Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y Includes 1 to 36, Electric Start | ||
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y Includes 1 to 34a, Manual Start | ||
| 417222904 | Fixed Flange Ass'y | ||
| 1 | 417222171 | Sliding Flange Ass'y Includes 3 to 6 | 1 |
| 1 | 417222758 | Bushing | 1 |
| 1 | 413703100 | Loctite 609, 10 ml | 1 |
| 1 | 293370037 | Circlip | 1 |
| 3 | 417222671 | Lever | 3 |
| 3 | 417222762 | Roller | 3 |
| 6 | 417004302 | Stopper Washer | 6 |
| 3 | 417222594 | Pin | 3 |
| 3 | 732958001 | Cotter Pin | 3 |
| 3 | 417222028 | SCREW ASS'Y | 3 |
| 3 | 232561414 | Elastic Stop Nut M6 | 3 |
| 1 | 417222312 | Spring Seat | 1 |
| 1 | 415015400 | Spring, Violet/green | 1 |
| 1 | 417007500 | Spring Cover Ass'y Includes 18 to 20 | 1 |
| 1 | 417009204 | Bushing | 1 |
| 3 | 205084044 | Socket Head Screw M8 X 1.25 X 40 | 3 |
| 3 | 250200009 | Lock Washer 8 mm | 3 |
| 417222213 | Governor Cup | ||
| 417222548 | RAMP 415 | ||
| 3 | 250400009 | Rolled Pin 10 X 22 | 3 |
| 6 | 250000059 | Hex. Flange Screw M6 X 18 | 6 |
| 3 | 417222955 | CALIBRATION SCREW | 3 |
| 3 | 417005600 | Washer | 3 |
| 3 | 233061414 | Hex. Flange Nut M6 | 3 |
| 3 | 417005700 | Spring | 3 |
| 6 | 732401030 | O-Ring | 6 |
| 6 | 417222362 | Slider Shoe | 6 |
| 1 | 417009205 | Guard | 1 |
| 3 | 234061410 | Flat Washer 6 mm | 3 |
| 417222826 | BUSHING | ||
| 1 | 417222829 | Ring Gear Electric Start | 1 |
| 6 | 250000243 | Torx Screw M8 X 16, Scotch Grip Electric Start | 6 |
| 1 | 250200006 | Spring Washer 14 mm | 1 |
| 1 | 417120000 | Drive Pulley Bolt | 1 |
| XXXX | Not Available As Spare Part - Driven Pulley Ass'y Includes 39 to 61 | ||
| 1 | 417126807 | FIXED FLANGE ASS'Y Includes 40 to 44 | 1 |
| 415005800 | Adjustment Ring | ||
| 415005900 | Adjustment Shim | ||
| 3 | 207162544 | Hex. Screw M6 X 25 | 3 |
| 3 | 207162244 | HEX. SCREW M6 X 22 | 3 |
| 1 | 417127040 | SLIDDING FLANGE ASS'Y Includes 45 to 55 | 1 |
| 1 | 417127042 | BUSHING | 1 |
| 1 | 417127043 | BUSHING | 1 |
| 1 | 413408300 | Loctite, Black Max, 3 ml | 1 |
| 371911200 | CIRCLIP | ||
| 1 | 417126878 | CIRCLIP | 1 |
| 3 | 250000279 | Torx Screw M8, Scotch Grip | 3 |
| 3 | 417127015 | Stud | 3 |
| 3 | 417126892 | Roller | 3 |
| 417126823 | V-CIRCLIP | ||
| 3 | 417126797 | WASHER | 3 |
| 417126967 | Cam Ass’y | ||
| 1 | 417126381 | GUARD | 1 |
| 1 | 504099600 | STOPPER WASHER | 1 |
| 417126688 | SPRING, GREEN | ||
| 417126734 | HALF KEY | ||
| 1 | 417126322 | SWIVEL ABUTMENT | 1 |
| 1 | 417300252 | Spacer | 1 |
| 1 | 417300265 | Spacer | 1 |
| 1 | 504112000 | Shim | 1 |
| 417300238 | PROTECTOR | ||
| 1 | 517302322 | Strength Washer | 1 |
| 1 | 207087544 | HEX. SCREW M8 X 75 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 1 | 417300166 | Drive Belt | 1 |
| 1 | 516002616 | DECAL, SUSPENSION ADJUSTMENT | 1 |
| 1 | 517281905 | Bracket | 1 |
| 3 | 390402200 | Pop Rivet 3/16" | 3 |
| 417300282 | Bracket | ||
| 1 | 516002674 | EMERGENCY STARTING LABEL | 1 |
| 1 | 417300213 | BELT GUARD | 1 |
| 1 | 417300301 | SIDE PROTECTOR ASS'Y Includes 79 to 80 | 1 |
| 417300246 | Foam | ||
| 1 | 516002670 | WARNING DECAL, SECURITY BELT GUARD | 1 |
| 417300216 | BELT GUARD BRACKET | ||
| 3 | 390909200 | Avex Rivet | 3 |
| 4 | 293150103 | Pop Rivet 3/16" | 4 |
