Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 708303769 | Luggage Rack | 1 |
| 4 | 250001003 | Torx-Truss M/S M6 X 40 | 4 |
| 2 | 250000954 | Torx Screw M6 X 70 | 2 |
| 6 | 250200162 | Flat Washer M6.6 X 22 | 6 |
| 2 | 250200162 | Flat Washer M6.6 X 22 | 2 |
| 2 | 233261494 | Hex. Flange Elastic Nut M6 | 2 |
| 2 | 250001003 | Torx-Truss M/S M6 X 40 | 2 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 4 | 250200162 | Flat Washer M6.6 X 22 | 4 |
| 4 | 250000760 | Torx Screw Truss Head K50X20 T20 | 4 |
| 4 | 708302992 | Tie-Down Ring Bracket | 4 |
| 4 | 708302990 | D-Ring | 4 |
| 4 | 708302991 | Tie-Down Ring Spring | 4 |
| 8 | 250001107 | Torx Flat Head Screw T-30 S.Grip M6X25 | 8 |
| 4 | 708304337 | Retaining Plate | 4 |
| 4 | 860201806 | Luggage Rack Base With Hardware Includes 185 to 185c | 4 |
| 2 | 860201806 | Luggage Rack Base With Hardware | 2 |
| 4 | 511000822 | Threaded Insert Not Shown | 4 |
| 4 | 250000446 | Torx Screw M6 X 20, Scotch Grip Not Shown | 4 |
| 8 | 250001003 | Torx-Truss M/S M6 X 40 | 8 |
| 8 | 708304332 | Retaining Plate | 8 |
| 1 | 705016220 | LH Box Panel | 1 |
| 6 | 250100208 | Panel Nut M6 X 1.0 | 6 |
| 2 | 207662054 | Hex. Flange Screw M6 X 20 | 2 |
| 4 | 517306478 | Clip | 4 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 6 | 234062670 | Stainless Steel Flat Washer | 6 |
| 2 | 219704386 | Seal 3000MM Long | 2 |
| 1 | 705016221 | RH Box Panel | 1 |
| 1 | 708303774 | Rear Fascia | 1 |
| 2 | 250100208 | Panel Nut M6 X 1.0 | 2 |
| 2 | 520001820 | Red Reflector | 2 |
| 4 | 250000722 | Torx Screw M6 X 20 | 4 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 1 | 708304335 | Camera Support | 1 |
| 1 | 708304271 | Heat Shield | 1 |
| 5 | 250000720 | Torx Screw K50 X 16 | 5 |
| 1 | 708303788 | Deep Black, LH Taillight Trim | 1 |
| 4 | 250100208 | Panel Nut M6 X 1.0 | 4 |
| 1 | 708303789 | Deep Black, RH Taillight Trim | 1 |
| 1 | 708303964 | Intercooler Cover | 1 |
| 1 | 708304244 | Lower Acoustic Insulation Cover | 1 |
| 1 | 708304322 | Upper Acoustic Insulation Cover | 1 |
| 6 | 705003841 | Support Plate | 6 |
| 6 | 517302785 | Edge Clip | 6 |
| 2 | 293150230 | Tuflok Plastic Rivet | 2 |
| 1 | 705017038 | Access Cover | 1 |
| 1 | 708304272 | Rear Scoop Ass'y Includes 8000a to 8000a8 | 1 |
| 2 | 705003841 | Support Plate | 2 |
| 2 | 517302785 | Edge Clip | 2 |
| 4 | 705003841 | Support Plate | 4 |
| 4 | 517302785 | Edge Clip | 4 |
| 1 | 708304061 | Central Air Inlet Grille | 1 |
| 2 | 708304273 | Seperation Panel Includes 8000c to 8000c7 | 2 |
| 6 | 508000853 | Push Nut | 6 |
| 1 | 207662554 | Hex. Flange Screw M6 X 25 | 1 |
| 1 | 233261494 | Hex. Flange Elastic Nut M6 | 1 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 6 | 517306478 | Clip | 6 |
| 4 | 207662054 | Hex. Flange Screw M6 X 20 | 4 |
| 2 | 250000959 | Screw PT Type K-50 X 16 | 2 |
