Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 30 | 234081410 | Flat Washer 8 mm | 2 |
| 70 | 250000942 | Hex Screw M8 X 30 | 2 |
| 80 | 234081410 | Flat Washer 8 mm | 2 |
| 90 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 100 | 518334517 | Engine Chassis Module Ass'y Includes 100 to 100n | 1 |
| 100a | 518334523 | RH Side Member Ass'y Includes 100a to 100a3 | 1 |
| 100a3 | 505072690 | Leg Bushing | 1 |
| 100b | 518334599 | LH Side Member Ass'y Includes 100b to 100b2 | 1 |
| 100b2 | 505072690 | Leg Bushing | 1 |
| 100c | 293150148 | Rivet Magna-Grip 6,4 X 50,8 | 3 |
| 100d | 293150149 | Collar Huck Magna-Grip 6.4 | 3 |
| 100f | 518332715 | Bottom Plate | 1 |
| 100g | 293150203 | Rivet Avibulb 3/16 | 14 |
| 100h | 293450268 | Insert M5 X 0.8 | 1 |
| 100j | 293150148 | Rivet Magna-Grip 6,4 X 50,8 | 2 |
| 100k | 293150149 | Collar Huck Magna-Grip 6.4 | 2 |
| 100m | 518329454 | Oil Plate | 1 |
| 100n | 250000767 | Torx Truss Screw M6 X 12 | 2 |
| 110 | 293150267 | Rivet Ornit 6,5 X 16.5 | 3 |
| 115 | 207662046 | Hex. Flange Screw M6 X 20 | 2 |
| 120 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 125 | 293150268 | Rivet Ornit 6,5 X 18.5 | 2 |
| 127 | 293150264 | Rivet Ornit 6,5 X 10.5 | 2 |
| 128 | 293150266 | Ornit Rivet 6,5 X 14.5 | 4 |
| 130 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 140 | 207662046 | Hex. Flange Screw M6 X 20 | 2 |
| 150 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 180 | 207661646 | Hex. Flange Screw M6 X 16 | 4 |
| 300 | 518333691 | LH Side Member Ass'y Includes 300 to 300b | 1 |
| 300b | 512061516 | Vibration Damper | 2 |
| 310 | 250001060 | Screw-Pan HD.Torx M8X30 | 4 |
| 350 | 518331740 | LH Front Chassis Reinforcement | 1 |
| 400 | 518334461 | Chassis Suspension Module | 1 |
| 410 | 250001051 | Screw-Forming Hex.HD.FL. M6 X 16 | 2 |
| 435 | 207562056 | Hex. Flange Screw M6 X 20 | 1 |
| 440 | 293150267 | Rivet Ornit 6,5 X 16.5 | 6 |
| 800 | 518332514 | LH Under Chassis Reinforcement | 1 |
| 810 | 518332516 | RH Under Chassis Reinforcement | 1 |
| 815 | 293150271 | Rivet Ornit 6,5 X 10.5 | 6 |
| 820 | 518331733 | Cross Member Support | 2 |
| 830 | 293150266 | Ornit Rivet 6,5 X 14.5 | 4 |
| 850 | 293150265 | Rivet Ornit 6,5 X 12.5 | 4 |
| 900 | 518333368 | Deep Black, LH Rear Diagonal Cross Member | 1 |
| 910 | 518333369 | Deep Black, RH Rear Diagonal Cross Member | 1 |
| 920 | 250000887 | Pan Head Torx Screw M8 X 12 | 4 |
| 1100 | 518329370 | Upper Colomn Support | 1 |
| 1105 | 518330916 | Upper Side Column Support | 1 |
| 1120 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1121 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1122 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1123 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1124 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1125 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1126 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1140 | 207662046 | Hex. Flange Screw M6 X 20 | 1 |
| 1141 | 207662046 | Hex. Flange Screw M6 X 20 | 1 |
| 1142 | 207662046 | Hex. Flange Screw M6 X 20 | 1 |
| 1143 | 207662046 | Hex. Flange Screw M6 X 20 | 1 |
| 1144 | 207662046 | Hex. Flange Screw M6 X 20 | 1 |
| 1145 | 207662046 | Hex. Flange Screw M6 X 20 | 1 |
| 1146 | 207662556 | Hex. Flange Screw M6 X 25 | 1 |
| 1150 | 207562056 | Hex. Flange Screw M6 X 20 | 1 |
| 1200 | 518329906 | Center Column Support | 1 |
