Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | F6H-U35A1-00-00 | Cushion, Fore 1 UR FOR SC2 | 1 |
| 1 | F6H-U35A1-10-00 | Cushion, Fore 1 UR FOR WC5 | 1 |
| 5 | F1C-U5192-00-00 | .Snap | 5 |
| 5 | 90202-06SA3-00 | .Washer, Plate | 5 |
| 1 | F6H-U379A-00-00 | Back Rest 6 UR FOR SC2 | 1 |
| 1 | F6H-U379A-10-00 | Back Rest 6 UR FOR WC5 | 1 |
| 4 | F1C-U5195-00-00 | Clip, 1 | 4 |
| 10 | 90167-08SA8-00 | Screw, Tapping | 10 |
| 1 | F6H-U35B1-00-00 | Backrest Front, Port UR FOR SC2 | 1 |
| 1 | F6H-U35B1-10-00 | Backrest Front, Port UR FOR WC5 | 1 |
| 3 | F1C-U5195-00-00 | Clip, 1 | 3 |
| 8 | 90167-08SA8-00 | Screw, Tapping | 8 |
| 6 | 90209-14SA5-00 | Washer | 6 |
| 1 | F6H-U35A2-00-00 | Cushion Seat, Front Right UR FOR SC2 | 1 |
| 1 | F6H-U35A2-10-00 | Cushion Seat, Front Right UR FOR WC5 | 1 |
| 1 | F6H-U379B-00-00 | Back Rest 7 UR FOR SC2 | 1 |
| 1 | F6H-U379B-10-00 | Back Rest 7 UR FOR WC5 | 1 |
| 1 | F6H-U35B2-00-00 | Backrest Front, Stbd UR FOR SC2 | 1 |
| 1 | F6H-U35B2-10-00 | Backrest Front, Stbd UR FOR WC5 | 1 |
| 1 | F6H-U3724-00-00 | Cushion Seat, Rear UR FOR SC2 | 1 |
| 1 | F6H-U3724-10-00 | Cushion Seat, Rear UR FOR WC5 | 1 |
| 5 | 90209-14SA3-00 | Washer | 5 |
| 5 | 90201-14S00-00 | Washer, Plate | 5 |
| 5 | 90170-14S00-00 | Nut | 5 |
| 1 | F6H-U3766-00-00 | Backrest 1 UR FOR SC2 | 1 |
| 1 | F6H-U3766-10-00 | Backrest 1 UR FOR WC5 | 1 |
| 6 | F1C-U5195-00-00 | Clip, 1 | 6 |
| 14 | 90167-08SA8-00 | Screw, Tapping | 14 |
| 14 | F6H-U514F-00-00 | Cap | 14 |
| 1 | F6H-U36A1-00-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F6H-U36A1-10-00 | Pad 1 UR FOR WC5 | 1 |
| 15 | F1C-U5195-00-00 | Clip, 1 | 15 |
| 33 | 90167-08SA8-00 | Screw, Tapping | 33 |
| 1 | F6H-U36A2-00-00 | Pad 2 UR FOR SC2 | 1 |
| 1 | F6H-U36A2-10-00 | Pad 2 UR FOR WC5 | 1 |
| 1 | F6H-U371D-00-00 | Cushion 1 UR FOR SC2 | 1 |
| 1 | F6H-U371D-10-00 | Cushion 1 UR FOR WC5 | 1 |
| 2 | F1C-U5192-00-00 | .Snap | 2 |
| 2 | 90202-06SA3-00 | .Washer, Plate | 2 |
| 1 | F6H-U3791-00-00 | Back Rest 1 UR FOR SC2 | 1 |
| 1 | F6H-U3791-10-00 | Back Rest 1 UR FOR WC5 | 1 |
| 2 | F1C-U5195-00-00 | Clip, 1 | 2 |
| 6 | 90167-08SA8-00 | Screw, Tapping | 6 |
| 1 | F6H-U35C1-00-00 | Cusion, Main 1 UR FOR SC2 | 1 |
| 1 | F6H-U35C1-10-00 | Cusion, Main 1 UR FOR WC5 | 1 |
| 4 | F1C-U5192-00-00 | .Snap | 4 |
| 4 | 90202-06SA3-00 | .Washer, Plate | 4 |
| 1 | F6H-U35L1-00-00 | Backrest Aft 1 UR FOR SC2 | 1 |
| 1 | F6H-U35L1-10-00 | Backrest Aft 1 UR FOR WC5 | 1 |
| 1 | F6H-U35L2-00-00 | Backrest Aft 2 UR FOR SC2 | 1 |
| 1 | F6H-U35L2-10-00 | Backrest Aft 2 UR FOR WC5 | 1 |
| 1 | F6H-U3790-01-00 | Back Rest Assy | 1 |
| 6 | 90151-14S24-00 | Screw, Countersunk | 6 |
| 6 | 90185-14S00-00 | Nut, Self-Locking | 6 |
| 1 | F6H-U1543-00-00 | Eye Strap | 1 |
| 1 | 90149-10SA6-00 | Screw | 1 |
| 2 | 90202-06SA1-00 | Washer, Plate | 2 |
| 2 | F4C-U6319-00-00 | Eye Strap | 2 |
| 4 | 90161-08SA4-00 | Screw, Tapping | 4 |
| 1 | F6H-U3795-00-00 | Back Rest 2 UR FOR SC2 | 1 |
| 1 | F6H-U3795-10-00 | Back Rest 2 UR FOR WC5 | 1 |
| 1 | F6H-U371E-00-00 | Cushion 2 UR FOR SC2 | 1 |
| 1 | F6H-U371E-10-00 | Cushion 2 UR FOR WC5 | 1 |
| 1 | F6H-U3712-10-00 | Base, Driver Seat UR FOR SC2 | 1 |
| 1 | F6J-U3712-00-00 | Base, Driver Seat UR FOR WC5 | 1 |
| 8 | 90152-14S20-00 | Screw, Countersunk | 8 |
| 8 | 90209-14SA6-00 | Washer | 8 |
| 1 | F6H-U142E-00-00 | Cushion, Pad 1 UR FOR SC2 | 1 |
| 1 | F6H-U142E-10-00 | Cushion, Pad 1 UR FOR WC5 | 1 |
| 8 | 90162-12S24-00 | Screw, Tapping | 8 |
| 1 | F6H-U3796-00-00 | Back Rest 3 UR FOR SC2 | 1 |
| 1 | F6H-U3796-10-00 | Back Rest 3 UR FOR WC5 | 1 |
| 1 | F6H-U36A3-00-00 | Pad 3 UR FOR SC2 | 1 |
| 1 | F6H-U36A3-10-00 | Pad 3 UR FOR WC5 | 1 |
| 7 | F1C-U5195-00-00 | Clip, 1 | 7 |
| 16 | 90167-08SA8-00 | Screw, Tapping | 16 |
| 1 | F6H-U36A4-00-00 | Pad 4 UR FOR SC2 | 1 |
| 1 | F6H-U36A4-10-00 | Pad 4 UR FOR WC5 | 1 |
