Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 10a1 | 417224332 | Fixed Flange Ass'y | 1 |
| 10a2 | 417224767 | Sheave Drive Pulley Sliding Ass'y Includes 10a2 to 10a2h | 1 |
| 10a2b | 293250389 | Bushing | 2 |
| 10a2c | 293370137 | Circlip | 2 |
| 10a2d | 417224153 | Back Torque Roller | 3 |
| 10a2f | 417224458 | Roller Pulley Ext | 3 |
| 10a2g | 417224510 | Pin | 3 |
| 10a2h | 250400101 | Spring Pin 2.6MM X 20.5MM | 6 |
| 10a3 | 417224611 | Spider Drive Pulley Ass'y Includes 10a3 to 10a3h | |
| 10a3b | 417224910 | Stopper Spring | 1 |
| 10a3c | 417224614 | Spring Guide | 1 |
| 10a3d | 417224285 | Roller Ass'y | 3 |
| 10a3f | 417224204 | Axle - 10mm | 3 |
| 10a3g | 417224009 | Washer-Thrust | 6 |
| 10a3h | 250000763 | Torx-Truss M/S M5 X 14 S.Grip | 3 |
| 10b | 417224172 | Clutch Spring | 1 |
| 10c | 417224003 | Seat Spring | 1 |
| 10d | 293370116 | Circlip | 1 |
| 10f1 | 417224227 | Ramp 968 | 1 |
| 10f2 | 417224086 | RH Lever | 1 |
| 10f3 | 417224114 | LH Lever | 1 |
| 10f4 | 417224222 | Pivot 38mm | 1 |
| 10f5a | 417224113 | Molded Cam | 1 |
| 10g | 417224694 | Pin Ramp | 3 |
| 10h | 250000763 | Torx-Truss M/S M5 X 14 S.Grip | 3 |
| 10j | 417224682 | VIbration Damper | 1 |
| 10k | 250000757 | Button Head Torx Screw M8 X 25 S.Gr | 6 |
| 20 | 250200144 | Conical Spring Washer M14 | 1 |
| 30 | 417300522 | Pulley Drive Bolt M14 X 144 | 1 |
| 100a | 417127595 | Fixed Flange Ass'y Includes 100a to 100a6 | 1 |
| 100a3 | 417127016 | Pulley Roller | 2 |
| 100a4 | 417127294 | Pivot Stud | 2 |
| 100a5 | 250200009 | Lock Washer 8 mm | 2 |
| 100a6 | 250400070 | Spring Pin | 2 |
| 100b | 417127317 | Sliding Flange Ass'y Includes 100b to 100b3 | 1 |
| 100b2 | 417127318 | Bushing ID 41mm OD 45mm X 19mm L | 1 |
| 100b3 | 293370049 | Circlip | 1 |
| 100c | 417127325 | Cam Ass'y Includes 100c to 100c3 | 1 |
| 100c2 | 417127318 | Bushing ID 41mm OD 45mm X 19mm L | 1 |
| 100c3 | 293370049 | Circlip | 1 |
| 100d | 417127137 | Green, Spring | 1 |
| 100f | 417127116 | Swivel Abutment | 2 |
| 100g | 250000757 | Button Head Torx Screw M8 X 25 S.Gr | 4 |
| 100h | 415129604 | Calibration Ass'y | 1 |
| 100j | 250000981 | Socket Screw M5 X 25 | 1 |
| 100k | 234051410 | Flat Washer M5 | 1 |
| 100m | 232551414 | Elastic Stop Nut M5 | 1 |
| 100n | 417127155 | Washer | 1 |
| 100p | 504152574 | Ball Bearing | 1 |
| 200 | 417300571 | Drive Belt | 1 |
| 300 | 417300479 | Belt Guard | 1 |
| 330 | 417300561 | Front Retaining Hook | 1 |
| 340 | 390909200 | Avex Rivet | 3 |
| 360 | 417300569 | CVT Duct Cooling | 1 |
| 365 | 417300590 | Acoustic Panel | 1 |
| 370 | 293150103 | Pop Rivet 3/16" | 5 |
| 380 | 414644300 | Black, Dart | 3 |
| 500 | 417300592 | Rear Guard Support | 1 |
| 505 | 233261466 | Hex. Flange Elastic Nut M6 | 1 |
| 510 | 250000755 | Torx Screw M6 X 16 | 1 |
| 520 | 114045200 | Hair Pin | 1 |
