Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 50252-KT0-670 | BAND, SUB-TANK | ||
| 51453-KK0-004 | CAP, AIR VALVE | ||
| 524A2-KA3-731 | CASE & NUT SET, ROD GUIDE | ||
| 52400-KT0-681ZA | CUSHION ASSY., RR. *R119* (FLASH RED) | ||
| 52401-KT0-681ZA | SPRING, RR. SHOCK ABSORBER *R119* (FLASH RED) | ||
| 52410-KT0-681 | DAMPER, RR. | ||
| 52421-KT0-681 | ROD, PISTON | ||
| 52422-KA3-731 | SEAT, SPRING (UPPER) (KAYABA) | ||
| 52423-KA3-731 | NUT, ADJUSTER | ||
| 52424-KS6-701 | SEAT, SPRING (LOWER) | ||
| 52424-KT1-671 | SEAT, SPRING (LOWER) | ||
| 52425-KT0-681 | CASE, RR. SHOCK ABSORBER | ||
| 52426-KT0-681 | ROD | ||
| 1 | 52427-KT1-671 | RUBBER, BUMPER | 1 |
| 52428-KA3-731 | CAP, CASE | ||
| 52429-KA3-731 | CASE, ROD GUIDE (KAYABA) | ||
| 52430-KT0-671 | TANK ASSY., SUB | ||
| 52431-KA3-731 | RING, PISTON (KAYABA) | ||
| 52435-KA3-731 | RING, SNAP | ||
| 52437-KA3-731 | CORE, VALVE | ||
| 1 | 52438-KA3-731 | NUT, HEX. (12MM) | 1 |
| 52439-KA3-731 | O-RING SET (KAYABA) | ||
| 52440-KT0-671 | HOSE, JOINT | ||
| 52441-KA3-731 | BOLT, OIL | ||
| 2 | 52442-KA3-731 | WASHER, OIL BOLT | 2 |
| 52445-KT1-671 | WASHER, SPRING SEAT | ||
| 52448-KS6-004 | SCREW, PAN (3X8) | ||
| 52449-KA3-731 | DIAL, ADJUSTING | ||
| 1 | 52451-MA0-000 | BUSH, DAMPER (LOWER) | 1 |
| 52460-KT0-670 | ARM ASSY., SHOCK ABSORBER | ||
| 52462-KF0-003 | BUSH, CUSHION ARM | ||
| 52463-KF0-000 | COLLAR, CUSHION ARM PIVOT | ||
| 52470-KT0-670 | ROD ASSY., RUBBER CONNECTING | ||
| 2 | 52472-MA0-013 | BUSH, CUSHION CONNECTING ROD | 2 |
| 2 | 52473-MA0-010 | COLLAR, CONNECTING ROD PIVOT | 2 |
| 2 | 52473-MA0-020 | COLLAR, CONNECTING ROD PIVOT | 2 |
| 52486-KA3-731 | COLLAR, SHOCK ABSORBER (UPPER) | ||
| 52487-KA3-731 | RING, STOPPER | ||
| 87516-KT1-771 | LABEL, RR. DAMPER WARNING | ||
| 90128-KF0-000 | BOLT, FLANGE (12X90) | ||
| 1 | 90129-KF0-000 | BOLT, FLANGE (10X77) | 1 |
| 90150-KK0-000 | BOLT, FLANGE (10X83) | ||
| 90151-KF0-000 | BOLT, FLANGE (10X69) | ||
| 90151-KV6-910 | BOLT, FLANGE (10X69) | ||
| 1 | 90153-KK0-000 | BOLT, FLANGE (10X58) | 1 |
| 4 | 90304-GE8-003 | NUT, U (10MM) (FUSE RASHI) | 4 |
| 1 | 90306-KF0-003 | NUT, FLANGE (12MM) (FUSERASHI) | 1 |
| 90351-KK0-004 | O-RING (1.9X9.8) | ||
| 90501-KK0-004 | WASHER (10MM) | ||
| 90501-KK6-700 | WASHER (10MM) | ||
| 1 | 91077-KA3-731 | BEARING, SPHERICAL (14MM) | 1 |
| 1 | 91077-KN5-004 | BEARING, SPHERICAL (14MM) | 1 |
| 91261-KA3-711 | SEAL, CUSHION ARM PIVOT (NOK) | ||
| 91261-KA3-712 | SEAL, CUSHION ARM PIVOT (ARAI) | ||
| 91262-KR8-750 | SEAL, CUSHION ARM PIVOT (ARAI) | ||
| 4 | 91262-KA3-711 | SEAL, CUSHION CONNECTING ROD PIVOT (NOK) | 4 |
| 4 | 91262-KA3-712 | SEAL, CUSHION CONNECTING ROD PIVOT (ARAI) | 4 |
| 2 | 91351-KA3-731 | DUST SEAL, RR. SHOCK (UPPER) | 2 |
| 1 | 94002-12000-0S | NUT, HEX. (12MM) | 1 |
| 3 | 96201-80000 | NIPPLE, GREASE (B.T6S) | 3 |
| 2 | 96300-06022-00 | BOLT, FLANGE (6X22) | 2 |
| 2 | 96500-06022-00 | BOLT, FLANGE (6X22) | 2 |
