Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 515178492 | Braided Sleeve 60MM Long | 1 |
| 1 | 420893738 | Turbocharger Ass'y | 1 |
| 1 | 512061280 | Support | 1 |
| 2 | 207682046 | Hex. Flange Screw M8 X 20 | 2 |
| 1 | 512061333 | Washer | 1 |
| 1 | 512061334 | PTO Limiter | 1 |
| 1 | 250001058 | Hex. Flange Screw M8 X 50 | 1 |
| 1 | 512061328 | Upper Stopper | 1 |
| 1 | 420889432 | Servo Motor Ass'y | 1 |
| 1 | 293370122 | Circlip | 1 |
| 2 | 207551044 | Hex. Flange Screw M5 X 10 | 2 |
| 1 | 512061517 | Rear PTO Support Ass'y | 1 |
| 2 | 250001016 | Hex Flange Screw M8 X 25 S.Grip | 2 |
| 2 | 250200146 | Conical Spring Washer M8 | 2 |
| 1 | 512061025 | Front PTO Support | 1 |
| 1 | 512061515 | MAG Support Ass'y | 1 |
| 3 | 250001016 | Hex Flange Screw M8 X 25 S.Grip | 3 |
| 3 | 250200146 | Conical Spring Washer M8 | 3 |
| 2 | 250001062 | Hex. Flange Screw M6 X 16 | 2 |
| 1 | 207586046 | Hex. Flange Screw Din.6921 S.Grip M8 x 60 | 1 |
| 1 | 250200146 | Conical Spring Washer M8 | 1 |
| 1 | 207585544 | Hex. Flange Screw M8 X 55 | 1 |
| 1 | 506151245 | Washer | 1 |
| 1 | 250200008 | Flat Washer With Teflon 8 mm | 1 |
| 1 | 503183200 | Yellow, Washer | 1 |
| 1 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| 1 | 512061398 | Spacer | 1 |
| 1 | 250000761 | Torx Truss Screw M8 X 50 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 2 | 512061137 | Engine Stopper | 2 |
| 2 | 512061354 | Spacer | 2 |
| 1 | 508001089 | Chamber Ass'y Includes 2000 to 2000q | 1 |
| 1 | 512061083 | Rubber | 1 |
| 2 | 420441840 | Screw | 2 |
| 2 | 293650079 | Norma Clamp | 2 |
| 1 | 207652544 | Hex. Flange Screw M5 X 25 | 1 |
| 1 | 233251434 | Flange Elastic Nut M5 | 1 |
| 6 | 250000760 | Torx Screw Truss Head K50X20 T20 | 6 |
| 1 | 515178563 | Pressure Sensor And Air Temperature | 1 |
| 1 | 250000759 | Torx Truss Pt K40 X 16 | 1 |
| 1 | 293650091 | Norma Clamp | 1 |
| 2 | 420201630 | Rubber Cap | 2 |
| 1 | 512061274 | Airbox Support | 1 |
| 3 | 293150103 | Pop Rivet 3/16" | 3 |
| 1 | 293150104 | Pop Rivet 3/16" | 1 |
| 1 | 512061281 | Inlet Tube | 1 |
| 1 | 293650077 | Norma Clamp | 1 |
| 1 | 512061326 | Throttle Cable | 1 |
| 1 | 414274500 | Circlip | 1 |
| 1 | 512060859 | Upper Housing Includes 3800 to 3800a | 1 |
| 1 | 414440800 | Socket Set Screw M8 X 10 | 1 |
| 1 | 512060860 | Lower Housing | 1 |
| 1 | 512061266 | Throttle Ass'y | 1 |
| 2 | 250000991 | Flange Screw M5x12 | 2 |
| 1 | 512061168 | Ignition Coil | 1 |
| 3 | 250000760 | Torx Screw Truss Head K50X20 T20 | 3 |
| 2 | 512061166 | Ignition Cable | 2 |
| 2 | 512061238 | Spark Plug Wire Holder | 2 |
| 1 | 293300059 | O-Ring | 1 |
| 2 | 512060993 | Clamp | 2 |
| 1 | 512060136 | Starter Grip | 1 |
| 1 | 512061329 | Oil Tank | 1 |
| 1 | 519000332 | Oil Pump | 1 |
| 1 | 512061379 | Hose 7,94 mm ID | 1 |
| 1 | 512061381 | Hose | 1 |
| 2 | 293650140 | Oetiker Clamp | 2 |
| 1 | 503195447 | Protector Tube | 1 |
| 2 | 250000767 | Torx Truss Screw M6 X 12 | 2 |
| 1 | 512061322 | Grommet | 1 |
