Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 504154289 | Deep Black, Chain Case Ass'y Includes 10 to 10b | 1 |
| 2 | 250400068 | Dowel Pin | 2 |
| 3 | 250001213 | Socket Head Screw M6 X 18 | 3 |
| 1 | 250001016 | Hex Flange Screw M8 X 25 S.Grip | 1 |
| 2 | 233261434 | Flange Elastic Nut M6 | 2 |
| 1 | 293200168 | Oil Seal | 1 |
| 1 | 293350115 | Ball Bearing | 1 |
| 1 | 504152576 | Circlip | 1 |
| 1 | 504152628 | Shim | 1 |
| 1 | 504153913 | Sprocket 27 Teeth | 1 |
| 1 | 504154893 | Adapter Ass'y Includes 150 to 150f | 1 |
| 1 | 293350142 | Ball Bearing | 1 |
| 1 | 504154019 | Magnetic Cap Includes 150c to 150c2 | 1 |
| 1 | 504154043 | Cap | 1 |
| 1 | 293300291 | O-Ring Seal | 1 |
| 1 | 504152784 | Spring Washer M10 | 1 |
| 1 | 207503046 | Hex. Flange Screw M10 X 30, Scotch Grip | 1 |
| 1 | 293200159 | Oil Seal | 1 |
| 1 | 504152582 | Circlip | 1 |
| 1 | 504153995 | Sprocket 45 Teeth | 1 |
| 1 | 504152572 | Circlip | 1 |
| 1 | 504153397 | Drive Chain 116 Links | 1 |
| 1 | 414575600 | Hair Pin | 1 |
| 1 | 504153760 | Adjustment Screw | 1 |
| 1 | 250500013 | Hex. Countersunk Drain Plug | 1 |
| 1 | 293300202 | O-Ring | 1 |
| 1 | 504154577 | Chain Tensioner | 1 |
| 1 | 504153312 | Slider Chain | 1 |
| 1 | 293370105 | Circlip | 1 |
| 1 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 | 1 |
| 1 | 504154078 | Deep Black, Chain Case Cover Ass'y Includes 1700 to 1700f | 1 |
| 1 | 515178223 | Clip Connector | 1 |
| 1 | 415130141 | Braided Sleeve | 1 |
| 1 | 293300200 | O-Ring | 1 |
| 8 | 250001153 | Hex. Flange Screw M6X20 | 8 |
| 1 | 504154839 | Plug | 1 |
| 1 | 293710180 | Straight Pipe Fitting | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 503195447 | Protector Tube | 1 |
| 1 | 250001015 | Hex. Flange Screw M6 X 35 | 1 |
| 1 | 293300201 | O-Ring | 1 |
| 1 | 504153695 | Bearing Housing Ass'y Includes 2500 to 2500b | 1 |
| 1 | 250300028 | Clinch Stud, M8 X 25 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 504154942 | Drive Axle Ass'y Includes 3000 to 3000g | 1 |
| 1 | 504154910 | LH Sprocket Wheel 8 Teeth | 1 |
| 1 | 504154911 | RH Sprocket Wheel 8 Teeth | 1 |
| 1 | 504154417 | Retaining Ring | 1 |
| 1 | 293350059 | Ball Bearing | 1 |
| 1 | 293300230 | O-Ring Seal | 1 |
| 1 | 504154399 | Track 16 X 146 X 2,0 Includes 3200 to 3200b | 1 |
| 1 | 415130661 | Clip | 1 |
| 1 | 504152651 | Cleat | 1 |
| 1 | 504082900 | Washer | 1 |
