Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 41201-KA3-701 | SPROCKET, FINAL DRIVEN (51T) | ||
| 41202-KA3-701 | SPROCKET, FINAL DRIVEN (49T) (Optional). | ||
| 41203-KA3-701 | SPROCKET, FINAL DRIVEN (53T) | ||
| 41204-KA3-701 | SPROCKET, FINAL DRIVEN (51T) (STEEL) | ||
| 41231-KA4-700 | RETAINER, RR. WHEEL BEARING | ||
| 42306-KA3-830 | COLLAR, RR. AXLE | ||
| 42306-KA4-700 | COLLAR, RR. AXLE | ||
| 42311-KA4-700 | COLLAR, RR. WHEEL SIDE | ||
| 426A0-KA4-700 | SPOKE SET A, RR. (BS7X205.5) | ||
| 426B0-KA4-700 | SPOKE SET B, RR. (BS7X165) | ||
| 42601-KA3-701 | HUB, RR. WHEEL | ||
| 42620-KA4-700 | COLLAR, RR. WHEEL DISTANCE | ||
| 42621-KA4-700 | CAP, DISTANCE COLLAR | ||
| 42701-KA3-701 | RIM, RR. WHEEL (DAIDO) | ||
| 42711-KA3-003 | TIRE, RR. (4.00-18) (BS) | ||
| 1 | 08400-30000 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 08400-34001 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-KA3-711 | TUBE, TIRE (130/80-140/90) (BS) | 1 |
| 1 | 42712-KA5-681 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 42712-KS7-003 | TUBE, TIRE | 1 |
| 1 | 42712-KT1-671 | TUBE, TIRE (100/100-18) (INOUE) | 1 |
| 1 | 42712-300-000 | TUBE, TIRE (4.00-18) | 1 |
| 42712-300-003 | TUBE, TIRE (4.00-18) (BS) | ||
| 1 | 42712-310-004 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-312-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-340-006 | TUBE, TIRE (4.00-18) (NITTO) | 1 |
| 1 | 42712-374-003 | TUBE, TIRE (3.75-18) (BS) | 1 |
| 1 | 42712-400-003 | TUBE, TIRE (4.10-18) (BS) | 1 |
| 1 | 42712-425-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-430-701 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 42712-435-003 | TUBE, TIRE (4.00-18) (BS) | 1 |
| 1 | 42712-446-003 | TUBE, TIRE (3.50/4.10-18) (BS) | 1 |
| 1 | 44712-300-004 | TUBE, TIRE (100/100-18) (DUNLOP) | 1 |
| 1 | 42713-268-003 | FLAP, TIRE (18) (BS) | 1 |
| 2 | 42715-KA2-680 | STOPPER, BEAD (1.85) | 2 |
| 6 | 90125-KA3-700 | SCREW, FLAT (8X29) | 6 |
| 1 | 90305-MA2-003 | NUT, FLANGE (18MM) | 1 |
| 1 | 90305-MB4-003 | NUT, U (18MM) | 1 |
| 6 | 90309-428-731 | NUT, FLANGE (M8X1.25) (SELF-LOCK) | 6 |
| 91061-KA4-701 | BEARING, RADIAL BALL (6004TM) (TOYO) | ||
| 1 | 91257-230-000 | OIL SEAL (28X42X7) | 1 |
| 1 | 91257-230-003 | OIL SEAL (28X42X7) (ARAI) | 1 |
| 1 | 91257-230-005 | OIL SEAL (28X42X7) (NOK) | 1 |
| 2 | 94001-08000-0S | NUT, HEX. (8MM) | 2 |
| 2 | 94111-08000 | WASHER, SPRING (8MM) | 2 |
| 1 | 96140-62040-10 | BEARING, RADIAL BALL (6204U) | 1 |
| 97922-79168-U0 | SPOKE SET, RR. (BS7X164) |
