Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 64102-MJ0-000 | CLIP, SCREEN MOLDING | 1 |
| 64110-ML7-406 | WINDSCREEN ASSY. | ||
| 64150-ML7-670 | WINDSCREEN ASSY. | ||
| 642A1-ML7-670ZA | COWL SET (UPPER) *NH138* (WL) (SHASTA WHITE) | ||
| 642A1-ML7-675ZA | COWL SET (UPPER) *NH138* (WL) (SHASTA WHITE) | ||
| 642A8-MK8-670ZA | COWL SET, R. (LOWER) *NH138* (WL) (SHASTA WHITE) | ||
| 642A8-MK8-671ZA | COWL, R. (LOWER) *NH138* (SHASTA WHITE) | ||
| 642A8-MK8-672ZA | COWL, R. (LOWER) *NH138* (SHASTA WHITE) | ||
| 642A9-MK8-670ZA | COWL SET, L. (LOWER) *NH138* (WL) (SHASTA WHITE) | ||
| 642A9-MK8-671ZA | COWL SET, L. (LOWER) *NH138* (WL) (SHASTA WHITE) | ||
| 642A9-MK8-672ZA | COWL SET, L. (LOWER) *NH138* (WL) (SHASTA WHITE) | ||
| 64201-ML7-670 | RUBBER, SCREEN SEAL | ||
| 64105-MV8-505 | MOLDING, WINDSCREEN | ||
| 64206-ML7-000 | MOLDING, WINDSCREEN | ||
| 1 | 64212-KM3-000 | RUBBER B, WINDSCREEN | 1 |
| 64212-ML7-000 | RUBBER, MIRROR SETTING | ||
| 64213-ML7-000 | STAY, MIRROR SETTING | ||
| 64214-ML7-000 | RUBBER B, WINDSCREEN | ||
| 64295-ML7-300 | MAT, R. MUFFLER | ||
| 64296-ML7-300 | MAT, L. MUFFLER | ||
| 64500-ML7-670 | STAY, FAIRING | ||
| 64505-ML7-000 | STUD ASSY. (6X14) | ||
| 64508-ML7-000 | STUD (6X14) | ||
| 1 | 64509-KE8-700 | RETAINER (6MM) | 1 |
| 64509-ML7-000 | BOLT, COWL SETTING | ||
| 64510-ML7-000 | STAY, R. COWL (LOWER) | ||
| 64510-ML7-010 | STAY, R. COWL (LOWER) | ||
| 64515-ML7-000 | STAY, COWL CENTER (LOWER) | ||
| 64520-ML7-000 | STAY, R. COWL SIDE (UPPER) | ||
| 64521-ML7-000 | STAY, L. COWL SIDE (UPPER) | ||
| 1 | 64527-ML7-000 | NUT, CLIP (4MM) | 1 |
| 64535-ML7-000 | SPRING, COWL SETTING | ||
| 64570-ML7-000 | DUCT, R. AIR | ||
| 64580-ML7-000 | DUCT, L. AIR | ||
| 64590-ML7-670ZA | PANEL, R. (INNER) *NH105* (MAT BLACK) | ||
| 64595-ML7-670ZA | PANEL, L. (INNER) *NH105* (MAT BLACK) | ||
| 64596-ML7-000 | RUBBER, PANEL SIDE (INNER) | ||
| 87522-463-930 | LABEL, WINDSCREEN CAUTION | ||
| 88110-ML7-003ZA | MIRROR, R. BACK *NH1* (BLACK) | ||
| 88110-ML7-702ZA | MIRROR, R. *NH1* (BLACK) | ||
| 88120-ML7-003ZA | MIRROR, L. *NH1* (BLACK) | ||
| 90105-ML7-000 | SCREW, PANEL SETTING (INNER) | ||
| 1 | 90111-MB6-000 | SCREW, SCREEN SETTING | 1 |
| 1 | 90112-MJ4-670 | SCREW, FAIRING SETTING | 1 |
| 1 | 90114-MG9-770 | SCREW, PROTECTOR SETTING | 1 |
| 90116-ML7-000 | SCREW, WINDSCREEN SETTING | ||
| 90150-ML7-000 | BOLT, SOCKET (6X14) | ||
| 90202-MB6-000 | NUT, SCREEN SETTING | ||
| 1 | 90316-MJ1-000 | NUT, INSERT (5X0.8) | 1 |
| 1 | 90407-952-300 | WASHER, SPECIAL (6MM) | 1 |
| 94021-10270-0S | NUT, CAP (10MM) | ||
| 1 | 94101-10700 | WASHER, PLAIN (10MM) | 1 |
| 1 | 94103-06800 | WASHER, PLAIN (6MM) | 1 |
| 94111-10700 | WASHER, SPRING (10MM) | ||
| 1 | 95700-06016-00 | BOLT, FLANGE (6X16) | 1 |
| 1 | 95701-06016-00 | BOLT, FLANGE (6X16) | 1 |
| 1 | 95701-08016-08 | BOLT, FLANGE (8X16) | 1 |
| 1 | 95800-08016-08 | BOLT, FLANGE (8X16) | 1 |
| 1 | 95800-08028-08 | BOLT, FLANGE (8X28) | 1 |
| 1 | 95801-08028-08 | BOLT, FLANGE (8X28) | 1 |
