Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 409210000 | MALE TERMINAL | ||
| 515175254 | Cable Support | ||
| 515175400 | Drive Angle | ||
| 1 | 515175726 | PILOT LAMP, HEADLAMP | 1 |
| 1 | 515175727 | PILOT LAMP | 1 |
| 517258500 | Washer | ||
| 1 | 219704409 | Was 415080100 Fuel Line Primer 3,2mm | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 293750009 | Tie-Rap 173 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 515175220 | Wrap_Tie 200 X 4.6 - Call Your Local BRP Dealership | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 409204600 | FEMALE TERMINAL HOUSING, 24 CIRCUITS | 1 |
| 1 | 515175666 | Male Housing | 1 |
| XXXX | Not Available As Spare Part - Hex. Tapping Screw | ||
| 1 | 515167900 | Cap Assy. | 1 |
| 415073500 | Switch Nut | ||
| 1 | 570151100 | Plunger Cap | 1 |
| 1 | 234001410 | Flat Washer 10 mm | 1 |
| 1 | 515175653 | Brake Switch | 1 |
| 3 | 414176000 | Open Clamp | 3 |
| 414806500 | Case Holder | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 409013100 | Male Lock | ||
| 409204300 | Female Housing | ||
| 409207700 | Male Terminal Housing (4 circuits) | ||
| 409204500 | MALE HOUSING | ||
| 2 | 210261680 | Hex. Flange Screw M6 X 16 | 2 |
| 2 | 410107300 | Switch (Heating Grip) | 2 |
| 1 | 515175281 | Switch Cover | 1 |
| 515175762 | D.E.S.S. Switch Includes 27 - 28. | ||
| 1 | 515175232 | Male Terminal | 1 |
| 1 | 234061410 | Flat Washer 6 mm | 1 |
| 414807100 | O-Ring | ||
| 515175335 | Speedometer, Kmh | ||
| 515175336 | Speedometer, Mph | ||
| 4 | 391301700 | Washer | 4 |
| 415101500 | Speedometer Cable | ||
| 414806700 | Lock Washer | ||
| 414806900 | Nut | ||
| 1 | 232561414 | Elastic Stop Nut M6 | 1 |
| 1 | 415100600 | SPRING | 1 |
| 410501000 | Instrumentation Bulb | ||
| 515175341 | Tachometer | ||
| 1 | 515175517 | Headlamp Ass'y Includes 40 - 44. | 1 |
| XXXX | Not Available As Spare Part - Double Headlamp | ||
| 2 | 410504401 | Halogen Bulb | 2 |
| 410607100 | PROTECTOR CAP | ||
| 2 | 410608300 | BULB HOLDER | 2 |
| 1 | 224060251 | Washer | 1 |
| 2 | 250100018 | NUT M5 | 2 |
| 1 | 515175324 | SPRING | 1 |
| 2 | 207053544 | Hex. Screw M5 X 35 | 2 |
| 2 | 234051410 | Flat Washer M5 | 2 |
| 1 | 517295800 | ADJUSTER ROD | 1 |
| 1 | 415100800 | Grommet | 1 |
| 1 | 732610072 | Push Nut | 1 |
| 1 | 515175548 | Handle | 1 |
| 2 | 390402200 | Pop Rivet 3/16" | 2 |
| 515175491 | Voltage Regulator Includes 55 - 59. | ||
| 409013400 | Female Lock | ||
| 409208000 | Female Terminal Housing (4 circuits) | ||
| 278000996 | WIRE SEAL | ||
| 4 | 278000994 | FEMALE TERMINAL | 4 |
| 409013000 | Male Terminal | ||
| 409010900 | Male Terminal | ||
| 409208300 | Seal | ||
| 1 | 409013900 | SEAL | 1 |
| 1 | 515175231 | Female Terminal | 1 |
| 1 | 409010400 | Female Terminal Housing, 1 Circuit | 1 |
| 1 | 409010100 | Female Terminal | 1 |
| 1 | 409010600 | FEMALE TERMINAL | 1 |
| 409202700 | FEMALE TERMINAL HOUSING, 3 CIRCUITS | ||
| 515175320 | FEMALE TERMINAL | ||
| 1 | 515175669 | MALE HOUSING | 1 |
| 1 | 278000636 | Female Wedge, 4 Circuits | 1 |
| 1 | 515175667 | MALE TERMINAL HOUSING, 4 PIN | 1 |
| 1 | 278000739 | Male Connector, 4 Circuits | 1 |
| 1 | 515175679 | FEMALE LOCK, 12 CIRCUITS | 1 |
| 1 | 278000738 | Male Lock, 4 Circuits | 1 |
| 515175704 | FEMALE TERMINAL HOUSING, 12 CIRCUITS | ||
| 1 | 409015600 | MALE LOCK, 12 CIRCUITS | 1 |
| 2 | 270000141 | Clip | 2 |
| 1 | 293730018 | Mount Dart | 1 |
| 515175763 | Frame Harness | ||
| 515175764 | Console Harness | ||
| 515175463 | Hood Harness | ||
| 278000743 | Gauge Nut | ||
| 1 | 278000632 | Female Terminal | 1 |
| 1 | 409205300 | WIRE SEAL | 1 |
| 1 | 219704407 | Tubing 10 MM 1000MM Long | 1 |
| 1 | 219704400 | Was 409901800 Tubing (13 mm) | 1 |
| 1 | 219704408 | Tubing 16 Mm 1000Mm Long | 1 |
| 515175314 | GAINE LOW TEMP.VINYL | ||
| 2 | 517225900 | Flat Washer | 2 |
| 293740005 | Tape | ||
| 1 | 278000631 | Male Terminal | 1 |
| 278001276 | FEMALE TERMINAL | ||
| 1 | 561503100 | FEMALE TERMINAL | 1 |
| 1 | 515175654 | Male Terminal Housing, 2 Circuits | 1 |
| 1 | 515175658 | Female Housing, 2 Circuits | 1 |
| 278001742 | CONNECTOR 6 CAVITIES | ||
| 515175276 | LOCK MALE, 8 CIRCUITS | ||
| 1 | 409010300 | Female Terminal | 1 |
| 1 | 293000052 | Sealing Cap | 1 |
| 1 | 278000737 | MALE LOCK, 6 CIRCUITS | 1 |
| 1 | 409207300 | Female Connector, 2 Circuits | 1 |
| 1 | 409206900 | Male Housing, 2 Circuits | 1 |
| 1 | 409207500 | Male Lock, 2 Circuits | 1 |
| 409207100 | FEMALE LOCK, 2 CIRCUITS | ||
| 409203300 | Female Terminal | ||
| 1 | 409207600 | Male Lock, 3 Circuits | 1 |
