Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 212100007 | NUT-HEXAGONAL DIN.934A2 | ||
| 8 | 213200003 | Washer 10 mm | 8 |
| 274000161 | Head Pipe Ass'y | ||
| 2 | 215684060 | Hexagonal Screw M8 x 40 | 2 |
| 274000254 | BUSHING | ||
| 293830036 | RUBBER BUSHING | ||
| 4 | 293150011 | Pop Rivet 3/16" | 4 |
| 270000378 | Rotax Engine 787 (Silver) | ||
| 270000359 | Engine Support | ||
| 293830055 | Rubber Pad | ||
| 18 | 213000001 | Lock-Washer 8 mm | 18 |
| 12 | 213200002 | Flat Washer 8 mm | 12 |
| 204340089 | RH Exhaust Hose | ||
| 270000122 | Shim 0.3 mm | ||
| 270000123 | SHIM 1.3 MM | ||
| 6 | 293730006 | Black, Dart | 6 |
| 270000352 | Rubber Mount | ||
| 8 | 213200011 | Flat Washer 8 mm | 8 |
| 215681660 | Hex. Screw M8 x 16 | ||
| 8 | 215084060 | Hex. Screw M8 x 40 | 8 |
| 274000234 | Muffler Support | ||
| 10 | 211000174 | Hex. Screw M8 x 25 | 10 |
| 204340090 | EXHAUST HOSE L.H | ||
| 4 | 293650077 | Norma Clamp | 4 |
| 293650076 | NORMA CLAMP | ||
| 6 | 293850021 | Rubber Strap | 6 |
| 204340071 | Resonator # 2 | ||
| 1 | 219704368 | Seal Tray 1000Mm Long | 1 |
| 204340072 | Exhaust Hose | ||
| 274000170 | Exhaust Hose | ||
| 204340070 | Resonator # 1 | ||
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 215903560 | Socket Head Screw M10 x 35 | ||
| 4 | 215984060 | Allen Screw M8 x 40 | 4 |
| 204340107 | LH Exhaust Hose (Port Side) | ||
| 274000210 | Cone Pipe ass'y | ||
| 274000357 | Clamp-Exhaust | ||
| 274000169 | Brass Washer | ||
| 1 | 413710300 | Loctite 17914, Sealant, 80 ml | 1 |
| 204340073 | Exhaust Hose | ||
| 2 | 293750002 | Tie Wrap 142 mm | 2 |
| 2 | 293730018 | Mount Dart | 2 |
| 211300017 | Stud M10 | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 274000598 | Pipe Support | ||
| 215982060 | Allen Screw M8 x 20 | ||
| 4 | 215084060 | Hex. Screw M8 x 40 | 4 |
| 290931500 | Gasket | ||
| 2 | 293850024 | STRAP CLIP | 2 |
| 1 | 204250048 | Shim 0.3 mm | 1 |
| 1 | 204250049 | SHIM 1.3 MM | 1 |
| 270000353 | Rubber Mount | ||
| 216663260 | Screw 6.3 x 32 | ||
| 204340091 | Resonator # 3 | ||
| 2 | 215081860 | Hex. Screw M8 x 18 | 2 |
| 6 | 213200011 | Flat Washer 8 mm | 6 |
| 274000276 | Gasket | ||
| 204340069 | Expension Chamber R.H | ||
| 204340080 | Expension Chamber L.H | ||
| 274000277 | Ring | ||
| 16 | 210000005 | Hex. Screw M6 x 25 | 16 |
| 293850018 | Clip | ||
| 32 | 213200001 | Flat Washer 6 mm | 32 |
| 16 | 212000001 | Elastic Stop Nut M6 | 16 |
| 204060017 | Strap Clip 90° | ||
| 4 | 293150037 | Avdel Rivet 3/16" | 4 |
| 204060192 | Resonator Support | ||
| 204060193 | Protector Pad | ||
| 293350016 | CUSHION | ||
| 4 | 213200015 | Washer 5 mm | 4 |
| 204060190 | Support Foam Lower | ||
| 204060191 | Foam Support, Exterior | ||
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
