Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 06910-HR6-B00 | BEARING SET, NEEDLE | 1 |
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 2 | 35600-HN7-003 | SWITCH ASSY., NEUTRAL | 2 |
| 1 | 37700-KZR-601 | SENSOR ASSY., SPEED (TDK-EPC) | 1 |
| 1 | 40415-HL4-A00 | SPRING, FR. PROPELLER SHAFT | 1 |
| 1 | 41200-HL4-A01 | DIFFERENTIAL ASSY., FR. | 1 |
| 1 | 41211-HL4-A01 | CASE, FR. DIFFERENTIAL | 1 |
| 1 | 41212-HL4-A01 | CAP, FR. DIFFERENTIAL CASE | 1 |
| 1 | 41231-HL4-A01 | CAM, FACE (66) (A) | 1 |
| 1 | 41232-HL4-A01 | CAM, FACE (66) (B) | 1 |
| 1 | 41240-HL4-A01 | FOLLOWER SET, CAM | 1 |
| 1 | 41251-HL4-A01 | SHIM A (1.3) | 1 |
| 1 | 41252-HL4-A01 | SHIM B (1.4) | 1 |
| 1 | 41253-HL4-A01 | SHIM C (1.5) | 1 |
| 1 | 41254-HL4-A01 | SHIM D (1.6) | 1 |
| 1 | 41255-HL4-A01 | SHIM E (1.7) | 1 |
| 1 | 41261-HL4-A01 | SPRING, DIFFERENTIAL SIDE CONED | 1 |
| 1 | 41400-HL4-AK1 | GEAR, FR. FINAL | 1 |
| 1 | 41405-HA7-670 | RING, STOPPER | 1 |
| 1 | 41411-HL4-AK1 | CASE SUB-ASSY., FR. | 1 |
| 1 | 41412-HL4-AK0 | COVER SUB-ASSY., FR. | 1 |
| 1 | 41413-HL4-A00 | CASE SUB-ASSY., FR. CLUTCH | 1 |
| 1 | 41447-HM8-000 | SHIM A, PINION GEAR (1.64) | 1 |
| 1 | 41448-HM8-000 | SHIM B, PINION GEAR (1.70) | 1 |
| 1 | 41449-HM8-000 | SHIM C, PINION GEAR (1.76) | 1 |
| 1 | 41451-HM8-000 | SHIM D, PINION GEAR (1.82) | 1 |
| 1 | 41452-HM8-000 | SHIM E, PINION GEAR (1.88) | 1 |
| 1 | 41453-HM8-000 | SHIM F, PINION GEAR (1.94) | 1 |
| 1 | 41454-HM8-000 | SHIM G, PINION GEAR (2.00) | 1 |
| 1 | 41455-HM8-000 | SHIM H, PINION GEAR (2.06) | 1 |
| 1 | 41456-HM8-000 | SHIM I, PINION GEAR (2.12) | 1 |
| 1 | 41457-HM8-000 | SHIM J, PINION GEAR (2.18) | 1 |
| 1 | 41502-HL4-A00 | JOINT, FR. FINAL CLUTCH | 1 |
| 1 | 41503-HP5-600 | SPRING, FR. FINAL CLUTCH | 1 |
| 1 | 41504-HP5-600 | SPRING, FR. FINAL CLUTCH LOCK | 1 |
| 1 | 41505-HP5-600 | STOPPER, FR. FINAL CLUTCH | 1 |
| 1 | 41506-HL1-A00 | COLLAR, FR. FINAL CLUTCH | 1 |
| 1 | 41521-HL4-A00 | GEAR, FR. PINION (13T) | 1 |
| 1 | 41527-HR0-F00 | SLEEVE, FR. FINAL CLUTCH | 1 |
| 1 | 41531-HL4-A00 | GEAR, FR. RING (44T) | 1 |
| 2 | 41540-HA0-000 | SPACER A, RING GEAR (1.82) | 2 |
| 2 | 41541-HA0-000 | SPACER B, RING GEAR (1.88) | 2 |
| 2 | 41542-HA0-000 | SPACER C, RING GEAR (1.94) | 2 |
| 2 | 41543-HA0-000 | SPACER D, RING GEAR (2.00) | 2 |
| 2 | 41544-HA0-000 | SPACER E, RING GEAR (2.06) | 2 |
| 2 | 41545-HA0-000 | SPACER F, RING GEAR (2.12) | 2 |
| 2 | 41546-HA0-000 | SPACER G, RING GEAR (2.18) | 2 |
| 2 | 41547-HA0-000 | SPACER H, RING GEAR (2.24) | 2 |
| 2 | 41548-HA0-000 | SPACER I, RING GEAR (2.30) | 2 |
| 2 | 41561-HL4-A00 | SPACER X, RING GEAR (1.14) | 2 |
| 2 | 41562-HL4-A00 | SPACER Y, RING GEAR (1.20) | 2 |
| 2 | 41563-HL4-A00 | SPACER Z, RING GEAR (1.76) | 2 |
| 2 | 41564-HL4-A00 | SPACER J, RING GEAR (1.80) | 2 |
| 2 | 41565-HL4-A00 | SPACER K, RING GEAR (1.86) | 2 |
| 2 | 41566-HL4-A00 | SPACER L, RING GEAR (1.92) | 2 |
| 2 | 41567-HL4-A00 | SPACER M, RING GEAR (1.98) | 2 |
| 2 | 41568-HL4-A00 | SPACER N, RING GEAR (2.04) | 2 |
| 1 | 41540-HL4-A00 | SHAFT, FR. FINAL CLUTCH | 1 |
| 1 | 41550-HL4-A00 | FORK, FR. FINAL CLUTCH | 1 |
| 1 | 41603-HL4-A00 | SPRING A, DIFFERENTIAL LOCK | 1 |
| 1 | 41604-HL4-A00 | SPRING B, DIFFERENTIAL LOCK | 1 |
| 1 | 41605-HL4-A00 | STOPPER, DIFFERENTIAL LOCK SHAFT | 1 |
| 1 | 41606-HL4-A00 | COLLAR, FR. DIFFERENTIAL LOCK | 1 |
| 1 | 41627-HL4-A00 | SLEEVE, DIFFERENTIAL LOCK | 1 |
| 1 | 41640-HL4-A00 | SHAFT, FR. DIFFERENTIAL LOCK | 1 |
| 1 | 41650-HL4-A00 | FORK, DIFFERENTIAL LOCK | 1 |
| 1 | 41712-HL4-F40 | STAY, CLUTCH CABLE | 1 |
| 1 | 41719-HL4-A00 | COVER, FR. DIFFERENTIAL LOCK | 1 |
| 1 | 41728-HL4-A00 | COVER, FR. CLUTCH | 1 |
| 2 | 90102-HL4-A00 | BOLT, SPECIAL (6MM) | 2 |
| 10 | 90104-HL4-A00 | BOLT, FLANGE (10X23) | 10 |
| 4 | 90106-MM9-000 | BOLT, FR. FENDER FIXING | 4 |
| 1 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 1 | 90121-HL4-A00 | BOLT, FLANGE (10X192) | 1 |
| 6 | 90133-HP5-600 | BOLT, FLANGE (8X27) | 6 |
| 2 | 90134-HP5-600 | BOLT, FLANGE (10X35) | 2 |
| 1 | 90242-MB0-000 | NUT, LOCK (64MM) | 1 |
| 3 | 90305-HC0-770 | NUT, SELF-LOCK (10MM) | 3 |
| 2 | 90443-KR0-000 | WASHER, NEUTRAL SWITCH | 2 |
| 1 | 90471-580-000 | WASHER (8MM) | 1 |
| 1 | 90652-HC4-003 | CLAMP, HARNESS | 1 |
| 1 | 90652-HF7-003 | JOINT, BREATHER TUBE | 1 |
| 1 | 91051-HL4-A01 | BEARING, RADIAL BALL (6206) | 1 |
| 1 | 91052-HL6-AF1 | BEARING (35X68X16) | 1 |
| 1 | 91055-HL4-A01 | BEARING, RADIAL BALL (6907) | 1 |
| 1 | 91055-HP5-601 | BEARING, RADIAL BALL (32X58X13) | 1 |
| 1 | 91056-HP5-601 | BEARING, NEEDLE (12X18X12) | 1 |
| 2 | 91251-HL4-A01 | OIL SEAL (27X53X7) | 2 |
| 1 | 91252-HL4-A01 | OIL SEAL (24X32X5) | 1 |
| 1 | 91254-HR3-A21 | OIL SEAL (42X58X12) | 1 |
| 1 | 91254-KS7-831 | DUST SEAL (22X28X5) | 1 |
| 1 | 91302-001-020 | O-RING (30.8MM) (Honda Code 0001065) | 1 |
| 1 | 91303-KF0-003 | O-RING (14.8X2.4) (ARAI) | 1 |
| 1 | 91351-HL4-A00 | GASKET, FR. FINAL CLUTCH COVER | 1 |
| 2 | 91352-GAZ-930 | O-RING (8.5X1.5) (L. SIDE ONLY) | 2 |
| 1 | 91362-HL4-A01 | O-RING, SPECIAL | 1 |
| 2 | 94301-06100 | PIN A, DOWEL (6X10) (YAMADA) | 2 |
| 1 | 94510-32000 | CIRCLIP (OUTER) (32MM) | 1 |
| 1 | 94520-58000 | CIRCLIP (INNER) (58MM) | 1 |
| 1 | 95002-35000 | CLIP, TUBE (C6.5) | 1 |
| 1 | 95005-35001-30M | BULK HOSE, VACUUM (3.5X1000) (3.5X860) (BULK HOSE: 95005-35001-30M) | 1 |
| 1 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 1 |
| 1 | 95701-08020-00 | BOLT, FLANGE (8X20) | 1 |
| 3 | 95701-08025-00 | BOLT, FLANGE (8X25) | 3 |
| 2 | 95801-10150-00 | BOLT, FLANGE (10X150) | 2 |
| 2 | 95801-10150-08 | BOLT, FLANGE (10X150) | 2 |
