Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 18150-MAM-A80 | PIPE, R. EX. | ||
| 18250-MAM-A80 | PIPE, L. EX. | ||
| 6 | 18291-MN5-650 | GASKET, EX. PIPE | 6 |
| 12 | 18292-KBR-000 | GASKET, PROTECTOR | 12 |
| 1 | 18310-MAM-A80 | MUFFLER, R. | 1 |
| 18315-MW5-870YC | PROTECTOR, R. CHAMBER *NH1Z* (BLACK-Z) | ||
| 18315-MW5-870YF | PROTECTOR, R. CHAMBER *R176C* (CANDY SPECTRA RED) | ||
| 18315-MW5-870YB | PROTECTOR, R. CHAMBER *G167P* (PEARL MERCED GREEN) | ||
| 18315-MW5-870ZF | PROTECTOR, R. CHAMBER *PB255P* (PEARL CORONADO BLUE) | ||
| 18316-MAM-A80 | TAILPIECE, R. | ||
| 18316-MN5-000 | GROMMET | ||
| 1 | 18321-MN5-000 | RUBBER, R. HEAT PROTECTOR | 1 |
| 1 | 18322-MN5-000 | RUBBER, L. HEAT PROTECTOR | 1 |
| 18323-MN5-000 | RUBBER A, SEAL | ||
| 18324-MN5-000 | RUBBER B, SEAL | ||
| 18325-MW5-770YA | PROTECTOR, R. EX. PIPE *G167P* (PEARL MERCED GREEN) | ||
| 18325-MW5-770YB | PROTECTOR, R. EX. PIPE *NH1Z* (BLACK-Z) | ||
| 18325-MW5-770YE | PROTECTOR, R. EX. PIPE *R176C* (CANDY SPECTRA RED) | ||
| 18325-MW5-770ZE | PROTECTOR, R. EX. PIPE *PB255P* (PEARL CORONADO BLUE) | ||
| 18326-MN5-000YL | PROTECTOR, L. RR. EX. PIPE *NH1Z* (BLACK-Z) | ||
| 18326-MN5-000YP | PROTECTOR, L. RR. EX. PIPE *R176C* (CANDY SPECTRA RED) | ||
| 18326-MN5-000YK | PROTECTOR, L. RR. EX. PIPE *G167P* (PEARL MERCED GREEN) | ||
| 18326-MN5-000ZP | PROTECTOR, L. RR. EX. PIPE *PB255P* (PEARL CORONADO BLUE) | ||
| 18327-MT8-000 | CHAMBER, R. HOT AIR | ||
| 4 | 18334-MT8-770 | NUT, FLANGE (5MM) | 4 |
| 18335-MW5-770YC | LID, R. EX. PIPE PROTECTOR *G167P* (PEARL MERCED GREEN) | ||
| 18335-MW5-770YD | LID, R. EX. PIPE PROTECTOR *NH1Z* (BLACK-Z) | ||
| 18335-MW5-770YE | LID, R. EX. PIPE PROTECTOR *R176C* (CANDY SPECTRA RED) | ||
| 18335-MW5-770ZF | LID, R. EX. PIPE PROTECTOR *PB255P* (PEARL CORONADO BLUE) | ||
| 18336-MAM-A80 | TAILPIECE, L. | ||
| 18338-MT8-770 | RUBBER, CUSHION (5MM) | ||
| 18340-MAM-A80 | CHAMBER | ||
| 18340-MN5-003 | CHAMBER, EX. | ||
| 18373-MB6-003 | BAND, R. EX. PIPE | ||
| 18374-MB6-003 | BAND, L. EX. PIPE | ||
| 1 | 18376-MB4-003 | BAND, R. MUFFLER | 1 |
| 1 | 18377-MB4-003 | BAND, L. MUFFLER | 1 |
| 2 | 18391-MAM-000 | GASKET A, MUFFLER | 2 |
| 2 | 18392-MAM-000 | GASKET B, MUFFLER | 2 |
| 1 | 18410-MAM-A80 | MUFFLER, L. | 1 |
| 18415-MW5-870YC | PROTECTOR, L. CHAMBER *NH1Z* (BLACK-Z) | ||
| 18415-MW5-870YF | PROTECTOR, L. CHAMBER *R176C* (CANDY SPECTRA RED) | ||
| 18415-MW5-870YB | PROTECTOR, L. CHAMBER *G167P* (PEARL MERCED GREEN) | ||
| 18415-MW5-870ZF | PROTECTOR, L. CHAMBER *PB255P* (PEARL CORONADO BLUE) | ||
| 2 | 18421-MN5-000 | RUBBER, MUFFLER MOUNTING | 2 |
| 2 | 18422-MN5-000 | COLLAR, MUFFLER MOUNTING | 2 |
| 18423-MN5-000 | RUBBER, CHAMBER MOUNTING | ||
| 2 | 18424-MN5-000 | COLLAR, CHAMBER MOUNTING | 2 |
| 18425-MW5-770YA | PROTECTOR, L. EX. PIPE *G167P* (PEARL MERCED GREEN) | ||
| 18425-MW5-770YB | PROTECTOR, L. EX. PIPE *NH1Z* (BLACK-Z) | ||
| 18425-MW5-770YE | PROTECTOR, L. EX. PIPE *R176C* (CANDY SPECTRA RED) | ||
| 18425-MW5-770ZE | PROTECTOR, L. EX. PIPE *PB255P* (PEARL CORONADO BLUE) | ||
| 18427-MT8-000 | CHAMBER, L. HOT AIR | ||
| 18435-MW5-770YC | LID, L. EX. PIPE PROTECTOR *G167P* (PEARL MERCED GREEN) | ||
| 18435-MW5-770YD | LID, L. EX. PIPE PROTECTOR *NH1Z* (BLACK-Z) | ||
| 18435-MW5-770YE | LID, L. EX. PIPE PROTECTOR *R176C* (CANDY SPECTRA RED) | ||
| 18435-MW5-770ZF | LID, L. EX. PIPE PROTECTOR *PB255P* (PEARL CORONADO BLUE) | ||
| 1 | 50524-MG9-000 | RUBBER, STAND STOPPER | 1 |
| 61329-MJ6-000 | RUBBER, OIL COOLER MOUNTING | ||
| 10 | 90126-MN5-000 | BOLT, FLANGE (6X8) | 10 |
| 6 | 90129-MN5-000 | BOLT, FLANGE (8X37) | 6 |
| 11 | 90130-MN5-000 | BOLT, FLANGE (6X10) | 11 |
| 11 | 96001-06010-07 | BOLT, FLANGE (6X10) | 11 |
| 12 | 90304-HB3-771 | NUT, SPECIAL (6MM) | 12 |
| 6 | 90308-MT8-000 | NUT, CAP (6MM) | 6 |
| 4 | 90344-692-003 | NUT, CLIP (6MM) | 4 |
| 1 | 90501-MJ6-000 | COLLAR, HEADLIGHT BRACKET | 1 |
| 4 | 94050-08080 | NUT, FLANGE (8MM) | 4 |
| 6 | 94101-06000 | WASHER, PLAIN (6MM) | 6 |
| 6 | 94101-06080 | WASHER, PLAIN (6MM) | 6 |
| 6 | 94101-06800 | WASHER, PLAIN (6MM) | 6 |
| 19 | 94101-06400 | WASHER, PLAIN (6MM) | 19 |
| 2 | 94103-06400 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94103-08200 | WASHER, PLAIN (8MM) | 2 |
| 2 | 94103-08800 | WASHER, PLAIN (8MM) | 2 |
| 6 | 94111-06000 | WASHER, SPRING (6MM) | 6 |
| 1 | 95701-06018-08 | BOLT, FLANGE (6X18) | 1 |
| 2 | 95701-08045-08 | BOLT, FLANGE (8X45) | 2 |
| 2 | 95701-08055-02 | BOLT, FLANGE (8X55) | 2 |
| 6 | 96001-06012-00 | BOLT, FLANGE (6X12) | 6 |
