Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11100-KZ4-J00 | CRANKCASE, R. | ||
| 1 | 11191-KZ4-620 | GASKET, CRANKCASE | 1 |
| 11200-KZ4-J00 | CRANKCASE, L. | ||
| 1 | 11211-ML3-910 | TUBE, BREATHER | 1 |
| 14100-KZ4-J01 | VALVE ASSY., REED | ||
| 14111-KZ4-003 | REED VALVE | ||
| 14121-KZ4-J01 | STOPPER, REED VALVE | ||
| 1 | 14132-KZ4-620 | GASKET, REED VALVE | 1 |
| 16221-KZ4-A10 | INSULATOR, CARBURETOR | ||
| 16223-KA4-740 | BAND, INSULATOR | ||
| 1 | 22810-KS6-700 | LIFTER, CLUTCH | 1 |
| 2 | 23521-KW3-000 | PLATE A, BEARING SETTING | 2 |
| 2 | 90012-KZ4-700 | BOLT, STUD (8X35) | 2 |
| 2 | 90015-MR1-000 | BOLT, STUD (8X35) | 2 |
| 1 | 90015-KA3-711 | BOLT, SPECIAL (12MM) | 1 |
| 1 | 90463-ML7-000 | WASHER, SEALING (6.5MM) | 1 |
| 1 | 91001-KA3-711 | BEARING, BALL (6204) | 1 |
| 2 | 91002-KA4-005 | BEARING, RADIAL BALL (7X19X6) (NACHI) | 2 |
| 2 | 91002-KE1-014 | BEARING, RADIAL BALL (63/22) | 2 |
| 2 | 91002-KY4-901 | BEARING, RADIAL BALL (63/22) | 2 |
| 2 | 91002-466-008 | BEARING, RADIAL BALL (63/22) (TOYO) | 2 |
| 1 | 91004-KZ4-A11 | BEARING, RADIAL BALL (20X42X11) (KOYO) | 1 |
| 1 | 91004-GC4-731 | BEARING, RADIAL BALL (25X42X9) (TOYO) | 1 |
| 1 | 91004-430-003 | BEARING, RADIAL BALL (6905Z) (NACHI) | 1 |
| 2 | 91012-KA3-710 | PLATE, COUNTERSHAFT BEARING | 2 |
| 1 | 91022-KA4-740 | BEARING, SHELL (33X38X8) (NTN) | 1 |
| 1 | 91201-KS6-004 | OIL SEAL (26X37X7) (ARAI) | 1 |
| 1 | 91201-VB3-802 | OIL SEAL (10X17X4) (NOK) | 1 |
| 1 | 91202-KA3-711 | OIL SEAL (10X17X4) (ARAI) | 1 |
| 1 | 91202-KA3-712 | OIL SEAL (10X17X4) (NOK) | 1 |
| 1 | 91203-KA4-771 | OIL SEAL (14X22X5) (NOK) | 1 |
| 1 | 91203-KA4-772 | OIL SEAL (14X22X5) (ARAI) | 1 |
| 1 | 91203-KK3-830 | OIL SEAL (14X22X5) | 1 |
| 1 | 91203-KS6-004 | OIL SEAL (30X45X8) (ARAI) | 1 |
| 1 | 91205-166-004 | OIL SEAL (20X32X7) (NOK) | 1 |
| 1 | 91406-657-671 | CLIP, WIRE HARNESS | 1 |
| 1 | 92301-06010-0A | BOLT, RECESSED (6X10) | 1 |
| 2 | 92900-08035-3E | BOLT, STUD (8X35) | 2 |
| 1 | 93500-05025-0A | SCREW, PAN (5X25) | 1 |
| 2 | 93600-06012-0A | SCREW, FLAT (6X12) | 2 |
| 6 | 93892-03006-08 | SCREW-WASHER (3X6) | 6 |
| 1 | 94109-12000 | WASHER, DRAIN PLUG (12MM) | 1 |
| 2 | 94301-08140 | PIN, DOWEL (8X14) | 2 |
| 2 | 94301-10160 | PIN, DOWEL (10X16) | 2 |
| 2 | 96001-06014-00 | BOLT, FLANGE (6X14) | 2 |
| 3 | 96001-06045-00 | BOLT, FLANGE (6X45) | 3 |
| 4 | 96001-06050-00 | BOLT, FLANGE (6X50) | 4 |
| 2 | 96001-06075-00 | BOLT, FLANGE (6X75) | 2 |
| 1 | 96001-06085-00 | BOLT, FLANGE (6X85) | 1 |
| 1 | 96100-60030-00 | BEARING, RADIAL BALL (6003) | 1 |
| 1 | 91001-KZ4-J11 | BEARING, RADIAL BALL (17X35X10) | 1 |
| 4 | 96300-06022-00 | BOLT, FLANGE (6X22) | 4 |
