Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 12361-035-000 | CAP, VALVE ADJ. | 1 |
| 12361-300-000 | CAP, VALVE ADJ. | ||
| 12361-371-980 | CAP, VALVE ADJ. | ||
| 41300-MA1-000 | GEAR ASSY., FINAL DRIVEN | ||
| 41301-MA1-000 | CASE, FINAL GEAR | ||
| 41306-415-000 | CAP, BREATHER | ||
| 41321-415-000 | COVER, L. CASE | ||
| 41324-415-000 | PLATE, DUST GUARD | ||
| 41331-415-000 | RETAINER B, BEARING | ||
| 1 | 41332-415-000 | LOCK A, BEARING ADJ. | 1 |
| 1 | 41333-415-000 | LOCK B, BEARING ADJ. | 1 |
| 41351-371-000 | RETAINER A, BEARING | ||
| 414A3-MA1-000 | GEAR SET, FINAL DRIVEN | ||
| 41450-415-000 | SHIM A, PINION GEAR (1.10) | ||
| 41451-415-000 | SHIM B, PINION GEAR (1.14) | ||
| 41452-415-000 | SHIM C, PINION GEAR (1.18) | ||
| 41453-415-000 | SHIM D, PINION GEAR (1.22) | ||
| 41454-415-000 | SHIM E, PINION GEAR (1.26) | ||
| 41455-415-000 | SHIM F, PINION GEAR (1.30) | ||
| 41456-415-000 | SHIM G, PINION GEAR (1.34) | ||
| 41457-415-000 | SHIM H, PINION GEAR (1.38) | ||
| 41458-415-000 | SHIM I, PINION GEAR (1.42) | ||
| 41459-415-000 | SHIM J, PINION GEAR (1.46) | ||
| 41460-415-000 | SHIM K, PINION GEAR (1.50) | ||
| 41461-415-000 | SHIM L, PINION GEAR (1.54) | ||
| 41462-415-000 | SHIM M, PINION GEAR (1.58) | ||
| 41463-415-000 | SHIM N, PINION GEAR (1.62) | ||
| 41464-415-000 | SHIM O, PINION GEAR (1.66) | ||
| 41465-415-000 | SHIM P, PINION GEAR (1.70) | ||
| 41466-415-000 | SHIM Q, PINION GEAR (1.74) | ||
| 41467-415-000 | SHIM R, PINION GEAR (1.78) | ||
| 41468-415-000 | SHIM S, PINION GEAR (1.82) | ||
| 41469-415-000 | SHIM T, PINION GEAR (1.86) | ||
| 41470-415-000 | SHIM U, PINION GEAR (1.90) | ||
| 41510-415-000 | SHIM A, RING GEAR (1.80) | ||
| 41511-415-000 | SHIM B, RING GEAR (1.84) | ||
| 41512-415-000 | SHIM C, RING GEAR (1.88) | ||
| 41513-415-000 | SHIM D, RING GEAR (1.92) | ||
| 41514-415-000 | SHIM E, RING GEAR (1.96) | ||
| 41515-415-000 | SHIM F, RING GEAR (2.00) | ||
| 41516-415-000 | SHIM G, RING GEAR (2.04) | ||
| 41517-415-000 | SHIM H, RING GEAR (2.08) | ||
| 41518-415-000 | SHIM I, RING GEAR (2.12) | ||
| 41519-415-000 | SHIM J, RING GEAR (2.16) | ||
| 41520-415-000 | SHIM K, RING GEAR (2.20) | ||
| 41521-415-000 | SHIM L, RING GEAR (2.24) | ||
| 41522-415-000 | SHIM M, RING GEAR (2.28) | ||
| 41523-415-000 | SHIM N, RING GEAR (2.32) | ||
| 42623-MA1-000 | COLLAR, RR. AXLE DISTANCE | ||
| 1 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 90125-371-000 | BOLT, STUD (10X45) | ||
| 90126-415-000 | BOLT, BREATHER | ||
| 90133-371-000 | BOLT, FLANGE (8X32) | ||
| 90134-371-000 | BOLT, FLANGE (10X38) | ||
| 1 | 90305-GE8-003 | NUT, U (14MM) | 1 |
| 1 | 90305-MA1-003 | NUT, RR. AXLE U (14MM) | 1 |
| 1 | 90471-580-000 | WASHER (8MM) | 1 |
| 1 | 90545-300-000 | WASHER, OIL BOLT | 1 |
| 91051-371-003 | BEARING (6914) (TOYO SEIKO) | ||
| 91051-371-004 | BEARING (6914) (KOYO SEIKO) | ||
| 91051-371-005 | BEARING (6914) (NACHI) | ||
| 91061-371-003 | BEARING (30205) | ||
| 91062-415-013 | BEARING (30203C) | ||
| 91121-PH8-961 | BEARING, TAPER (30203) | ||
| 91261-415-003 | OIL SEAL (25X40X8) | ||
| 91262-415-003 | OIL SEAL (33X43X7) | ||
| 91264-415-003 | OIL SEAL (30X47X7) | ||
| 91265-371-003 | OIL SEAL (70X90X8) | ||
| 1 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 91353-415-003 | O-RING (49.6X3.5) | ||
| 91353-415-004 | O-RING (49.6X3.5) | ||
| 91354-415-003 | O-RING (53.6X2.4) | ||
| 91355-371-003 | O-RING (96.5X2.0) | ||
| 91356-415-003 | O-RING (62.7X4) | ||
| 4 | 92000-06012 | BOLT, HEX. (6X12) | 4 |
| 4 | 92101-06012 | BOLT, HEX. (6X12) | 4 |
| 4 | 92101-06012-0A | BOLT, HEX. (6X12) | 4 |
| 1 | 96100-60063-00 | BEARING, RADIAL BALL (6006) | 1 |
| 1 | 96201-80000 | FITTING, GREASE (B.76S) | 1 |
