Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Seat Ass'y | ||
| 510003526 | Seat Cover | ||
| 510003612 | Seat Cover (Europe) Touring E. Touring SLE. | ||
| 415038202 | Seat Foam | ||
| 510003543 | Pivot (40 Tooth) Touring SLE. | ||
| 5 | 224051111 | Washer | 5 |
| XXXX | Not Available As Spare Part - Rivet | ||
| 732601221 | «T» Bolt | ||
| 2 | 732610072 | Push Nut | 2 |
| 2 | 228761045 | Elastic Flange Nut M6 | 2 |
| 1 | 414513600 | Light Housing | 1 |
| 511000007 | Light Housing Ass. Touring E. Touring SLE. | ||
| 510003628 | Hose Touring SLE. | ||
| 4 | 224781140 | Lock Washer 8 mm | 4 |
| 2 | 228751045 | Elastic Flange Nut M5 | 2 |
| 1 | 410504000 | Bulb, Tail Lamp | 1 |
| 414513700 | Lens | ||
| 2 | 414516400 | Washer | 2 |
| 2 | 732601253 | Self Tapping Phillips Screw | 2 |
| 517243800 | Rear Bumper | ||
| 6 | 365901100 | HEX. SCREW 12 X 3/4 | 6 |
| 4 | 224081171 | Flat Washer 8 mm | 4 |
| 4 | 213000001 | Lock-Washer 8 mm | 4 |
| 4 | 222082065 | Hex. Screw M8 x 20 | 4 |
| 580642600 | RH Moulding Ass'y Includes 23 - 26. | ||
| 580642700 | LH Moulding Ass'y | ||
| 580642800 | RH Moulding Ass'y (Cargo) Touring E. Touring SLE. | ||
| 580642900 | LH Moulding Ass'y (Cargo) Touring E. Touring SLE. | ||
| 224151101 | WASHER-LOCK SERRATED DIN.6798A | ||
| 2 | 222851065 | SCREW-PAN HD.PH.DIN.7985A | 2 |
| 414510100 | REFLECTOR, RED | ||
| 510003596 | Sub Seat | ||
| 510003597 | Sub Seat Touring E. Touring SLE. | ||
| 415064800 | Seat Belt | ||
| XXXX | Not Available As Spare Part - Pop Rivet | ||
| 8 | 732601250 | Screw M8 x 20 | 8 |
| 415104700 | Seat Backrest Ass'y Includes 31 - 32. Touring E. Touring LE. | ||
| 415104703 | Backrest Cover Touring E. Touring LE. | ||
| 572076800 | Upper Moulding | ||
| 4 | 224051111 | Washer | 4 |
| 572051200 | Rear Trunk | ||
| 572059700 | Snow Guard Touring E. | ||
| 572099100 | Snow Guard Touring LE. Touring SLE. | ||
| 4 | 390908000 | Rivet (Black) | 4 |
| 4 | 517225900 | Flat Washer | 4 |
| 572088700 | RH Footrest | ||
| 572088800 | LH Footrest | ||
| 6 | 732603009 | Hex. Screw M4.8 x 16 | 6 |
| 8 | 213000001 | Lock-Washer 8 mm Touring SLE. | 8 |
| 414728000 | SEAT BUCKLE | ||
| 529035571 | Tool Box With Tools Touring E. | ||
| 529035500 | TOOL KIT Touring LE. Touring SLE. | ||
| 572036310 | BOX COVER | ||
| 517264500 | Lens Rear Support | ||
| 4 | 228781045 | Elastic Flange Stop Nut M8 Touring E. Touring LE. | 4 |
| 510003609 | Z-Plate Touring E. Touring LE. | ||
| 515175250 | Female Terminal Housing, 3 Circuits Touring E. Touring SLE. | ||
| 515175252 | FEMALE TERMINAL Touring E. Touring SLE. | ||
| 414510200 | REFLECTOR, AMBER Touring E. Touring SLE. | ||
| 1 | 529032900 | Adjustment Wrench Touring SLE. | 1 |
| 8 | 222082565 | Hex. Screw M8 x 25 Touring SLE. | 8 |
| 12 | 228761045 | Elastic Flange Nut M6 Touring E. Touring SLE. | 12 |
| 2 | 222065065 | Hex. Screw M6 x 50 (Europe) Touring E. Touring SLE. | 2 |
| 4 | 222262065 | Carriage Bolt M6 x 20 (Europe) Touring E. Touring SLE. | 4 |
| 517256100 | Inner Plate Touring E. Touring SLE. | ||
| 2 | 222061865 | Hex. Screw M6 x 18 Touring E. Touring SLE. | 2 |
| 414998500 | Instruction Label (Hitch) Touring E. Touring SLE. | ||
| 517273100 | Rack Touring E. Touring SLE. | ||
| 511000019 | Support Touring E. Touring SLE. | ||
| 2 | 222064065 | Hex. Screw M6 x 40 Touring E. Touring SLE. | 2 |
| 2 | 222062065 | Hex. Screw M6 x 20 Touring E. Touring SLE. | 2 |
| 511000022 | REINFORCEMENT Touring E. Touring SLE. | ||
| 2 | 517191700 | SPACER Touring E. Touring SLE. | 2 |
| 517185600 | Spacer Touring E. Touring SLE. | ||
| 517152700 | Hitch Protector Touring E. Touring SLE. | ||
| 1 | 517152800 | SPRING Touring E. Touring SLE. | 1 |
| 1 | 114045200 | Hair Pin Touring E. Touring SLE. | 1 |
| 1 | 222063065 | Hex. Screw M6 x 30 Touring E. Touring SLE. | 1 |
| 1 | 228561045 | Elastic Stop Nut M6 Touring E. Touring SLE. | 1 |
| 390409400 | RIVET_POP 5/32 X ,400 BLACK Touring E. Touring SLE. | ||
| XXXX | Not Available As Spare Part - Washer (Europe) Touring E. Touring SLE. | ||
| XXXX | Not Available As Spare Part - Chain (Europe) Touring E. Touring SLE. | ||
| 1 | 732804000 | SPRING PIN M3 X 24 Touring E. Touring SLE. | 1 |
| 517199300 | Hitch Touring E. Touring SLE. | ||
| 2 | 228521045 | Elastic Stop Nut M12 Touring SLE. | 2 |
| 510003527 | Seat Backrest Ass'y Includes 77 - 85. Touring SLE. | ||
| 510003528 | Backrest Touring SLE. | ||
| 510003531 | Cover Touring SLE. | ||
| 510003542 | Arm RH Touring SLE. | ||
| 510003607 | Arm LH Touring SLE. | ||
| 510003532 | Fem. Handle M8 x 1.25 mm Touring SLE. | ||
| 2 | 510003533 | Handle M8 X 35 Touring SLE. | 2 |
| 510003534 | Male Handle M12 x 50 mm Touring SLE. | ||
| 510003576 | Hex. Nut Touring SLE. | ||
| 510003578 | Hex. Nut Touring SLE. | ||
| 510003584 | Lock Washer Touring SLE. | ||
| 2 | 517297900 | WASHER Touring E. Touring SLE. | 2 |
| 2 | 222053065 | Hex. Screw M5 x 30 Touring E. Touring SLE. | 2 |
