Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11101-147-000 | CRANKCASE, R. Use up to Engine SN 1234760 | ||
| 11101-147-020 | CRANKCASE, R. Use up to Engine SN 1234760 | ||
| 11101-147-020 | CRANKCASE, R. Use from Engine SN 1234671 | ||
| 11102-147-000 | BUSH, ENGINE HANGER RUBBER | ||
| 11103-147-000 | COLLAR, DISTANCE | ||
| 11191-147-000 | GASKET, CRANKCASE | ||
| 11191-147-010 | GASKET, CRANKCASE | ||
| 11191-147-306 | GASKET, CRANKCASE | ||
| 11201-147-020 | CRANKCASE, L. Use up to Engine SN 1161485 | ||
| 11201-147-030 | CRANKCASE, L. Use from Engine SN 1161486 | ||
| 11211-147-020 | TUBE, BREATHER Use up to Engine SN 1288907 | ||
| 11211-147-030 | TUBE, BREATHER | ||
| 11212-147-000 | CAP, BREATHER | ||
| 14100-147-013 | VALVE, REED (HOKUSHIN) | ||
| 14100-147-014 | VALVE, REED (NIHON) | ||
| 14100-147-015 | VALVE, REED (ARAI) | ||
| 15100-147-023 | PUMP ASSY., OIL (12T) Use up to Engine SN 1284770 | ||
| 15100-147-043 | PUMP ASSY., OIL (12T) Use up to Engine SN 1284770 | ||
| 15100-147-043 | PUMP ASSY., OIL (12T) | ||
| 15100-147-305 | PUMP ASSY. A, OIL (12T) Use up to Engine SN 1284770 | ||
| 15100-147-305 | PUMP ASSY. A, OIL (12T) | ||
| 15100-147-315 | PUMP ASSY., OIL (12T) Use up to Engine SN 1284770 | ||
| 15100-147-315 | PUMP ASSY., OIL (12T) | ||
| 15160-147-305 | GEAR SET, OIL (4/16T) (Optional). | ||
| 15525-147-000 | TUBE, OIL PASSAGE | ||
| 17100-147-000 | PIPE, INLET | ||
| 35755-001-020 | PLATE, CONTACT FIXING | ||
| 52109-222-810 | BUSH, RR. SWINGARM RUBBER (LOWER) | ||
| 90005-147-000 | SCREW, SPECIAL PAN (6X14) | ||
| 4 | 90041-147-000 | BOLT, STUD (6X108) | 4 |
| 1 | 90081-035-000 | BOLT, SEALING (14MM) Use from Engine SN 1288645 | 1 |
| 1 | 90081-086-000 | BOLT, SEALING (14MM) Use up to Engine SN 1288644 | 1 |
| 1 | 90441-035-000 | WASHER, SEALING (14MM) | 1 |
| 90451-292-000 | WASHER, THRUST (7MM) | ||
| 2 | 91201-147-003 | OIL SEAL (15X25.5X7) | 2 |
| 91210-147-305 | OIL SEAL SET (Optional). | ||
| 91254-GF0-761 | OIL SEAL (20X35X7) | ||
| 91254-816-000 | OIL SEAL (20X35X7) | ||
| 1 | 91301-GA6-000 | O-RING (18.5X2.2) | 1 |
| 1 | 91301-147-013 | O-RING (18.5X2.2) | 1 |
| 1 | 91301-147-023 | O-RING (18.3X2.3) (ARAI) | 1 |
| 2 | 93500-06022 | SCREW, PAN (6X22) | 2 |
| 2 | 93500-06022-0A | SCREW, PAN (6X22) | 2 |
| 4 | 93500-06025 | SCREW, PAN (6X25) | 4 |
| 5 | 93500-06045 | SCREW, PAN (6X45) | 5 |
| 5 | 93500-06045-0A | SCREW, PAN (6X45) | 5 |
| 1 | 93500-06080 | SCREW, PAN (6X80) | 1 |
| 1 | 93500-06080-0A | SCREW, PAN (6X80) | 1 |
| 2 | 94301-10200 | PIN A, DOWEL (10X20) | 2 |
| 2 | 95002-02650 | CLIP, TUBE (B6.5) | 2 |
| 1 | 96150-62020-10 | BEARING, RADIAL BALL (6202UU) | 1 |
