Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705601887 | LH Front Brake Caliper Includes 10 to 10d | 1 |
| 1 | 715900379 | LH Brake Pads Includes 10a to 10a1 | 1 |
| 1 | 715900384 | Pin Kit | 1 |
| 1 | 705601017 | Bleeding Screw | 1 |
| 1 | 715900385 | Cap Spring Kit | 1 |
| 1 | 705601888 | RH Front Brake Caliper Includes 20 to 20d | 1 |
| 1 | 715900380 | RH Brake Pads Includes 20a to 20a1 | 1 |
| 1 | 705601803 | Master Cylinder Includes 30 to 30b | 1 |
| 1 | 715900373 | Boot Rod Kit | 1 |
| 1 | 715900374 | Fork Kit | 1 |
| 1 | 705601906 | LH Front Caliper Hose Includes 40 to 40a | 1 |
| 3 | 293650256 | Clamp | 3 |
| 1 | 705601907 | RH Front Caliper Hose Includes 41 to 41a | 1 |
| 1 | 293650256 | Clamp | 1 |
| 1 | 705601915 | Front Master Cylinder Hose | 1 |
| 1 | 705601916 | Rear Master Cylinder Hose | 1 |
| 1 | 705601910 | LH Rear Caliper Hose Includes 45 to 45a | 1 |
| 1 | 705601911 | RH Rear Caliper Hose Includes 46 to 46a | 1 |
| 4 | 293650256 | Clamp | 4 |
| 5 | 705600609 | Banjo Bolt (M10 x 1.25 thread) | 5 |
| 12 | 705601628 | Copper Washer | 12 |
| 2 | 207682544 | Hex. Flange Screw M8 X 25 | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 15 | 390402200 | Pop Rivet 3/16" | 15 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 1 | 705601669 | Brake Switch | 1 |
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 1 | 705601889 | LH Rear Brake Caliper Includes 170 to 170d | 1 |
| 1 | 715900386 | LH Brake Pads Includes 170a to 170a1 | 1 |
| 1 | 705601890 | RH Rear Brake Caliper Includes 180 to 180d | 1 |
| 1 | 715900387 | RH Brake Pads Includes 180a to 180a1 | 1 |
| 1 | 705601777 | Brake Pedal Includes 250a to 250g | 1 |
| 1 | 705601725 | Lever | 1 |
| 1 | 705601722 | Bushing | 1 |
| 1 | 705601729 | Spring | 1 |
| 1 | 705601770 | Circlip | 1 |
| 1 | 219704439 | Hose 1/4 1000Mm Long - Call Your Local BRP Dealership | 1 |
| 1 | 708002655 | Adjustment Handle | 1 |
| 1 | 705600792 | Brake Pedal Spring | 1 |
| 2 | 293300144 | O-Ring | 2 |
| 1 | 705601373 | Inside Sleeve | 1 |
| 1 | 230603046 | Hex. Flange Screw, M10 X 130 | 1 |
| 1 | 233201436 | Hex. Flange Elastic Nut M10 | 1 |
| 4 | 705601511 | Brake Disc | 4 |
| 16 | 235381646 | Torx Screw M8 X 16, Scotch Grip | 16 |
| 8 | 207502546 | Hex. Flange Screw M10 X 25 | 8 |
| 1 | 705601567 | Support | 1 |
| 1 | 705601608 | Stopper Bracket | 1 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 1 | 705601526 | Master Cylinder Reservoir Ass'y Includes 525 to 525g | 1 |
| 1 | 219800350 | Diaphragm Cover Ass'y | 1 |
| 2 | 705601073 | Oil Level Sensor | 2 |
| 1 | 705601294 | Spindle Lock | 1 |
| 2 | 211100002 | Push Nut | 2 |
| 2 | 705601603 | Hose | 2 |
| 4 | 293650046 | Oetiker Clamp | 4 |
| 2 | 390402200 | Pop Rivet 3/16" | 2 |
| 1 | 703501118 | Module ESP Wet Prog & Grommet Kit Includes 1000 to 1000b | 1 |
| 1 | 710003279 | Shock Damper | 1 |
| 1 | 207661644 | Hex. Flange Screw M6 X 16 | 1 |
| 2 | 705601818 | Hose Clip | 2 |
