Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 1 | 278000646 | Emergency Switch Includes 3 - 6. | 1 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 3 | 278000223 | Female Terminal | 3 |
| 3 | 278000218 | Wire Seal | 3 |
| 204470025 | Safety Strap | ||
| 1 | 295500444 | Safety Landyard Ass'y | 1 |
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 204470108 | Fan Ass'y Includes 10 - 13. | 1 |
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 2 | 278000223 | Female Terminal | 2 |
| 2 | 278000218 | Wire Seal | 2 |
| 204470249 | Fan Support | ||
| 278000887 | BUZZER ASSEMBY Includes 15 - 17. | ||
| 2 | 278000222 | Male Terminal | 2 |
| 2 | 278000217 | Female Housing, 2 Circuits | 2 |
| 278000707 | Buzzer Nut | ||
| 204470071 | Front Lamp | ||
| 1 | 204470072 | FRONT LAMP SUPPORT | 1 |
| 3 | 211000011 | Screw M4 x 16 | 3 |
| 278000674 | Rear Light Base Ass'y Includes 23 - 27. | ||
| 204471177 | Rear Lamp Base Ass'y | ||
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 211000136 | Screw M4 x 30 | ||
| 204470206 | Rear Lamp Pole Includes 29 - 30. | ||
| 204470053 | Bulb | ||
| 219704457 | Loctite Adhesive 425 20ML | ||
| 278000970 | SPEED SENSOR ASSY Includes 32 - 34. | ||
| 1 | 293710031 | ELECTRIC CONNECTION | 1 |
| 295500108 | Paddle Wheel Kit | ||
| 1 | 278000416 | SEAL WASHER | 1 |
| 216351060 | SCREW-CTSK.OV.HD.PH.DIN.966A-A2 | ||
| 2 | 293750001 | Tie Wrap 94 mm | 2 |
| 2 | 210000004 | Hex. Screw M6 x 20 | 2 |
| 204070305 | Shouldered Screw M8 x 35 | ||
| 8 | 213200007 | Washer 6 mm | 8 |
| 1 | 215665060 | Hex. Screw M6 x 50 | 1 |
| XXXX | Not Available As Spare Part - Pop Rivet 5/32 | ||
| 204470106 | OIL LEVEL SENSOR ASS'Y Includes 43 - 46. | ||
| 204470104 | Grommet | ||
| 278000565 | IGNITION SWITCH CAP, RED | ||
| 278000622 | RH IGNITION SWITCH Includes 49 - 52. | ||
| 278000621 | IGNITION SWITCH | ||
| 204470256 | Nylon Spacer | ||
| 1 | 204470038 | WATER SENSOR Includes 54 - 57. | 1 |
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 204470058 | Sensor Support | ||
| 204470156 | Harness Ass'y | ||
| 204470155 | Electronic Module Ass'y Includes 61 - 68. | ||
| 278000379 | Fuse Holder | ||
| 4 | 278000704 | FUSE, 7.5 AMPERES | 4 |
| 278001069 | FUSE HOLDER COVER | ||
| 278001070 | Cover Seal | ||
| 3 | 278001197 | Fuse, 10 Amperes | 3 |
| 278001196 | FUSE, 3 AMPERES | ||
| 4 | 278000344 | Fuse, 5 Amperes | 4 |
| 204470255 | Electronic Module Support | ||
| 204470258 | Spacer (Nylon) | ||
| 1 | 204470220 | Bilge Pump | 1 |
| 4 | 212000001 | Elastic Stop Nut M6 | 4 |
| 2 | 293150043 | Pop Rivet 3/16" | 2 |
| 2 | 213200004 | Flat Washer 5 mm | 2 |
| 1 | 213200003 | Washer 10 mm | 1 |
| 1 | 218300600 | Hex. Jam Nut M10 | 1 |
| 1 | 210000015 | Hexagonal Screw M6 x 30 | 1 |
| 1 | 293150008 | Pop Rivet 3/16" | 1 |
| 1 | 294000606 | Tie Rap 180 mm | 1 |
| 293750015 | TIE RAP MOUNT | ||
| 2 | 219704353 | Was 271000110 Protection Trim | 2 |
| 1 | 215061660 | Hex. Screw M6 x 16 | 1 |
