Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 50250-KA3-830 | RUBBER, SUB-TANK MOUNTING | ||
| 50251-KA3-830 | RUBBER, SUB-TANK | ||
| 50252-KA3-830 | BAND, SUB-TANK | ||
| 52400-KA3-841 | SHOCK ABSORBER, RR. (KAYABA) | ||
| 52400-KA3-842 | SHOCK ABSORBER ASSY. (KAYABA) | ||
| 52400-KA3-843 | SHOCK ABSORBER ASSY., RR. | ||
| 52400-KA3-844 | SHOCK ABSORBER ASSY., RR. | ||
| 52401-KA3-841 | SPRING, RR. SHOCK ABSORBER (4.2KG/MM) (4-GRV) (KAYABA) | ||
| 52402-KA3-841 | SPRING, RR. SHOCK ABSORBER (3.8KG/MM) (2-GRV) (KAYABA) (Optional). | ||
| 52403-KA3-841 | SPRING, RR. SHOCK ABSORBER (4.6KG/MM) (6-GRV) (KAYABA) (Optional). | ||
| 52410-KA3-841 | DAMPER, RR. (KAYABA) | ||
| 52410-KA3-842 | DAMPER, RR. (KAYABA) | ||
| 52410-KA3-843 | DAMPER, RR. | ||
| 52410-KA3-844 | DAMPER, RR. | ||
| 52421-KA3-832 | ROD, PISTON (KAYABA) | ||
| 52422-KA3-731 | SEAT, SPRING (UPPER) (KAYABA) | ||
| 52423-KA3-831 | NUT, ADJUSTER (KAYABA) | ||
| 52424-KA3-831 | SEAT, SPRING (LOWER) (KAYABA) | ||
| 52424-KS6-701 | SEAT, SPRING (LOWER) (KAYABA) | ||
| 52424-KT1-671 | SEAT, SPRING (LOWER) | ||
| 52425-KA3-831 | CASE, RR. SHOCK ABSORBER | ||
| 52426-KA3-831 | ROD (KAYABA) | ||
| 52427-KA3-731 | RUBBER, BUMPER | ||
| 52428-KA3-731 | CAP, CASE | ||
| 52429-KA3-731 | CASE, ROD GUIDE (KAYABA) | ||
| 52430-KA3-832 | SUB-TANK ASSY. (KAYABA) | ||
| 52431-KA3-731 | RING, PISTON (KAYABA) Use up to Frame SN FC607765 | ||
| 52431-KA3-832 | RING, PISTON (KAYABA) Use from Frame SN FC607766 | ||
| 52435-KA3-832 | RING, SNAP (KAYABA) | ||
| 52436-KA3-731 | CAP, AIR VALVE | ||
| 52437-KA3-731 | CORE, VALVE | ||
| 52437-KA3-831 | O-RING SET (KAYABA) | ||
| 52439-KA3-731 | O-RING SET (KAYABA) | ||
| 52437-KA3-832 | O-RING SET (KAYABA) | ||
| 1 | 52438-KA3-731 | NUT, HEX. (12MM) | 1 |
| 52440-KA3-831 | HOSE, JOINT (KAYABA) | ||
| 52441-KA3-731 | BOLT, OIL | ||
| 4 | 52442-KA3-731 | WASHER, OIL BOLT (KAYABA) | 4 |
| 52445-KA3-831 | WASHER, SPRING SEAT (KAYABA) | ||
| 52447-KA3-731 | O-RING (2.4X10.8) | ||
| 52448-KA3-731 | SCREW, PAN (3X6) | ||
| 52449-KA3-831 | DIAL, ADJUSTING | ||
| 52460-KA3-831 | ARM ASSY., SHOCK ABSORBER | ||
| 52462-KA3-831 | BUSH, DAMPER ARM | ||
| 52463-KA3-830 | COLLAR, CUSHION ARM PIVOT | ||
| 52464-KA3-830 | COLLAR, CUSHION ARM | ||
| 52470-KA3-830 | ROD ASSY., DAMPER CONNECTING | ||
| 52472-KA3-831 | BUSH, SHOCK CONNECTING ROD THRUST | ||
| 52473-KA3-830 | COLLAR, CONNECTING ROD PIVOT | ||
| 52486-KA3-731 | COLLAR, SHOCK ABSORBER (UPPER) | ||
| 52486-KA3-831 | COLLAR, SHOCK ABSORBER (UPPER) (KAYABA) | ||
| 52486-KS6-004 | COLLAR, SHOCK ABSORBER (UPPER) | ||
| 52487-KA3-731 | RING, STOPPER | ||
| 87516-KA3-741 | LABEL, RR. DAMPER CAUTION | ||
| 87516-KK0-771 | LABEL, RR. DAMPER WARNING | ||
| 87516-KT1-771 | LABEL, RR. DAMPER WARNING | ||
| 87516-KT1-901 | LABEL, RR. DAMPER WARNING | ||
| 90128-KA3-831 | BOLT, FLANGE (12X105) | ||
| 90128-KA4-003 | BOLT, FLANGE (12X105) | ||
| 1 | 90129-KF0-000 | BOLT, FLANGE (10X77) | 1 |
| 90130-KA3-830 | BOLT, FLANGE (10X83) | ||
| 90130-KS6-000 | BOLT, FLANGE (10X83) | ||
| 90153-KA3-730 | BOLT, FLANGE (10X48) | ||
| 90154-KA3-830 | BOLT, FLANGE (10X52) | ||
| 3 | 90304-GA6-003 | NUT, AXLE (10MM) | 3 |
| 1 | 90306-KA4-003 | NUT, FLANGE (12MM) | 1 |
| 1 | 90306-181-761 | NUT, FLANGE (12MM) | 1 |
| 1 | 91077-KA3-731 | BEARING, SPHERICAL (14MM) | 1 |
| 1 | 91077-KN5-004 | BEARING, SPHERICAL (14MM) | 1 |
| 91077-KA3-831 | BEARING, SPHERICAL (14MM) | ||
| 91078-KA3-831 | BEARING, NEEDLE (19.1X26.1X27) (TOYO) | ||
| 2 | 91079-KA3-831 | BEARING, NEEDLE (17.5X24.5X22) | 2 |
| 2 | 91261-KA3-831 | SEAL, RUBBER ARM PIVOT (ARAI) | 2 |
| 2 | 91261-KS6-701 | SEAL, CUSHION ARM PIVOT | 2 |
| 91262-KA3-831 | SEAL, RUBBER CONNECTING ROD PIVOT | ||
| 2 | 91351-KA3-731 | DUST SEAL, RR. SHOCK (UPPER) | 2 |
| 2 | 91351-KA3-831 | DUST SEAL, RR. SHOCK (UPPER) | 2 |
