Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 12010-ME5-000 | CYLINDER HEAD ASSY. Use up to Engine SN 2014959 | ||
| 12010-ME5-010 | CYLINDER HEAD ASSY. Use up to Engine SN 2014959 | ||
| 12010-ME5-010 | CYLINDER HEAD ASSY. | ||
| 12010-ME5-020 | CYLINDER HEAD ASSY. | ||
| 12010-ME5-030 | CYLINDER HEAD ASSY. | ||
| 12205-ME5-305 | GUIDE, VALVE | ||
| 12205-ME5-315 | GUIDE, VALVE | ||
| 12221-ME5-005 | PLATE, OIL CHAMBER Use up to Engine SN 2013052 | ||
| 12221-ME5-015 | PLATE, OIL CHAMBER Use up to Engine SN 2013052 | ||
| 12221-ME5-015 | PLATE, OIL CHAMBER Use up to Engine SN 2022964 | ||
| 12221-ME5-025 | PLATE, OIL CHAMBER Use up to Engine SN 2013052 | ||
| 12221-ME5-025 | PLATE, OIL CHAMBER Use up to Engine SN 2022964 | ||
| 12221-ME5-035 | PLATE, OIL CHAMBER Use up to Engine SN 2013052 | ||
| 12221-ME5-035 | PLATE, OIL CHAMBER Use up to Engine SN 2022964 | ||
| 12221-ME5-035 | PLATE, OIL CHAMBER | ||
| 12230-ME5-000 | PIPE, R. OIL Use up to Engine SN 2013052 | ||
| 12230-ME5-010 | PIPE, R. OIL Use up to Engine SN 2013052 | ||
| 12230-ME5-020 | PIPE, R. OIL Use up to Engine SN 2013052 | ||
| 12230-ME5-020 | PIPE, R. OIL | ||
| 12240-ME5-000 | PIPE, L. OIL Use up to Engine SN 2013052 | ||
| 12240-ME5-010 | PIPE, L. OIL Use up to Engine SN 2013052 | ||
| 12240-ME5-020 | PIPE, L. OIL Use up to Engine SN 2013052 | ||
| 12240-ME5-020 | PIPE, L. OIL | ||
| 12245-ME5-000 | SPACER, OIL PIPE Use up to Engine SN 2013052 | ||
| 12251-ME5-003 | GASKET, CYLINDER HEAD | ||
| 12251-ME5-005 | GASKET, CYLINDER HEAD | ||
| 1 | 12331-ME5-000 | CAP, CYLINDER HEAD SIDE | 1 |
| 1 | 12331-ME5-010 | CAP, CYLINDER HEAD SIDE | 1 |
| 15520-ME5-000 | PIPE, OIL FEED Use up to Engine SN 2013052 | ||
| 15520-ME5-010 | PIPE, OIL FEED | ||
| 1 | 15532-HC0-000 | BOLT, OIL CONTROL (8X28) Use up to Engine SN 2013052 | 1 |
| 1 | 15532-ME5-005 | BOLT B, OIL CONTROL (8X28) Use up to Engine SN 2013052 | 1 |
| 1 | 15532-ME5-015 | BOLT B, OIL CONTROL (8X28) Use up to Engine SN 2013052 | 1 |
| 1 | 15532-ME5-015 | BOLT B, OIL CONTROL (8X28) | 1 |
| 15535-ME5-000 | BOLT D, OIL CONTROL (6X38) Use up to Engine SN 2013052 | ||
| 15535-ME5-010 | BOLT D, OIL CONTROL (6X38) Use up to Engine SN 2013052 | ||
| 15535-ME5-010 | BOLT D, OIL CONTROL (6X38) | ||
| 15545-ME5-005 | BOLT C, OIL CONTROL (10X30) Use up to Engine SN 2013052 | ||
| 15545-ME5-015 | BOLT C, OIL CONTROL (10X30) Use up to Engine SN 2013052 | ||
| 15545-ME5-015 | BOLT C, OIL CONTROL (10X30) | ||
| 15565-ME5-000 | BOLT A, OIL CONTROL (8X28) Use up to Engine SN 2013052 | ||
| 15565-ME5-010 | BOLT A, OIL CONTROL (8X28) Use up to Engine SN 2013052 | ||
| 15565-ME5-010 | BOLT A, OIL CONTROL (8X28) | ||
| 16213-ME5-000 | INSULATOR, R. CARBURETOR | ||
| 1 | 16214-MB0-000 | JOINT, BOOSTER | 1 |
| 16214-ME5-000 | INSULATOR, L. CARBURETOR | ||
| 16215-ME5-000 | PLATE, CARBURETOR INSULATOR | ||
| 16215-ME5-306 | PLATE, CARBURETOR INSULATOR | ||
| 16223-ME5-000 | BAND, R. INSULATOR | ||
| 16224-ME5-000 | BAND, L. INSULATOR | ||
| 90005-ME5-000 | BOLT, SOCKET (6X22) | ||
| 1 | 90017-MA6-000 | BOLT, FLANGE (6X45.5) Use up to Engine SN 2014959 | 1 |
| 1 | 90017-MA6-000 | BOLT, FLANGE (6X45.5) Use from Engine SN 2014960 | 1 |
| 90018-MA6-000 | BOLT, FLANGE (6X77) Use up to Engine SN 2014959 | ||
| 90018-MA6-000 | BOLT, FLANGE (6X77) Use from Engine SN 2014960 | ||
| 90035-ME5-000 | BOLT, STUD (8-6X52) | ||
| 90088-ME5-000 | ORIFICE, OIL CONTROL Use up to Engine SN 2013052 | ||
| 90088-ME5-010 | ORIFICE, OIL CONTROL Use from Engine SN 2013053 | ||
| 90089-ME5-000 | ORIFICE, OIL CONTROL (9MM) Use up to Engine SN 2013052 | ||
| 90089-ME5-010 | ORIFICE, OIL CONTROL (9MM) | ||
| 90203-422-000 | NUT, FLANGE CAP (8MM) | ||
| 90436-ME5-000 | WASHER (6MM) | ||
| 1 | 90441-469-000 | WASHER, SEALING (8MM) | 1 |
| 90444-ME5-000 | NUT, SPECIAL (8MM) | ||
| 1 | 90452-323-000 | WASHER, SEALING (5MM) | 1 |
| 1 | 90475-703-000 | WASHER C (8MM) Use up to Engine SN 2013052 | 1 |
| 1 | 90475-703-000 | WASHER C (8MM) Use from Engine SN 2013053 | 1 |
| 1 | 90545-300-000 | WASHER, OIL BOLT | 1 |
| 1 | 91301-200-000 | O-RING (10X1.6) | 1 |
| 1 | 91306-HA0-003 | O-RING (33.7X2.6) (ARAI) | 1 |
| 1 | 91306-ME5-003 | O-RING (33.7X2.6) | 1 |
| 1 | 91318-ME5-003 | O-RING (5.6X1.9) (ARAI) | 1 |
| 1 | 91319-ME5-003 | O-RING (5.5X1.4) | 1 |
| 1 | 93500-05008-0A | SCREW, PAN (5X8) | 1 |
| 1 | 93500-05020-0G | SCREW, PAN (5X20) | 1 |
| 1 | 94301-08140 | PIN A, DOWEL (8X14) (YAMADA) | 1 |
| 1 | 94301-10160 | PIN A, DOWEL (10X16) | 1 |
| 1 | 98069-57916 | SPARK PLUG (DPR7EA-9) (NGK) | 1 |
| 1 | 98069-57926 | SPARK PLUG (X22EPR-U9) (DENSO) | 1 |
| 1 | 98069-58916 | SPARK PLUG (DPR8EA-9) (NGK) | 1 |
| 1 | 98069-58926 | SPARK PLUG (X24EPR-U9) (DENSO) | 1 |
| 1 | 98069-59916 | SPARK PLUG (DPR9EA-9) (NGK) | 1 |
| 1 | 98069-59926 | SPARK PLUG (X27EPR-U9) (DENSO) | 1 |
