Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8KW-21940-00-00 | Front Frame Comp | 1 |
| 1 | 8FN-W2197-02-00 | . .Bulkhead | 1 |
| 2 | 90381-15001-00 | . . ..Bush, Solid | 2 |
| 2 | 90381-16004-00 | . . ..Bush, Solid | 2 |
| 1 | 8FN-Y291E-02-00 | . .Bulkhead 2 | 1 |
| 4 | 90105-08072-00 | . Bolt, Flange | 4 |
| 4 | 95607-08200-00 | . .Nut, Self-Locking | 4 |
| 1 | 8FN-21947-00-00 | . .Bracket, Steering 1 | 1 |
| 4 | 95607-10200-00 | . .Nut, U Flange | 4 |
| 1 | 8GS-2193A-01-00 | . .Protector | 1 |
| 48 | 90267-47195-00 | . Rivet, Blind(4.7X16.4 Yellow) | 48 |
| 21 | 90267-48016-00 | . Rivet, Blind (4.8X16.4 Yellow | 21 |
| 1 | 8FN-2198E-00-00 | . .Reinforcement, Frame 3 | 1 |
| 1 | 8FN-2194F-00-00 | . .Bracket, Engine 2 | 1 |
| 1 | 8FN-2194G-00-00 | . .Bracket, Engine 3 | 1 |
| 3 | 90267-48176-00 | . .Rivet, Blind (4.8X17 Yellow) | 3 |
| 12 | 90267-48177-00 | . .Rivet, Blind (4.8X14 Yellow) | 12 |
| 1 | 8LP-21950-00-00 | Rear Frame Comp | 1 |
| 39 | 90267-48023-00 | . .Rivet, Blind(4.8X12.1 Yellow | 39 |
| 39 | 90267-48177-00 | . .Rivet, Blind (4.8X14 Yellow) | 39 |
| 1 | 8JE-21944-00-00 | . .Bracket,Rr.Track Suspention | 1 |
| 1 | 8JE-21954-00-00 | . .Bracket,Rr.Track Suspention | 1 |
| 6 | 90176-10033-00 | . .Nut, Crown | 6 |
| 1 | 8FN-2194H-00-00 | . .Protector, Muffler | 1 |
| 1 | 8FN-21926-00-00 | . .Reinforcement, Footrest 1 | 1 |
| 1 | 8FN-21936-00-00 | . .Reinforcement, Footrest 2 | 1 |
| 1 | 8JE-21943-00-00 | . .Bracket, Main Track 1 | 1 |
| 1 | 8JE-21953-00-00 | . .Bracket, Main Track 2 | 1 |
| 2 | 8FN-21962-01-00 | . .Patch 2 | 2 |
| 2 | 8FN-21963-01-00 | . .Patch 3 | 2 |
| 7 | 90465-08368-00 | . .Clamp | 7 |
| 2 | 8FN-21953-00-00 | . .Bracket, Main Track 2 | 2 |
| 52 | 90267-48026-00 | . .Rivet, Blind (4.8X12.1 Black | 52 |
| 78 | 90267-48028-00 | . .Rivet, Blind (4.8X14 Black) | 78 |
| 1 | 8KW-W2195-00-00 | Frame Connection Kit | 1 |
| 1 | 8CR-21939-01-00 | . .Bracket, Chain Housing | 1 |
| 1 | 8FN-21939-00-00 | . .Bracket, Chain Housing | 1 |
| 1 | 8KW-2196M-00-00 | . .Bracket, 5 | 1 |
| 1 | 8KW-2197M-00-00 | . .Bracket, 6 | 1 |
| 4 | 90267-48018-00 | . Rivet, Blind (4.8X18.6 Black) | 4 |
| 48 | 90267-47195-00 | . Rivet, Blind(4.7X16.4 Yellow) UN | 48 |
| 6 | 90267-48016-00 | . Rivet, Blind (4.8X16.4 Yellow | 6 |
| 6 | 90267-48023-00 | . .Rivet, Blind(4.8X12.1 Yellow | 6 |
| 22 | 90267-48177-00 | . .Rivet, Blind (4.8X14 Yellow) | 22 |
| 2 | 90267-48176-00 | . .Rivet, Blind (4.8X17 Yellow) | 2 |
| 1 | 8FA-21999-00-00 | . .Clamp, Wire Harness | 1 |
| 1 | 8KW-21960-00-00 | Footrest Comp. 1 | 1 |
| 1 | 8KW-21970-00-00 | Footrest Comp. 2 | 1 |
| 1 | 8FN-2194E-00-00 | Bracket, Engine | 1 |
| 2 | 95602-08200-00 | Nut, U Flange | 2 |
| 1 | 95822-10016-00 | Bolt, Flange | 1 |
| 1 | 8FN-12440-01-00 | Heat Exchanger Assy | 1 |
| 1 | 95812-06016-00 | . Bolt, Flange | 1 |
| 1 | 90210-06006-00 | . Washer, Seal | 1 |
| 8 | 90267-48016-00 | Rivet, Blind (4.8X16.4 Yellow) | 8 |
| 1 | 8EK-21920-01-00 | Housing, Reinf Sub-Assy(L.H) | 1 |
| 1 | 8FU-2198F-01-00 | Cover 1 | 1 |
| 1 | 8FU-2198J-01-00 | Cover 3 | 1 |
| 1 | 8FU-2195E-01-00 | Plate, Strg Bracket 1 | 1 |
| 1 | 8FU-2195F-01-00 | Plate, Strg Bracket 2 | 1 |
| 1 | 8KW-2196A-00-00 | Frame Under 1 | 1 |
| 1 | 8KW-2196E-00-00 | Frame, Under 2 | 1 |
| 1 | 8FA-21972-01-00 | Bracket, Guard Fitting | 1 |
| 6 | 8FA-2196F-00-00 | Bracket 3 | 6 |
| 8 | 90267-48083-00 | Rivet,Blind (4.8X15.2 Silver) | 8 |
| 14 | 90267-48018-00 | Rivet, Blind (4.8X18.6 Black) | 14 |
| 4 | 90267-47187-00 | Rivet, Blind (4.7X16.4 Black) | 4 |
| 1 | 8KW-21949-00-00 | Bracket, Front Bumper 1 | 1 |
| 1 | 8KW-21959-00-00 | Bracket, Front Bumper 2 | 1 |
| 2 | 8FA-77125-00-00 | Stay 1 | 2 |
| 2 | 90267-47195-00 | Rivet, Blind(4.7X16.4 Yellow) | 2 |
| 5 | 95822-08016-00 | Bolt, Flange | 5 |
| 2 | 95822-08020-00 | Bolt, Flange | 2 |
| 4 | 90267-48095-00 | Rivet,Blind (4.8X12.6 Silver) | 4 |
| 1 | 8FR-2197E-00-00 | Protector, Frame Fr | 1 |
| 2 | 92012-06012-00 | Bolt, Button Head | 2 |
| 2 | 8JE-27431-00-00 | Footrest, Rear 1 | 2 |
| 8 | 95807-06012-00 | Bolt, Flange | 8 |
| 8 | 95707-06500-00 | Nut, Flange | 8 |
| 1 | 8LP-21933-00-00 | Reinforcement, Frame Rear 2 | 1 |
| 8 | 90267-47195-00 | Rivet, Blind(4.7X16.4 Yellow) | 8 |
| 1 | 8FN-241A5-00-00 | Seal 5 | 1 |
