Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 12000-KT0-680 | CYLINDER HEAD ASSY. | ||
| 12021-365-300 | GUIDE, VALVE | ||
| 1 | 12023-437-300 | GUIDE, EX. VALVE | 1 |
| 1 | 12206-KCS-305 | GUIDE, EX. VALVE (OVER SIZE) | 1 |
| 1 | 12251-KT0-P00 | GASKET, CYLINDER HEAD SET | 1 |
| 1 | 12251-446-306 | GASKET, CYLINDER HEAD | 1 |
| 1 | 12251-446-776 | GASKET, CYLINDER HEAD | 1 |
| 1 | 12260-437-000 | BUSH, CAMSHAFT | 1 |
| 1 | 12271-383-000 | RUBBER, OIL SEAL | 1 |
| 12320-427-010 | LIFTER, VALVE | ||
| 12325-427-000 | SPRING, VALVE LIFT | ||
| 12327-KT0-010 | RECEIVER, DECOMPRESSION CABLE (UPPER) | ||
| 12332-KT0-000 | BASE, PULSE GENERATOR | ||
| 1 | 12339-437-003 | GASKET, PULSE GENERATOR BASE | 1 |
| 1 | 12339-437-306 | GASKET, PULSE GENERATOR BASE | 1 |
| 1 | 12339-KT0-710 | GASKET, PULSE GENERATOR BASE | 1 |
| 1 | 12339-KT0-711 | GASKET, PULSE GENERATOR BASE | 1 |
| 2 | 12361-383-000 | CAP, TAPPET ADJUSTING HOLE | 2 |
| 16210-KT0-000 | INSULATOR, CARBURETOR | ||
| 1 | 28291-KT0-000 | CABLE, DECOMPRESSION | 1 |
| 30220-427-164 | ADVANCER ASSY., SPARK | ||
| 30300-KT0-010 | GENERATOR ASSY., PULSE | ||
| 30370-KT0-010 | COVER, PULSE GENERATOR | ||
| 1 | 30372-KA2-000 | GASKET, PULSE GENERATOR COVER | 1 |
| 1 | 30372-KT0-710 | GASKET, PULSE GENERATOR COVER | 1 |
| 1 | 32111-323-000 | CLAMP, WIRE | 1 |
| 32921-KT0-000 | CLIP, IGNITION CABLE | ||
| 90008-706-000 | BOLT, DECOMPRESSION PIVOT | ||
| 4 | 90081-383-000 | BOLT, SOCKET (6MM) Use up to Engine SN 5400866 | 4 |
| 4 | 96001-06035-00 | BOLT, FLANGE (6X35) Use from Engine SN 5400867 | 4 |
| 90081-427-000 | BOLT (6X116) | ||
| 4 | 90442-028-000 | WASHER, SEALING (8MM) | 4 |
| 4 | 90443-107-000 | NUT, CAP (8MM) | 4 |
| 1 | 90478-700-000 | WASHER A (6MM) | 1 |
| 1 | 90486-028-000 | WASHER, SPARK ADVANCER SETTING | 1 |
| 1 | 91201-427-003 | OIL SEAL (12X20X6) | 1 |
| 1 | 91202-107-003 | OIL SEAL (15X25X7) | 1 |
| 1 | 91203-965-003 | OIL SEAL (15X25X7) | 1 |
| 1 | 91301-107-000 | O-RING (75X2.5) | 1 |
| 2 | 91301-200-000 | O-RING (10X1.6) | 2 |
| 1 | 91302-200-000 | O-RING (33.5X3) | 1 |
| 1 | 91304-HB3-003 | O-RING (33.5X3.0) | 1 |
| 2 | 91303-107-000 | O-RING (35X3) | 2 |
| 1 | 96000-06012-00 | BOLT, FLANGE (6X12) | 1 |
| 1 | 96001-06012-00 | BOLT, FLANGE (6X12) | 1 |
| 1 | 92000-06014 | BOLT, HEX. (6X14) | 1 |
| 1 | 92000-06014-0A | BOLT, HEX. (6X14) | 1 |
| 1 | 92100-06014 | BOLT, HEX. (6X14) | 1 |
| 1 | 92101-06014-0A | BOLT, HEX. (6X14) | 1 |
| 2 | 92700-06035-3E | BOLT, STUD (6X35) | 2 |
| 2 | 92900-06020-3E | BOLT, STUD (6X35) | 2 |
| 2 | 92712-06028-0B | BOLT, STUD (6X28) | 2 |
| 2 | 93700-05020-0B | SCREW, OVAL (5X20) | 2 |
| 1 | 93891-05012-08 | SCREW-WASHER (5X12) | 1 |
| 2 | 94001-06000-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06200-0S | NUT, HEX. (6MM) | 2 |
| 1 | 94101-06000 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94101-06080 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94101-06800 | WASHER, PLAIN (6MM) | 1 |
| 2 | 94301-08140 | PIN, DOWEL (8X14) | 2 |
| 2 | 96000-06022-00 | BOLT, FLANGE (6X22) | 2 |
| 2 | 96001-06022-00 | BOLT, FLANGE (6X22) | 2 |
| 2 | 96000-06025-00 | BOLT, FLANGE (6X25) | 2 |
| 2 | 96001-06025-00 | BOLT, FLANGE (6X25) | 2 |
| 1 | 98069-38716 | SPARK PLUG (DR8ES-L) (NGK) | 1 |
| 1 | 98069-57716 | SPARK PLUG (DR7ES) (NGK) (Optional). | 1 |
| 1 | 98069-58716 | SPARK PLUG (DR8ES) (NGK) (Optional). | 1 |
| 1 | 98069-38719 | SPARK PLUG | 1 |
| 1 | 98069-57719 | SPARK PLUG (DR7ES) (NGK) (Optional). | 1 |
| 1 | 98069-57726 | SPARK PLUG (X22ESR-U) (DENSO) (Optional). | 1 |
| 1 | 98069-58719 | SPARK PLUG (DR8ES) (NGK) (Optional). | 1 |
| 1 | 98069-58726 | SPARK PLUG (X24ESR-U) (DENSO) | 1 |
| 1 | 98069-59726 | SPARK PLUG (X27ESR-U) (DENSO) (Optional). | 1 |
