Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 32900-ML7-671 | HOLDER, WIRE | ||
| 1 | 34908-GA7-701 | BULB, WEDGE BASE (12V 3.4W) | 1 |
| 1 | 37102-567-009 | BULB (12V3.4W) (158) | 1 |
| 1 | 37237-SA5-003 | BULB (12V3.4W2CP) (158) (NS) | 1 |
| 1 | 37237-SA5-004 | BULB (12V3.4W) (158) | 1 |
| 1 | 34908-KM1-671 | BULB, WEDGE BASE (12V3W) (TOSHIBA) | 1 |
| 1 | 37121-ML7-671 | CLAMP | 1 |
| 37200-ML7-671 | SPEEDOMETER ASSY. (MPH) (NIPPON SEIKI) | ||
| 37200-ML7-672 | SPEEDOMETER ASSY. (MPH) (NIPPON SEIKI) | ||
| 37202-ML7-671 | CASE, SPEEDOMETER (UPPER) | ||
| 37203-ML7-671 | RUBBER, SPEEDOMETER PANEL | ||
| 37204-ML7-671 | GLASS, SPEEDOMETER | ||
| 37205-ML7-671 | SOCKET, SPEEDOMETER | ||
| 37206-ML7-671 | GASKET, SPEEDOMETER | ||
| 37207-ML7-671 | PLATE, SPEEDOMETER REFLECTING | ||
| 37208-ML7-671 | CASE ASSY., SPEEDOMETER (LOWER) | ||
| 37210-ML7-671 | SPEEDOMETER | ||
| 37211-ML7-671 | BOSS, ELBOW | ||
| 1 | 37215-MA6-008 | RUBBER, METER CUSHION | 1 |
| 37216-GJ8-701 | GROMMET | ||
| 37220-445-008 | KNOB, TRIP METER | ||
| 1 | 37244-MA6-008 | WASHER, PLAIN | 1 |
| 37250-ML7-671 | METER ASSY., TACHO & TEMPERATURE | ||
| 37252-ML7-671 | CASE, TACHOMETER (UPPER) | ||
| 37253-ML7-671 | RUBBER, TACHOMETER PANEL | ||
| 37254-ML7-671 | GLASS, TACHOMETER | ||
| 37255-ML7-671 | SOCKET, TACHOMETER | ||
| 37256-ML7-671 | GASKET, TACHOMETER | ||
| 37257-ML0-721 | PLATE, TACHOMETER REFLECTING | ||
| 37257-ML7-671 | PLATE, TACHOMETER REFLECTING | ||
| 37258-ML7-671 | CASE ASSY., TACHOMETER (LOWER) | ||
| 37259-ML7-671 | COLLAR | ||
| 37260-ML7-671 | TACHOMETER | ||
| 37264-ML7-671 | SEAL | ||
| 37265-ML7-671 | VISOR, TACHOMETER | ||
| 37304-ML7-671 | RUBBER, CUSHION | ||
| 1 | 37305-KE5-008 | SCREW-WASHER (3X22) | 1 |
| 37400-ML7-671 | INSTRUMENT, TEMPERATURE | ||
| 37600-ML7-671 | BOX ASSY., PILOT | ||
| 37602-ML7-671 | CASE, PILOT BOX (UPPER) | ||
| 37603-ML7-671 | CASE ASSY. (LOWER) | ||
| 37605-ML7-671 | SOCKET, PILOT BOX | ||
| 38200-ML7-671ZA | BOX ASSY., FUSE *NH105* (MAT BLACK) | ||
| 38202-ML0-910 | COVER, FUSE *NH105* (MAT BLACK) | ||
| 38202-ML7-671 | COVER, FUSE *NH105* (MAT BLACK) | ||
| 38202-ML7-671ZA | COVER, FUSE *NH105* (MAT BLACK) | ||
| 38235-SA5-004 | PULLER, FUSE (DAIICHI) | ||
| 1 | 44830-MJ6-000 | CABLE, SPEEDOMETER | 1 |
| 1 | 44830-MT3-000 | CABLE ASSY., SPEEDOMETER | 1 |
| 44831-MM5-000 | CABLE (INNER) | ||
| 44831-443-720 | CABLE, SPEEDOMETER (INNER) | ||
| 90030-ML7-671 | SCREW-WASHER (3X12) | ||
| 90031-ML7-671 | SCREW-WASHER (3X22) | ||
| 90032-ML7-671 | SCREW, TAPPING (4X3) | ||
| 90133-SG0-A01 | SCREW, TAPPING (4X3) | ||
| 90033-ML7-671 | SCREW-WASHER (3X10) | ||
| 1 | 90158-KM7-911 | SCREW, PAN (2X6) | 1 |
| 90305-KM9-008 | NUT, SPECIAL (4MM) | ||
| 90305-MJ4-000 | NUT, SPECIAL (6MM) | ||
| 90430-ML7-671 | WASHER, PLAIN | ||
| 90431-ML7-671 | WASHER, WAVE | ||
| 1 | 91301-027-000 | O-RING (6.8X1.9) | 1 |
| 1 | 91306-PJ4-000 | O-RING (6.8X1.9) | 1 |
| 1 | 91310-MC7-003 | O-RING B (6.8X1.9) | 1 |
| 1 | 93500-04020-0G | SCREW, PAN (4X20) | 1 |
| 1 | 93500-04020-1G | SCREW, PAN (4X20) | 1 |
| 1 | 93700-05020-0G | SCREW, OVAL (5X20) | 1 |
| 1 | 93892-04010-00 | SCREW-WASHER (4X10) | 1 |
| 1 | 93892-04010-10 | SCREW-WASHER (4X10) | 1 |
| 93893-04010-07 | SCREW-WASHER (4X10) | ||
| 93893-04010-17 | SCREW-WASHER (4X10) | ||
| 1 | 93893-05020-00 | SCREW-WASHER (5X20) Use up to Frame SN GM000346 | 1 |
| 1 | 93893-05020-10 | SCREW-WASHER (5X20) Use up to Frame SN GM000346 | 1 |
| 93893-05022-07 | SCREW-WASHER (5X22) Use from Frame SN GM000347 | ||
| 1 | 93903-22480 | SCREW, TAPPING (3X16) | 1 |
| 1 | 93903-24420 | SCREW, TAPPING (4X16) | 1 |
| 1 | 93903-24480 | SCREW, TAPPING (4X16) | 1 |
| 1 | 94050-06080 | NUT, FLANGE (6MM) | 1 |
| 1 | 94591-46000 | CLIP, CABLE (4X60) | 1 |
| 1 | 98200-31000 | FUSE, BLADE (10A) | 1 |
| 1 | 98200-31500 | FUSE, BLADE (15A) | 1 |
