Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 572089400 | RH Protector | |
| 572089500 | LH Protector | ||
| 2 | 207182044 | Hex. Screw M8 X 20 | 2 |
| 3 | 517295600 | Rack Ass'y | |
| 4 | 415050200 | LH Grip, 370 mm | |
| 415050300 | RH Grip, 250 mm | ||
| 5 | 207182584 | Hex. Screw M8 X 25 | |
| 6 | 414988700 | Reflective Sheet | |
| 7 | 418001800 | HEAT GRIP DECAL | 1 |
| 8 | 511000002 | Switch Protector | |
| 9 | 511000001 | Rocker Switch | |
| 10 | 210261680 | Hex. Flange Screw M6 X 16 | 6 |
| 11 | 503183200 | Yellow, Washer | 2 |
| 12 | 209632540 | Phillips Tapping Screw M3.9 X 25 | 2 |
| 13 | 414516400 | Washer | |
| 14 | 414513700 | Lens | 1 |
| 15 | 410504000 | Bulb, Tail Lamp | 1 |
| 16 | 228751045 | Elastic Flange Nut M5 | 2 |
| 17 | 415109800 | Taillamp Housing | |
| 18 | 517257300 | Guide | |
| 19 | 570027400 | Rubber Shim | |
| 20 | 517251300 | SPACER | 2 |
| 21 | 572038200 | Lock Lever | |
| 22 | 414821400 | Pin | 4 |
| 23 | 517257600 | Eye Bolt | |
| 24 | 510003560 | Backrest Ass'y Includes 24 - 39. | |
| 25 | 414820900 | TILLER HANDLE | 1 |
| 26 | 414821000 | Cap | |
| 27 | 517296400 | RH Arm | |
| 28 | 517296500 | LH Arm | |
| 29 | 414813300 | Recliner | |
| 30 | 222082565 | Hex. Screw M8 x 25 | 2 |
| 31 | 224081201 | FLAT WASHER | 1 |
| 32 | 224781140 | Lock Washer 8 mm | 2 |
| 33 | 207182044 | Hex. Screw M8 X 20 | 2 |
| 34 | 232581414 | Hex. Elastic Stop Nut M8 | 2 |
| 35 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 36 | 414821200 | Backrest Foam | |
| 37 | 510003562 | Backrest Cover | |
| 38 | 415015500 | STRIP | 1 |
| 39 | 517250500 | Cap | |
| 40 | 414819600 | Washer | |
| 41 | 232581414 | Hex. Elastic Stop Nut M8 | 4 |
| 42 | 410110000 | Heating Grip | 2 |
| 43 | 732900030 | Spring Washer 8 mm | 2 |
| 44 | 414819500 | Washer | |
| 45 | 224081171 | Flat Washer 8 mm | 2 |
| 46 | 517250000 | Nut | |
| 47 | 234161601 | Lock Washer Helical M6 | 6 |
| 48 | 732601255 | Screw | |
| 49 | 572089300 | Plate | |
| 50 | 511000012 | RH Arm, Rack | |
| 517300900 | LH Am, Rack | ||
| 51 | 390906800 | Pop Rivet 3/16" | 4 |
| 52 | 206580890 | Pressure Screw M8 X 8 | 1 |
| 53 | 415050400 | Grip, Short, 60 mm | |
| 54 | 572089200 | Switch Housing | |
| 55 | 222961665 | Allen Screw M6 x 16 | 2 |
| 56 | 211200021 | Washer Plastic 6 mm | 2 |
| 57 | 228561045 | Elastic Stop Nut M6 | 4 |
| 58 | 517290000 | Guide | |
| 59 | 570063800 | Outer Spacer | |
| 60 | 572088900 | Spacer Block | |
| 61 | 517191700 | SPACER | 2 |
| 62 | 222065065 | Hex. Screw M6 x 50 (Europe) | 2 |
| 63 | 517275500 | Support | |
| 64 | 517223500 | Reinforcement | |
| 65 | 207162044 | Hex. Screw M6 X 20 | 2 |
| 66 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 8 |
| 67 | 517256100 | Inner Plate | |
| 68 | 207762044 | Carriage Bolt M6 X 20 | 4 |
| 69 | 517199300 | Hitch | |
| 70 | 517152700 | Hitch Protector | |
| 71 | 517152800 | SPRING | 1 |
| 72 | 114045200 | Hair Pin | 1 |
| 73 | 222063065 | Hex. Screw M6 x 30 | 1 |
| 74 | 228561045 | Elastic Stop Nut M6 | 1 |
| 75 | 390409400 | RIVET_POP 5/32 X ,400 BLACK | |
| 76 | 732804000 | SPRING PIN M3 X 24 | 1 |
| 77 | 414998500 | Instruction Label (Hitch) | |
| 78 | 572110800 | CAP, BLACK | 2 |
| 79 | 517008700 | Welded Hitch Plate Grand Touring SE. | 1 |
| 80 | 234061410 | Flat Washer 6 mm | 2 |
| 81 | 505001700 | CLEVIS PIN Grand Touring SE. | 1 |
| 82 | 371800200 | Cotter Pin Grand Touring SE. | 1 |
