Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204613742 | SLIDE AND SWIVEL SEAT BASE | ||
| 269001903 | SEAT PEDESTAL | ||
| 204100201 | PHILLIPS SCREW 1/4-20 X 1-1/4 | ||
| 211000054 | HEX. SCREW 1/4-20 X 1?, SCOTCH GRIP | ||
| 8 | 211200025 | Lock Washer 1/4” | 8 |
| 8 | 234082600 | Flat Washer 8 mm, Stainless | 8 |
| 269002132 | Bucket Seat | ||
| 12 | 269001696 | SEAT SUPPORT | 12 |
| 30 | 269001695 | SEAT SUPPORT | 30 |
| 60 | 293150043 | Pop Rivet 3/16" | 60 |
| 293150029 | RIVET_POP 5/32 | ||
| 204100030 | Phillips Screw #8 X 1/2” | ||
| 4 | 204130219 | SPACER MAGNET 1/8'' | 4 |
| 204614513 | MAGNETIC CATCH ASS'Y | ||
| 14 | 204100054 | SCREW 8 X 3/4? | 14 |
| 208442060 | PHILLIPS SCREW M4 X 20 | ||
| XXX | Not Available As Spare Parts | ||
| 269002142 | REAR CUSHION ASS'Y, PORT SIDE | ||
| 269002143 | REAR CUSHION ASS'Y, CENTER | ||
| 269002144 | Rear Cushion Ass'y, Starboard | ||
| 211100026 | HEX. NUT 1/4 | ||
| 8 | 234180602 | Lock Spring Washer 8 mm, Stainless | 8 |
| 204130008 | Plastic Cap, White | ||
| 1 | 269002145 | WRAP AROUND CUSHION ASS'Y, PORT SIDE | 1 |
| 8 | 269001590 | HINGE, 90 | 8 |
| 204100095 | SLOTTED BOLT 1/4?-20 X 1? | ||
| 1 | 269002146 | WRAP AROUND CUSHION ASS'Y, STARBOARD | 1 |
| 269002021 | REAR LATERAL BACKREST ASS'Y, PORT | ||
| 1 | 269002135 | REAR BACKREST ASS'Y, PORT | 1 |
| 1 | 269002253 | Rear Backrest Ass'y, Port | 1 |
| 1 | 269002099 | Rear Backrest Ass'y, Starboard | 1 |
| 269002100 | REAR LATERAL BACKREST ASS'Y, STARBOARD | ||
| 269002147 | FRONT CUSHION ASS'Y, PORT SIDE | ||
| 1 | 269002148 | FRONT CUSHION ASS'Y, CENTER | 1 |
| 269002149 | FRONT CUSHION ASS'Y, STARBOARD | ||
| 269002101 | BACKREST ACCESS DOOR, PORT | ||
| 204613980 | Hinge | ||
| 28 | 293150011 | Pop Rivet 3/16" | 28 |
| 269002102 | BACKREST ACCESS DOOR, STARBOARD | ||
| 2 | 204614762 | HOLDER | 2 |
| 4 | 204100054 | SCREW 8 X 3/4? | 4 |
| 269002153 | HOLDER DOOR ASS'Y | ||
| 2 | 204100220 | Pan Head Screw 10-32 X 1/2" | 2 |
| 2 | 212100005 | Hex. Nut | 2 |
| 2 | 204100236 | SCREW-HEX.HD.MACHINE #10 X 1 | 2 |
| 4 | 211200033 | FLAT WASHER | 4 |
| 1 | 269002103 | FRONT LATERAL CUSHION, PORT SIDE | 1 |
| 1 | 269002104 | FRONT LATERAL BACKREST ASS'Y, STARBOARD | 1 |
| 1 | 269002105 | FRONT CENTER BACKREST | 1 |
| 1 | 269002106 | SUNDECK CUSHION, PORT | 1 |
| 28 | 204100054 | SCREW 8 X 3/4? | 28 |
| 1 | 269002107 | SUNDECK CUSHION, STARBOARD | 1 |
| 269002150 | REAR FILLER BACKREST, CENTER |
