Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 400409430 | Engine 493 RER Legend 500. | ||
| 400509736 | Engine 593 RER Legend 600. | ||
| 400604026 | «693» Engine (Rer) Legend 700. | ||
| 1 | 512059488 | ENGINE SUPPORT | 1 |
| 4 | 234001410 | Flat Washer 10 mm | 4 |
| 234100602 | WASHER-LOCK SPRING DIN.128A-A2 | ||
| 4 | 233201414 | Hex. Flange Elastic Nut M10 | 4 |
| 570128700 | RUBBER MOUNT | ||
| 4 | 233601416 | Elastic Locking Nut M10 X 1.5 | 4 |
| 512050900 | Engine Support | ||
| 4 | 512056700 | Lock Washer | 4 |
| 4 | 207102544 | Hex. Screw M10 X 25 | 4 |
| 512058500 | Support Plate | ||
| 1 | 207182044 | Hex. Screw M8 X 20 | 1 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
| 1 | 232581414 | Hex. Elastic Stop Nut M8 | 1 |
| 1 | 512058800 | STOPPER SCREW | 1 |
| 512059056 | Stopper | ||
| 512059057 | WASHER | ||
| 1 | 732610019 | RH Hex. Jam Nut M12 | 1 |
| 514053263 | Muffler Bracket | ||
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 2 | 414913700 | SPRING | 2 |
| 1 | 570039000 | EXHAUST GROMMET Legend 500. Legend 600. | 1 |
| 514053064 | Exhaust Grommet Legend 700. | ||
| 514053325 | Muffler Legend 500. Legend 600. | ||
| 514053537 | Muffler Legend 700. | ||
| 514053160 | RH Heat Shield Legend 500. Legend 600. | ||
| 514053606 | RH Heat Shield Legend 700. | ||
| 514052733 | LH Heat Shield Legend 500. Legend 600. | ||
| 514053516 | LH HEAT SHIELD Legend 700. | ||
| 514052734 | RH Insulating Wool Legend 500. Legend 600. | ||
| 514053294 | RH Insulating Wool Legend 700. | ||
| 514052844 | LH Insulating Wool Legend 500. Legend 600. | ||
| 514053295 | LH Wooll Insulating Legend 700. | ||
| 10 | 390910000 | Pop Rivet 3/16” | 10 |
| 1 | 514052704 | RUBBER BUMPER | 1 |
| 514053488 | Tuned Pipe Ass’Y Includes 30 - 40. Legend 500. | ||
| 514053495 | Tuned Pipe Ass’Y Includes 30 - 41. Legend 600. | ||
| 514053676 | Tuned Pipe Ass’Y Includes 30 - 40. Legend 700. | ||
| 514053167 | Upper Enveloppe Legend 500. | ||
| 514053192 | Upper Enveloppe Legend 600. | ||
| 514053690 | Upper Enveloppe Legend 700. | ||
| 1 | 514053193 | REAR UPPER ENVELOPE Legend 600. | 1 |
| 1 | 514053313 | REAR UPPER ENVELOPE Legend 700. | 1 |
| 514053360 | Lower Envelope Legend 500. | ||
| 1 | 514053367 | LOWER ENVELOPE Legend 600. | 1 |
| 514053691 | Lower Envelope Legend 700. | ||
| 1 | 514053196 | REAR LOWER ENVELOPE Legend 600. | 1 |
| 1 | 514053314 | REAR LOWER ENVELOPE Legend 700. | 1 |
| 514052716 | Insulating Wool Legend 500. | ||
| 2 | 514053285 | INSULATING WOOL Legend 600. | 2 |
| 514053696 | Insulating Wool Legend 700. | ||
| 1 | 514053499 | Retaining Strap Legend 500. | 1 |
| 1 | 514053501 | Retaining Strap Legend 600. | 1 |
| 1 | 514053494 | RETAINING STRAP Legend 500. | 1 |
| 1 | 514053498 | Retaining Strap Legend 600. | 1 |
| 1 | 514053502 | Retaining Strap Legend 500. | 1 |
| 514053512 | RETAINING STRAP Legend 600. | ||
| 1 | 514053540 | RETAINING STRAP | 1 |
| 1 | 514053493 | RETAINING STRAP Legend 500. | 1 |
| 1 | 514053500 | RETAINING STRAP Legend 600. Legend 700. | 1 |
| 514053180 | Rubber Pad Legend 600. | ||
| 570044100 | Rubber Pad | ||
| 2 | 293150103 | Pop Rivet 3/16" | 2 |
| 1 | 293800090 | Sealant, Loctite, 80 ml | 1 |
| 8 | 415107100 | Spring | 8 |
| 514052718 | Reflective Sheet | ||
| 1 | 514053390 | REFLECTIVE SHEET | 1 |
| 2 | 514053436 | Spring Bracket | 2 |
| 1 | 207151244 | Hex. Screw M5 X 12 | 1 |
| 1 | 233251414 | Hex. Flange Elastic Nut M5 | 1 |
| 4 | 514053343 | GUIDE | 4 |
| 233481413 | Lock Spring Nut M8 | ||
| 1 | 514053442 | SUPPORT Legend 700. | 1 |
| 514053489 | Calibration Tube Legend 500. | ||
| 4 | 514053643 | Spring | 4 |
| 1 | 514053491 | RETAINING STRAP Legend 600. | 1 |
| 1 | 514053492 | Retaining Strap Legend 700. | 1 |
