Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 17204-148-000 | HOUSING, AIR CLEANER ELEMENT | ||
| 17205-148-000 | ELEMENT, AIR CLEANER | ||
| 17205-148-610 | ELEMENT, AIR CLEANER | ||
| 17211-148-680 | TUBE, AIR CLEANER IN. | ||
| 17212-148-000 | GASKET, ELEMENT CASE | ||
| 17213-148-000 | SPRING, AIR CLEANER SET | ||
| 17222-148-000 | TUBE, AIR CLEANER CONNECTING | ||
| 17222-148-010 | TUBE, AIR CLEANER CONNECTING | ||
| 1 | 17231-051-000 | BAND A, AIR CLEANER IN. PIPE | 1 |
| 1 | 17258-122-000 | BAND, AIR CLEANER | 1 |
| 17656-579-010 | GROMMET, FUEL PUMP CHAMBER | ||
| 18291-GT8-770 | GASKET, EX. PIPE | ||
| 18291-GT8-771 | GASKET, EX. PIPE | ||
| 18291-157-650 | GASKET, EX. PIPE | ||
| 1 | 18292-GY1-860 | GASKET, MUFFLER PROTECTOR | 1 |
| 1 | 18292-KS3-920 | GASKET, MUFFLER PROTECTOR | 1 |
| 1 | 18292-147-000 | GASKET, MUFFLER PROTECTOR | 1 |
| 18300-148-771 | MUFFLER ASSY. | ||
| 18315-148-670 | PROTECTOR, MUFFLER | ||
| 18316-148-670 | PROTECTOR, EX. PIPE | ||
| 18318-148-670 | STAY, EX. PIPE A PROTECTOR | ||
| 30510-148-000 | COVER, IGNITION COIL | ||
| 30530-148-003 | COIL, IGNITION | ||
| 30530-148-013 | COIL, IGNITION | ||
| 30700-155-153 | CAP ASSY., NOISE SUPPRESSOR | ||
| 30700-155-163 | CAP ASSY., NOISE SUPPRESSOR | ||
| 40510-148-010PG | COVER, PEDAL CHAIN | ||
| 40510-148-670 | COVER, PEDAL CHAIN | ||
| 40514-148-000 | PIN, COVER SET | ||
| 40515-148-000 | SPRING, COVER SET | ||
| 40520-148-720 | COVER, BELT | ||
| 40520-148-720PG | COVER, BELT | ||
| 50500-148-670B | STAND, MAIN *NH1* (BLACK) | ||
| 50501-148-000 | SHAFT, MAIN STAND | ||
| 52100-148-020 | SWINGARM | ||
| 52100-148-020PG | SWINGARM | ||
| 52112-148-000 | COLLAR, RR. SWINGARM | ||
| 84704-148-000 | IGNITION COIL, COLLAR | ||
| 1 | 87504-028-670 | LABEL, MUFFLER CAUTION | 1 |
| 1 | 87508-120-000 | LABEL, AIR CLEANER CAUTION | 1 |
| 87516-148-670 | LABEL, COVER BELT | ||
| 90103-148-000 | BOLT, ENGINE HANGER | ||
| 90105-148-000 | NUT, JOINT EX. PIPE | ||
| 90300-099-000 | E-RING (8MM) | ||
| 1 | 90481-705-000 | WASHER (10.5MM) | 1 |
| 1 | 92000-08030-0A | BOLT, HEX. (8X30) | 1 |
| 1 | 92101-08030-0A | BOLT, HEX. (8X30) | 1 |
| 1 | 92000-08040-0A | BOLT, HEX. (8X40) | 1 |
| 1 | 92101-08040-0A | BOLT, HEX. (8X40) | 1 |
| 92000-10012-0A | BOLT, HEX. (10X12) | ||
| 92101-10012-0A | BOLT, HEX. (10X12) | ||
| 1 | 93500-06032-0A | SCREW, PAN (6X32) | 1 |
| 1 | 93891-05010-07 | SCREW-WASHER (5X10) | 1 |
| 1 | 94030-08000 | NUT, HEX. (8MM) | 1 |
| 1 | 94001-10000-0S | NUT, HEX. (10MM) | 1 |
| 1 | 94101-08000 | WASHER, PLAIN (8MM) | 1 |
| 1 | 94101-10000 | WASHER, PLAIN (10MM) | 1 |
| 1 | 94111-06000 | WASHER, SPRING (6MM) | 1 |
| 1 | 94111-08000 | WASHER, SPRING (8MM) | 1 |
| 1 | 94111-10000 | WASHER, SPRING (8MM) | 1 |
| 1 | 95014-71402 | SPRING D, MAIN STAND | 1 |
| 89400-148-000 | PUMP ASSY. | ||
| 89400-148-000B | PUMP ASSY. *NH1* (BLACK) | ||
| 89400-148-000CW | PUMP ASSY. *NH0* (CHAMPIONSHIP WHITE) |
