Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204560025 | Fuel Tank (Plastic), Model 5603 | ||
| 204560019 | Fuel Tank (Aluminum) | ||
| 2 | 275500252 | TANK BRACKET | 2 |
| XXXX | Not Available As Spare Part - Tank Bracket | ||
| 293750017 | Tie-Rap | ||
| 2 | 293830044 | PROTECTOR PAD | 2 |
| 275500253 | Baffle Pick-up Ass'y Includes 6 - 8. | ||
| 275500111 | Tube Adapter | ||
| 204560032 | Fuel Filter | ||
| 1 | 293650035 | Tridon Clamp | 1 |
| 275500205 | HOSE 16 MM | ||
| 293830020 | Rubber Pad 330 mm | ||
| 1 | 275500206 | VENT BOAT | 1 |
| 204000068 | Hose 6 mm | ||
| 293650059 | Clic Clamp | ||
| 1 | 275500098 | Fuel Valve | 1 |
| 1 | 293250004 | GASKET | 1 |
| 1 | 293650038 | Oetiker Clamp | 1 |
| 204560038 | T-Fitting | ||
| 212100009 | HEX. PLASTIC NUT | ||
| 1 | 293650023 | Tridon Clamp | 1 |
| 1 | 275500241 | Black, Cap | 1 |
| 2 | 215085560 | Hexagonal Screw M8 x 55 | 2 |
| 2 | 212000002 | Elastic Stop Nut M8 | 2 |
| 4 | 210000002 | Hexagonal Screw M8 x 25 | 4 |
| 4 | 213000001 | Lock-Washer 8 mm | 4 |
| 4 | 213200011 | Flat Washer 8 mm | 4 |
| 1 | 213200010 | Washer 4 mm | 1 |
| 1 | 212200004 | Countersunk Phillips Screw M4 x 8 | 1 |
| 1 | 275500263 | FUEL VALVE KNOB, BLACK | 1 |
| 1 | 414363600 | Fuel Filter | 1 |
| 1 | 212100004 | Elastic Stop Nut M6 | 1 |
| 1 | 210000004 | Hex. Screw M6 x 20 | 1 |
| 2 | 212000001 | Elastic Stop Nut M6 | 2 |
| 291000749 | Fixation Plate | ||
| 4 | 293650023 | Tridon Clamp | 4 |
| 1 | 293710059 | Y-Fitting | 1 |
| 293650005 | TRIDON GEAR CLAMP | ||
| 293850018 | Clip | ||
| 293650060 | Caillau Clic Clamp | ||
| 275500067 | INTERNAL FILLER NECK HOSE | ||
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 2 | 294000606 | Tie Rap 180 mm | 2 |
| 204000172 | Filler Neck Hose | ||
| 8 | 293730006 | Black, Dart | 8 |
| 1 | 275500153 | Fuel Cap Ass'y Includes 46 - 47. | 1 |
| 1 | 293000034 | Black, Snap Cap | 1 |
| 293250017 | Gasket | ||
| 275500247 | Filler Neck | ||
| 1 | 293250029 | Gasket | 1 |
| 275500015 | Oil Cap Chain | ||
| 1 | 211000028 | Screw K40 x 10 | 1 |
| 1 | 293150032 | RIVET_POP 1/8 X ,487 | 1 |
| 1 | 213200018 | Washer 3 mm | 1 |
| 1 | 211100012 | Filler Neck Nut, Fuel | 1 |
| 293650057 | Clic Clamp | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 270000186 | Choke Cable Ass'y Includes 58 - 62. | ||
| 291000457 | Choke Plate | ||
| 2 | 212100003 | Lock Nut M6 | 2 |
| 211100007 | Hex. Nut | ||
| 4 | 213200001 | Flat Washer 6 mm | 4 |
| 275500270 | Formed Hose | ||
| 1 | 293650042 | Oetiker Clamp | 1 |
| 210100014 | Allen Screw M4 x 6 | ||
| 1 | 212000001 | Elastic Stop Nut M6 | 1 |
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 1 | 216362560 | Countersunk Phillips Screw M6 x 25 | 1 |
| 1 | 210000011 | Hex. Screw M6 x 12 | 1 |
