Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 703501076 | Seat Member Models XT and Lone Star | 1 |
| 1 | 390402200 | Pop Rivet 3/16" Models XT and Lone Star | 1 |
| 8 | 207682534 | Hex. Flange Screw M8 X 25 | 8 |
| 12 | 233281414 | Hex. Flange Elastic Nut M8 | 12 |
| 1 | 708001723 | Operator Seat Member Models XT and Lone Star | 1 |
| 4 | 390402200 | Pop Rivet 3/16" Models XT and Lone Star | 4 |
| 2 | 708002815 | Mid Seat Member | 2 |
| 2 | 708002821 | Passenger Seat Member Models XT and Lone Star | 2 |
| 1 | 708003242 | Seat Base Ass'y Model Lone Star | 1 |
| 1 | 708003234 | LH Seat Base Ass'y Model XT | 1 |
| 1 | 708003244 | Seat Base Ass'y Model Lone Star | 1 |
| 1 | 708003236 | RH Seat Base Ass'y Model XT | 1 |
| 1 | 708002793 | Central Cushion Ass'y Model Lone Star | 1 |
| 1 | 708001928 | Central Cushion Ass'y Model XT | 1 |
| 1 | 708003255 | Backrest Ass'y Model Lone Star | 1 |
| 1 | 708003249 | Backrest Ass'y Model XT | 1 |
| 1 | 708003254 | Backrest Ass'y Model Lone Star | 1 |
| 1 | 708003248 | Backrest Ass'y Model XT | 1 |
| 2 | 293830005 | Rubber Bumper | 2 |
| 1 | 708003160 | Backrest Ass'y Model Lone Star | 1 |
| 1 | 708003157 | Backrest Ass'y Model XT | 1 |
| 5 | 708002581 | Seat Base Pivot | 5 |
| 1 | 207684544 | Hex. Flange Screw M8 X 45 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 Models XT and Lone Star | 1 |
| 1 | 708001903 | Bushing | 1 |
| 1 | 250000760 | Torx Screw Truss Head K50X20 T20 | 1 |
| 1 | 207064544 | Hex. Screw M6 X 45 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 4 | 207182044 | Hex. Screw M8 X 20 Models XT and Lone Star | 4 |
| 1 | 250400069 | Pin | 1 |
| 1 | 269800431 | Hairpin Cotter | 1 |
| 1 | 269501487 | Latch | 1 |
| 1 | 517303756 | Grommet | 1 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 1 | 708000848 | LH Rail Models XT and Lone Star | 1 |
| 1 | 708002001 | RH Rail Models XT and Lone Star | 1 |
| 1 | 708002640 | Seat Stopper Models XT and Lone Star | 1 |
| 2 | 390402200 | Pop Rivet 3/16" Models XT and Lone Star | 2 |
| 1 | 708002293 | Cover | 1 |
| 1 | 708002331 | Driver Buckle | 1 |
| 1 | 708003163 | Middle Buckle | 1 |
| 1 | 708002329 | Passenger Buckle | 1 |
| 1 | 708003082 | LH Safety Belt | 1 |
| 1 | 708003200 | RH Safety Belt | 1 |
| 1 | 708003164 | Central Safety Belt | 1 |
| 1 | 207028046 | Hex. Screw M12 X 80 | 1 |
| 1 | 233221416 | Elastic Flange Nut M12 | 1 |
| 1 | 250000521 | Hex. Cap Screw 7/16'' X 1'' | 1 |
| 1 | 250200102 | Flat Washer M12 | 1 |
| 1 | 250100183 | Lock Nut Nylon 7/16 | 1 |
| 2 | 250000760 | Torx Screw Truss Head K50X20 T20 | 2 |
| 4 | 250000722 | Torx Screw M6 X 20 | 4 |
| 4 | 250200162 | Flat Washer M6.6 X 22 | 4 |
| 2 | 708002504 | Safety Belt screw | 2 |
| 1 | 708000890 | Safety Belt Screw | 1 |
| 1 | 708000891 | Position Washer | 1 |
