Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 40543-444-000 | ADJUSTER, CHAIN | ||
| 41201-444-000 | SPROCKET, FINAL DRIVEN (51T) (ALUMINUM) | ||
| 41201-444-810 | SPROCKET, FINAL DRIVEN (51T) (STEEL) (Optional). | ||
| 41202-444-810 | SPROCKET, FINAL DRIVEN (49T) (ALUMINUM) (Optional). | ||
| 41203-444-810 | SPROCKET, FINAL DRIVEN (53T) (ALUMINUM) (Optional). | ||
| 41231-444-000 | RETAINER, RR. WHEEL BEARING | ||
| 42301-466-000 | AXLE, RR. WHEEL | ||
| 42311-466-000 | COLLAR, RR. WHEEL SIDE | ||
| 42312-444-000 | WASHER, PLAIN (17MM) | ||
| 42601-466-000 | HUB, RR. WHEEL | ||
| 42604-430-000 | FLANGE, RR. SPOKE | ||
| 42605-444-305 | SPOKE ASSY. A, RR. | ||
| 42606-444-305 | SPOKE ASSY. B, RR. | ||
| 42607-444-305 | SPOKE ASSY. C, RR. | ||
| 42608-444-305 | SPOKE ASSY. D, RR. | ||
| 42620-444-000 | COLLAR, RR. WHEEL DISTANCE | ||
| 42701-444-003 | RIM, RR. WHEEL | ||
| 42711-KA3-003 | TIRE, RR. (4.00-18) (BS) | ||
| 42711-466-003 | TIRE, RR. (4.00-18) (BS) | ||
| 1 | 08400-34001 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-KT1-671 | TUBE, TIRE (100/100-18) (INOUE) | 1 |
| 1 | 42712-300-000 | TUBE, TIRE (4.00-18) | 1 |
| 42712-300-003 | TUBE, TIRE (4.00-18) (BS) | ||
| 1 | 42712-310-004 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-312-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-340-006 | TUBE, TIRE (4.00-18) (NITTO) | 1 |
| 1 | 42712-374-003 | TUBE, TIRE (3.75-18) (BS) | 1 |
| 1 | 42712-400-003 | TUBE, TIRE (4.10-18) (BS) | 1 |
| 1 | 42712-425-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-435-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 44712-300-004 | TUBE, TIRE (DUNLOP) | 1 |
| 1 | 42713-268-003 | FLAP, TIRE (18) (BS) | 1 |
| 1 | 42715-KA2-680 | STOPPER, BEAD (1.85) | 1 |
| 1 | 42715-444-000 | STOPPER, BEAD (1.85) | 1 |
| 90119-467-000 | BOLT, CHAIN ADJUSTING | ||
| 6 | 90125-KA4-000 | SCREW, FLAT (8X31) | 6 |
| 6 | 90125-430-010 | SCREW, SOCKET (8X32) | 6 |
| 6 | 90135-107-720 | BOLT, STUD (6X28) | 6 |
| 1 | 90307-283-000 | NUT, CHAIN ADJUSTING | 1 |
| 6 | 90309-357-000 | NUT, HEX. (8MM) | 6 |
| 6 | 90352-122-003 | NUT, DRIVEN SPROCKET (TOKAI) | 6 |
| 90912-444-004 | BEARING, RADIAL BALL (6203) (KOYO) | ||
| 90912-444-005 | BEARING, RADIAL BALL (6203) (NIPPON SEIKO) | ||
| 91257-444-003 | DUST SEAL (26X40X7) | ||
| 1 | 94001-08000-0S | NUT, HEX. (8MM) | 1 |
| 1 | 94111-08000 | WASHER, SPRING (8MM) | 1 |
