Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 10 | 506153209 | Black, Handle Bar | 1 |
| 18 | 293740005 | Tape | |
| 19 | 293740005 | Tape | |
| 20 | 506152560 | Grip 148mm | 2 |
| 25 | 506152856 | Heated Film | 2 |
| 50 | 506153176 | Thermal Insulation | 2 |
| 60 | 293740005 | Tape | |
| 400 | 860201427 | Riser Kit 120 Includes 400 to 400a1 | 1 |
| 405 | 506152894 | Steering Support | 2 |
| 410 | 506152894 | Steering Support | 2 |
| 420 | 250000904 | Button Head Torx Screw M8 X 38 | 4 |
| 430 | 250000852 | Hex. Flange Screw M8 X 1.25 x 40 | 4 |
| 900 | 506153366 | Steering Arm Ass'y Includes 900 to 900q | 1 |
| 900a | 506153197 | LH Swivel Arm Ass. Includes 900a to 900a2 | 1 |
| 900a2 | 503194671 | Bushing | 2 |
| 900b | 506152790 | RH Swivel Arm Includes 900b to 900b2 | 1 |
| 900b2 | 503194671 | Bushing | 2 |
| 900c | 506152792 | Swivel Pivot | 2 |
| 900d | 503191800 | Washer | 4 |
| 900f | 506153198 | Steering Support Includes 900f to 900f1 | 1 |
| 900g1 | 250300038 | Clinch Stud | 2 |
| 900h | 207088544 | HEX. SCREW M8 X 85 | 2 |
| 900j | 503192494 | Washer | 2 |
| 900k | 233281466 | Elastic Flange Nut M8 | 2 |
| 900m | 506152755 | Ball Joint | 1 |
| 900n | 250001028 | Hex. Flange Screw M6 X 45 | 2 |
| 900p | 506151245 | Washer | 4 |
| 900q | 233281466 | Elastic Flange Nut M8 | 2 |
| 903 | 506153157 | Steering Stopper Includes 903 to 903b | 1 |
| 905 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 910 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 915 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 920 | 207687044 | Hex. Flange Screw M8 X 70 | 1 |
| 930 | 207685044 | Hex. Flange Screw M8 X 50 | 1 |
| 940 | 506151245 | Washer | 3 |
| 950 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 960 | 506152753 | Ball Joint | 1 |
| 970 | 506152582 | Washer | 1 |
| 980 | 232500416 | Elastic Stop Nut M10 | 1 |
| 1000 | 506153026 | Main Tube Includes 1000 to 1000f | 1 |
| 1010 | 506152219 | Upper Half Housing | 2 |
| 1012 | 506153048 | Lower Half Housing | 2 |
| 1014 | 506152292 | Upper Vibration Ring | 2 |
| 1016 | 506152518 | Lower Vibration Ring | 2 |
| 1020 | 506152297 | Housing Bushing | 1 |
| 1021 | 250001114 | Hex. Flange Screw M6 x 75 | 1 |
| 1022 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1030 | 506152297 | Housing Bushing | 1 |
| 1031 | 250001114 | Hex. Flange Screw M6 x 75 | 1 |
| 1032 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 1050 | 506152937 | Housing Bushing | 2 |
| 1051 | 207687044 | Hex. Flange Screw M8 X 70 | 2 |
| 1052 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 1053 | 506152938 | Stopper Plate | 1 |
| 1100 | 506153294 | Cap | 2 |
| 1110 | 293150008 | Pop Rivet 3/16" | 10 |
| 1250 | 506153302 | Tie Rod Ass'y Includes 1250 to 1250c | 2 |
| 1250a | 506152344 | LH Threaded Ball Joint | 1 |
| 1250b | 506152684 | RH Threaded Ball Joint | 1 |
| 1250c | 732610010 | RH Threaded Hex. Jam Nut M10 | 1 |
| 1280 | 506152582 | Washer | 2 |
| 1300 | 233201464 | Hex. Flange Elastic M10 x 1.5 | 2 |
