Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 40545-KB7-000 | ADJUSTER, L. CHAIN | ||
| 40545-MA0-000 | ADJUSTER, L. CHAIN | ||
| 41200-KG1-670 | SPROCKET, FINAL DRIVEN | ||
| 41212-KG1-000 | SPACER, DRIVEN SPROCKET | ||
| 1 | 41231-429-000 | RETAINER, BEARING | 1 |
| 5 | 41241-307-010 | BUSH, RR. WHEEL DAMPER | 5 |
| 42312-KB9-000 | COLLAR, RR. WHEEL | ||
| 42610-KB9-000 | HUB, RR. WHEEL | ||
| 42620-KA2-000 | COLLAR, RR. AXLE DISTANCE | ||
| 42701-KG1-003 | RIM, RR. WHEEL | ||
| 42711-KG1-671 | TIRE, RR. (4.10-18) (BS) | ||
| 42711-KG1-672 | TIRE, RR. (4.10-18) (4PR) (DUNLOP) | ||
| 42711-437-971 | TIRE, RR. (4.10-18) (4PR) (DUNLOP) | ||
| 1 | 08400-30000 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 08400-34001 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-KA3-711 | TUBE, TIRE (BS) | 1 |
| 1 | 42712-KA5-681 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 42712-KS7-003 | TUBE, TIRE | 1 |
| 1 | 42712-KT1-671 | TUBE, TIRE (120/80-18) (IRC) | 1 |
| 42712-287-003 | TUBE, TIRE (3.25/3.50-18) (4.10-18) (BS) | ||
| 1 | 42712-300-000 | TUBE, TIRE (4.00-18) | 1 |
| 42712-300-003 | TUBE, TIRE (4.00-18) (BS) | ||
| 1 | 42712-310-004 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-312-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-340-006 | TUBE, TIRE (4.00-18) (NITTO) | 1 |
| 1 | 42712-374-003 | TUBE, TIRE (3.75-18) (BS) | 1 |
| 1 | 42712-400-003 | TUBE, TIRE (4.10-18) (BS) | 1 |
| 1 | 42712-401-681 | TUBE, TIRE (3.25/3.50-18) (4.10-18) (DUNLOP) | 1 |
| 1 | 42712-425-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-430-701 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 42712-435-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-446-003 | TUBE, TIRE (3.50/4.10-18) (BS) | 1 |
| 42712-446-631 | TUBE, TIRE (3.50-18) | ||
| 1 | 44712-300-004 | TUBE, TIRE (100/100-19) (DUNLOP) | 1 |
| 1 | 42713-268-003 | FLAP, TIRE (18) (BS) | 1 |
| 1 | 42713-401-681 | FLAP, TIRE (1.85X18) (DUNLOP) | 1 |
| 1 | 42717-329-000 | CAP, RIM HOLE | 1 |
| 5 | 90128-382-670 | BOLT, DRIVEN SPROCKET FIXING | 5 |
| 5 | 90128-446-770 | BOLT, DRIVEN SPROCKET FIXING | 5 |
| 1 | 90305-MA0-003 | NUT, AXLE (16MM) | 1 |
| 5 | 90308-382-670 | NUT, FLANGE (10MM) | 5 |
| 1 | 90504-MA0-000 | WASHER, RR. AXLE | 1 |
| 1 | 90664-KA2-000 | CIRCLIP (OUTER) (63MM) | 1 |
| 1 | 91216-729-921 | OIL SEAL (25X40X7) | 1 |
| 1 | 91252-428-000 | OIL SEAL (25X40X7) | 1 |
| 1 | 96140-62030-10 | BEARING, RADIAL BALL (6203U) | 1 |
| 1 | 96140-63030-10 | BEARING, RADIAL BALL (6303U) | 1 |
| 97508-69172-Q0 | SPOKE SET BS (8X166) | ||
| 97658-69174-Q0 | SPOKE SET B (8X167) |
