Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13011-ML7-305 | RING SET, PISTON (STD) | ||
| 13011-MT4-315 | RING SET, PISTON | ||
| 1 | 13021-ML7-305 | RING SET, PISTON (OS 0.25) | 1 |
| 1 | 13021-MT4-305 | RING SET, PISTON (OS 0.25) | 1 |
| 1 | 13021-MT4-315 | RING SET, PISTON (OS 0.25) | 1 |
| 1 | 13031-ML7-305 | RING SET, PISTON (OS 0.50) | 1 |
| 1 | 13031-MT4-305 | RING SET, PISTON (OS 0.50) | 1 |
| 1 | 13031-MT4-315 | RING SET, PISTON (OS 0.50) | 1 |
| 13101-MK8-670 | PISTON (STD) | ||
| 13101-MK8-770 | PISTON (STD) | ||
| 13102-MK8-305 | PISTON (OS 0.25) | ||
| 13103-MK8-305 | PISTON (OS 0.50) | ||
| 13103-MK8-306 | PISTON (OS 0.50) | ||
| 13111-ML7-000 | PIN, PISTON | ||
| 13111-MM4-000 | PIN, PISTON | ||
| 13210-MK8-670 | ROD ASSY., FR. CONNECTING | ||
| 13210-MK8-671 | ROD ASSY., FR. CONNECTING | ||
| 1 | 13213-ML7-000 | BOLT, CONNECTING ROD | 1 |
| 1 | 13213-ML7-010 | BOLT, CONNECTING ROD | 1 |
| 1 | 13215-ML7-000 | NUT, CONNECTING ROD | 1 |
| 13220-MK8-670 | ROD ASSY., RR. CONNECTING | ||
| 13220-MK8-671 | ROD ASSY., RR. CONNECTING | ||
| 13224-ML7-003 | BEARING A, FR. CONNECTING ROD (BLUE) | ||
| 13224-ML7-405 | BEARING A, CONNECTING ROD (BLUE) | ||
| 13225-ML7-003 | BEARING B, FR. CONNECTING ROD (BLACK) | ||
| 13225-ML7-405 | BEARING B, CONNECTING ROD (BLACK) | ||
| 13226-ML7-003 | BEARING C, FR. CONNECTING ROD (BROWN) | ||
| 13226-ML7-405 | BEARING C, CONNECTING ROD (BROWN) | ||
| 13227-ML7-003 | BEARING D, FR. CONNECTING ROD (GREEN) | ||
| 13228-ML7-003 | BEARING E, FR. CONNECTING ROD (YELLOW) | ||
| 13228-ML7-405 | BEARING E, CONNECTING ROD (YELLOW) | ||
| 13234-ML7-003 | BEARING A, RR. CONNECTING ROD (BLUE/BLUE) | ||
| 13235-ML7-003 | BEARING B, RR. CONNECTING ROD (BLACK/BLACK) | ||
| 13236-ML7-003 | BEARING C, RR. CONNECTING ROD (BROWN/BROWN) | ||
| 13237-ML7-003 | BEARING D, RR. CONNECTING ROD (GREEN/GREEN) | ||
| 13238-ML7-003 | BEARING E, RR. CONNECTING ROD (YELLOW/YELLOW) | ||
| 13310-MK8-670 | CRANKSHAFT | ||
| 1 | 13313-ML7-003 | BEARING A, CRANKSHAFT SIDE (BLUE) | 1 |
| 1 | 13313-ML7-691 | BEARING A, CRANKSHAFT SIDE (BLUE) | 1 |
| 13314-ML7-003 | BEARING B, CRANKSHAFT SIDE (BLACK) | ||
| 13314-ML7-690 | BEARING B, CRANKSHAFT SIDE (BLACK) | ||
| 13314-ML7-691 | BEARING B, CRANKSHAFT SIDE (BLACK) | ||
| 1 | 13315-ML7-003 | BEARING C, CRANKSHAFT SIDE (BROWN) | 1 |
| 1 | 13315-ML7-691 | BEARING C, CRANKSHAFT SIDE (BROWN) | 1 |
| 1 | 13316-ML7-003 | BEARING D, CRANKSHAFT SIDE (GREEN) | 1 |
| 1 | 13316-ML7-691 | BEARING D, CRANKSHAFT SIDE (GREEN) | 1 |
| 1 | 13317-ML7-003 | BEARING E, CRANKSHAFT SIDE (YELLOW) | 1 |
| 1 | 13317-ML7-690 | BEARING E, CRANKSHAFT SIDE (YELLOW) | 1 |
| 1 | 13317-ML7-691 | BEARING E, CRANKSHAFT SIDE (YELLOW) | 1 |
| 1 | 13323-ML7-003 | BEARING A, CRANKSHAFT CENTER (BLUE) | 1 |
| 1 | 13323-ML7-690 | BEARING A, CRANKSHAFT CENTER (BLUE) | 1 |
| 1 | 13323-MR7-013 | BEARING A, CRANKSHAFT CENTER (BLUE) | 1 |
| 13324-ML7-003 | BEARING B, CRANKSHAFT CENTER (BLACK) | ||
| 1 | 13325-ML7-003 | BEARING C, CRANKSHAFT CENTER (BROWN) | 1 |
| 1 | 13325-ML7-690 | BEARING C, CRANKSHAFT CENTER (BROWN) | 1 |
| 1 | 13325-MR7-013 | BEARING C, CRANKSHAFT CENTER (BROWN) | 1 |
| 13326-ML7-003 | BEARING D, CRANKSHAFT CENTER (GREEN) | ||
| 13326-ML7-690 | BEARING D, CRANKSHAFT CENTER (GREEN) | ||
| 1 | 13327-ML7-003 | BEARING E, CRANKSHAFT CENTER (YELLOW) | 1 |
| 1 | 13327-ML7-690 | BEARING E, CRANKSHAFT CENTER (YELLOW) | 1 |
| 1 | 13327-MR7-013 | BEARING E, CRANKSHAFT CENTER (YELLOW) | 1 |
| 1 | 90741-413-000 | KEY, WOODRUFF | 1 |
| 1 | 94601-17000 | CLIP, PISTON PIN (17MM) | 1 |
