Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 264000007 | Storage Bin Ass'y Includes 1 to 2 | 1 |
| 1 | 219704374 | Was 293250161 Gasket | 1 |
| 1 | 264000009 | Storage Bin Cover Ass'y Includes 3 to 4 | 1 |
| 1 | 293250210 | NEOPRENE SEAL | 1 |
| 2 | 269501609 | Clip | 2 |
| 2 | 264000024 | Latch | 2 |
| XXX | Not Available As Spare Parts | ||
| 1 | 264000034 | Rear Platform Ass'y Includes 8 to 13 | 1 |
| 1 | 219704375 | Was 293250186 Gasket | 1 |
| 1 | 291002585 | Rear Platform Carpet | 1 |
| 1 | 264000040 | LH Platform Carpet | 1 |
| 1 | 264000041 | RH Platform Carpet | 1 |
| 1 | 264000026 | Shock Ass'y Includes 14 to 15b | 1 |
| 2 | 269501717 | Shock End Piece | 2 |
| 2 | 293750001 | Tie Wrap 94 mm | 2 |
| 1 | 264000020 | LH Latch | 1 |
| 1 | 264000021 | RH Latch | 1 |
| 1 | 264000003 | LH Pivot Support | 1 |
| 1 | 264000032 | RH PIVOT SUPPORT | 1 |
| 2 | 264000042 | SPACER | 2 |
| 2 | 243162560 | Hex. Flange Screw M6.81 X 25, Plastite | 2 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 1 | 264000055 | LH LATCH BASE, BLACK | 1 |
| 1 | 264000056 | RH LATCH BASE, BLACK | 1 |
| 4 | 293150123 | Pop Rivet 3/16" | 4 |
| 1 | 264000001 | LH Rear Tray | 1 |
| 1 | 219704378 | Was 293250218 Gasket | 1 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 4 | 205463560 | Socket Head Screw M6 X 35 | 4 |
| 4 | 250100083 | Expansion Nut M6 X 1 | 4 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 1 | 264000002 | RH Rear Tray | 1 |
| 1 | 269500408 | Strap | 1 |
| 2 | 264000043 | TRAY PAD | 2 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 264000052 | GLOVE DOOR, SCARLET RED | ||
| 1 | 264000019 | Latch, Black | 1 |
| 1 | 293250204 | Gasket | 1 |
| 1 | 264000031 | GLOVE BOX ASS'Y Includes 40 to 41 | 1 |
| XXX | Not Available As Spare Parts Includes 42 to 43 | ||
| XXX | Not Available As Spare Parts Includes 48 to 57 | ||
| XXX | Not Available As Spare Parts Includes 49 to 51 | ||
| 1 | 264000033 | REAR REWIND CAP | 1 |
