Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 15772-551-000 | CLIP, BREATHER TUBE | 2 |
| 2 | 15772-551-680 | CLIP, BREATHER TUBE | 2 |
| 16965-MK3-000 | TUBE, FUEL (7.3X130) | ||
| 17210-MB1-000 | ELEMENT, AIR CLEANER | ||
| 17215-MK3-300 | GASKET, AIR CLEANER ELEMENT | ||
| 17220-MB1-700 | COVER, AIR CLEANER HOUSING | ||
| 17221-MB1-000 | GROMMET, AIR CLEANER HOUSING COVER | ||
| 17230-MK3-000 | HOUSING, AIR CLEANER | ||
| 1 | 17212-GJ5-000 | SEAL, AIR CLEANER COVER | 1 |
| 1 | 17212-GR1-000 | SEAL, AIR CLEANER HOUSING | 1 |
| 1 | 17212-KJ9-000 | SEAL, AIR CLEANER COVER | 1 |
| 1 | 17219-HB3-000 | SEAL, AIR CLEANER COVER | 1 |
| 1 | 17222-MN4-405 | SEAL, AIR CLEANER COVER | 1 |
| 1 | 17231-MB1-000 | SEAL, AIR CLEANER HOUSING | 1 |
| 1 | 17231-MB2-000 | SEAL, AIR CLEANER HOUSING | 1 |
| 17232-MB1-000 | SEAL, AIR CLEANER BASE (NA USE ALT:17222-MN4-405) | ||
| 17241-MK3-000 | CLAMP, AIR VENT TUBE | ||
| 17245-MK3-300 | TUBE, CHAMBER | ||
| 17247-MB1-000 | RING, JOINT TUBE | ||
| 17251-MB1-701 | COVER, AIR CLEANER BASE | ||
| 17252-MB1-700 | NET, AIR CLEANER BASE | ||
| 17254-MK3-300 | DUCT, IN. | ||
| 17255-MK3-000 | COVER, R. AIR CLEANER CHAMBER | ||
| 17256-MK3-000 | COVER, L. AIR CLEANER CHAMBER | ||
| 17257-MK3-000 | STAY, R. AIR CLEANER COVER | ||
| 17258-MK3-000 | STAY, L. AIR CLEANER COVER | ||
| 17260-MK3-000 | COVER, AIR CLEANER IN. DUCT | ||
| 17349-MK3-000 | BAND, CHAMBER JOINT TUBE | ||
| 17359-MA2-000 | TUBE, DRAIN | ||
| 17551-MK3-000 | TANK, STORAGE | ||
| 17553-MK3-000 | TUBE, BREATHER | ||
| 17555-MK3-000 | TUBE, RETURN | ||
| 1 | 17724-102-700 | CLIP, SUB-TANK HOSE | 1 |
| 61402-MK3-000 | COVER, R. FR. SIDE | ||
| 61403-MK3-000 | COVER, L. FR. SIDE | ||
| 90102-MB1-000 | BOLT, AIR CLEANER COVER SETTING | ||
| 90104-MJ8-000 | BOLT, SOCKET (5X12) | ||
| 1 | 90116-ME9-000 | BOLT, FLANGE (6MM) | 1 |
| 4 | 90141-MB0-000 | SCREW, PAN (4X15) | 4 |
| 90141-MB1-000 | SCREW A, AIR CLEANER BASE COVER FIXING | ||
| 90142-MB1-000 | SCREW B, AIR CLEANER BASE COVER FIXING | ||
| 1 | 90439-MB0-000 | WASHER, RR. COVER GROMMET | 1 |
| 1 | 90522-170-700 | COLLAR, GEARSHIFT LEVER SETTING | 1 |
| 2 | 93892-04008-08 | SCREW-WASHER (4X8) | 2 |
| 1 | 93892-04012-07 | SCREW-WASHER (4X12) | 1 |
| 1 | 95002-02120 | CLIP, TUBE (B12) | 1 |
| 1 | 95002-70000 | CLIP, TUBE (C11) | 1 |
| 1 | 95700-06018-08 | BOLT, FLANGE (6X18) | 1 |
| 1 | 95701-06018-08 | BOLT, FLANGE (6X18) | 1 |
| 1 | 96000-06045-07 | BOLT, FLANGE (6X45) | 1 |
| 1 | 96001-06045-07 | BOLT, FLANGE (6X45) | 1 |
