Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | F6H-U2290-20-00 | Floor Drain Assy | 2 |
| 8 | 90450-27801-00 | Hose Clamp Assy | 8 |
| 2 | 90450-33805-00 | Hose Clamp Assy | 2 |
| 1 | F6H-U8366-40-00 | Hose | 1 |
| 1 | F6H-U7817-00-00 | Holder, Filter | 1 |
| 1 | GP1-U7616-00-00 | Through Hull | 1 |
| 2 | F6H-U2249-11-00 | Hose, Drain | 2 |
| 1 | F3M-U7612-00-00 | Pipe, Bilge | 1 |
| 1 | F5K-U2290-20-00 | Floor Drain Assy | 1 |
| 1 | F4A-U771E-00-00 | Pipe, Joint | 1 |
| 2 | 90450-57802-00 | Hose Clamp Assy | 2 |
| 1 | F6H-U2290-10-00 | Floor Drain Assy | 1 |
| 2 | F6H-U2249-80-00 | Hose, Drain | 2 |
| 1 | F6H-U8366-50-00 | Hose | 1 |
| 1 | F6H-U2280-20-00 | Drain Plug Assy | 1 |
| 1 | F6H-U0121-00-00 | Valve, Check | 1 |
| 1 | F6H-U72M2-00-00 | Hose 1 | 1 |
| 2 | F6H-U8362-00-00 | Motor Assy | 2 |
| 1 | F6H-U1794-00-00 | Bracket | 1 |
| 4 | 90169-10SA1-00 | Screw, Truss Head Tapping | 4 |
| 4 | F6H-U7857-00-00 | Joint,Hose | 4 |
| 4 | 90450-33805-00 | Hose Clamp Assy | 4 |
| 1 | F6H-U8366-20-00 | Hose | 1 |
| 1 | F6H-U777C-10-00 | Lever, Cock | 1 |
| 1 | F6H-U1385-10-00 | Fitting, Hose | 1 |
| 1 | F6H-U777C-00-00 | Lever, Cock | 1 |
| 1 | F5K-U8366-31-00 | Hose | 1 |
| 2 | 90169-10SA1-00 | Screw, Truss Head Tapping | 2 |
| 1 | F6B-U8351-00-00 | Pump, Water | 1 |
| 2 | F6B-U1385-00-00 | . .Fitting, Hose | 2 |
| 4 | 90157-08S16-00 | Screw, Pan Head | 4 |
| 4 | 90201-08S00-00 | Washer, Plate | 4 |
| 1 | F6H-U215E-30-00 | Hose | 1 |
| 1 | 90464-99805-00 | Clamp | 1 |
| 2 | 90450-27801-00 | Hose Clamp Assy | 2 |
| 1 | F6B-U1575-00-00 | Union | 1 |
| 1 | F3M-U7620-10-00 | Hose Joint | 1 |
| 1 | F3M-U1385-00-00 | Fitting, Hose | 1 |
| 90151-08SA2-00 | Screw, Countersunk | ||
| 1 | F4A-U4208-00-00 | Hose Assy | 1 |
| 1 | F4A-U4209-00-00 | Sprayer Assy | 1 |
| 1 | F6H-U4261-00-00 | Tank, Water | 1 |
| 1 | F4X-U2242-00-00 | Drain 2 | 1 |
| 2 | F2A-U224C-00-00 | Body, Drain 1 | 2 |
| 1 | 90601-118UF-00 | Band, Hose 18 | 1 |
| 1 | F4X-U215E-40-00 | Hose | 1 |
| 1 | F0R-U7698-00-00 | Bracket | 1 |
| 4 | 90149-10SA6-00 | Screw | 4 |
| 4 | 90167-08S12-00 | Screw, Tapping | 4 |
| 2 | 90201-08S00-00 | Washer, Plate | 2 |
| 2 | 90149-06S16-00 | Screw | 2 |
| 1 | F6H-U215E-00-00 | Hose | 1 |
| 1 | F2A-U224D-00-00 | Body, Drain 2 | 1 |
| 1 | F6H-U215E-50-00 | Hose | 1 |
| 1 | 90167-08S12-00 | Screw, Tapping | 1 |
| 1 | F5K-U7698-00-00 | Bracket | 1 |
| 2 | 90149-10SA6-00 | Screw | 2 |
| 1 | F2A-U215E-30-00 | Hose | 1 |
| 1 | F2A-U224C-00-00 | Body, Drain 1 | 1 |
| 1 | F6H-U224C-00-00 | Body, Drain 1 | 1 |
| 1 | F2A-U7716-00-00 | Pipe, Filler | 1 |
| 3 | 90152-08S16-00 | Screw, Countersunk | 3 |
| 3 | 90201-08S00-00 | Washer, Plate | 3 |
| 3 | 90185-08S00-00 | Nut, Self-Locking | 3 |
| 1 | F1C-U7617-00-00 | Joint, Drain | 1 |
