATE | 2 |
| 219704463 | Était Was 413705800 Loctite 414 , 29.5 c.c | ||
| 204072064 | LATCH GUIDE | ||
| 204071783 | DRAIN FITTING | ||
| 204072186 | Lower Console Ass'y, Port Side Port Side | ||
| 204072188 | Lower Console Ass'y, Starboard Starboard | ||
| 204050138 | SCREW-SELF DRILL(HEX WASHER HEAD) | ||
| 6 | 211200025 | Lock Washer 1/4” | 6 |
| 10 | 207163560 | Hex. Screw M6 X 35 | 10 |
| 20 | 234062600 | Flat Washer M6, Stainless | 20 |
| 10 | 232561600 | Hex. Elastic Stop Nut M6 | 10 |
| 204550045 | Slit Conduit, Meter | ||
| 204072190 | Upper Console Ass'y, Starboard Starboard | ||
| 204072191 | Upper Console Ass'y, Port Side Port Side | ||
| 2 | 212000005 | NUT-STOP ELASTIC MS-17830 965A, 965C | 2 |
| 204100100 | Elastic Stop Nut 5/16-18 965B, 965D | ||
| 2 | 204100139 | WASHER-FENDER/S.S. 965A, 965C | 2 |
| 202000355 | Stainless Steel Washer 5/16" 965B, 965D | ||
| 2 | 207064560 | HEX. SCREW M6 X 45 | 2 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 2 | 232561600 | Hex. Elastic Stop Nut M6 | 2 |
| 2 | 204071928 | ALUMINUM SPACER | 2 |
| 1 | 209943260 | Phillips Tapping Screw M4.2 X 32 | 1 |
| 204070446 | Trim, White, 7/16”, Meter | ||
| XXXX | Not Available As Spare Part - Angled Support | ||
| 2 | 212000005 | NUT-STOP ELASTIC MS-17830 | 2 |
| 1 | 293730018 | Mount Dart 965A, 965C | 1 |
| 1 | 414115200 | Tie-Rap 180 mm 965A, 965C | 1 |
| 2 | 204620079 | Windscreen | 2 |
| 204620281 | HINGE ASS'Y | ||
| 10 | 293150039 | Pop Rivet 3/16" | 10 |
| 204620087 | RETAINING PLATE | ||
| 204620124 | DEFLECTOR | ||
| 2 | 204620106 | REAR STOPPER | 2 |
| 2 | 204620070 | LATCH | 2 |
| 2 | 204620080 | FOAM, WINDSCREEN | 2 |
| 4 | 207151260 | HEX. SCREW M6 X 12 | 4 |
| 2 | 232551600 | Hex. Elastic Nut M5 | 2 |
| 4 | 204620115 | Nut Housing | 4 |
| 4 | 232551600 | Hex. Elastic Nut M5 | 4 |
| 4 | 204620295 | RUBBER STOPPER | 4 |
| 2 | 207151260 | HEX. SCREW M6 X 12 | 2 |
| 4 | 234052600 | Flat Washer 5 mm, Stainless | 4 |
| 2 | 204620194 | RETAINER CABLE | 2 |
| 4 | 204620126 | ROLLED PIN 1.5 X 10 MM | 4 |
| 1 | 413708300 | Glue Tube, Loctite 454, 20 G | 1 |
| 204620127 | CABLE ATTACHEMENT | ||
| 204620018 | HINGE SPRING | ||
| 6 | 207152060 | Hex. Screw M5 X 20 | 6 |
| 6 | 234052600 | Flat Washer 5 mm, Stainless | 6 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 208662560 | PHILLIPS SCREW M6 X 25 | ||
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 2 | 204620280 | WINDSCREEN INSERT | 2 |
| 1 | 269500416 | Storage Tray | 1 |
| 204630008 | ICEBOX FOAM | ||
| 529035731 | Socket Wrench | ||
| XXXX | Not Available As Spare Part - Steel Bar |
