Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 20 | 515178492 | Braided Sleeve 60MM Long | 1 |
| 65 | 514056378 | Rubber Sheet | 1 |
| 300 | 512061447 | LH Side Member Includes 300 to 300a | 1 |
| 310 | 512061449 | Upper CVT Cooling Duct | 1 |
| 315 | 250000995 | Torx-truss M/s M6 X 10 | 2 |
| 317 | 207563544 | Hex. Flange Screw S.Grip M6 X 35 | 1 |
| 320 | 512061450 | Lower CVT Cooling Duct | 1 |
| 325 | 250000995 | Torx-truss M/s M6 X 10 | 3 |
| 420 | 293370122 | Circlip | 1 |
| 440 | 207551044 | Hex. Flange Screw M5 X 10 | 2 |
| 1000 | 512061416 | LH Rear Engine Support Ass'y Includes 1000 to 1000b2 | 1 |
| 1000a | 512061417 | LH Rear Engine Support | |
| 1020 | 250001016 | Hex Flange Screw M8 X 25 S.Grip | 2 |
| 1030 | 250200146 | Conical Spring Washer M8 | 2 |
| 1200 | 512061418 | LH Front Engine Support Ass'y Includes 1200 to 1200b2 | 1 |
| 1200a | XXX | Not Available As Spare Parts | |
| 1210 | 250001016 | Hex Flange Screw M8 X 25 S.Grip | 2 |
| 1220 | 250200146 | Conical Spring Washer M8 | 2 |
| 1300 | 512061439 | RH Front Engine Support | 1 |
| 1305 | 512061454 | Vibration Damper Includes 1305 to 1305b | 1 |
| 1310 | 250001016 | Hex Flange Screw M8 X 25 S.Grip | 2 |
| 1320 | 250200146 | Conical Spring Washer M8 | 2 |
| 1330 | 250001062 | Hex. Flange Screw M6 X 16 | 2 |
| 1400 | 512061411 | RH Rear Engine Support Ass'y | 1 |
| 1410 | 250001016 | Hex Flange Screw M8 X 25 S.Grip | 2 |
| 1420 | 250200146 | Conical Spring Washer M8 | 2 |
| 1500 | 512061454 | Vibration Damper Includes 1500 to 1500b | 1 |
| 1540 | 250001062 | Hex. Flange Screw M6 X 16 | 2 |
| 1550 | 207585544 | Hex. Flange Screw M8 X 55 | 2 |
| 1560 | 503183200 | Yellow, Washer | 2 |
| 1570 | 250200008 | Flat Washer With Teflon 8 mm | 2 |
| 1580 | 205082544 | Socket Head Screw M8 X 25 | 2 |
| 1585 | 503183200 | Yellow, Washer | 2 |
| 1595 | 232581414 | Hex. Elastic Stop Nut M8 | 2 |
| 1700 | 512061530 | Engine Stopper | 2 |
| 2000 | 508001159 | Primary Chamber Ass'y Includes 2000 to 2000j | 1 |
| 2000d | 732610072 | Push Nut | 10 |
| 2000f | 512061083 | Rubber | 1 |
| 2000g | 420441840 | Screw | 2 |
| 2010 | 512061325 | Cable Guide | 1 |
| 2020 | 250000759 | Torx Truss Pt K40 X 16 | 1 |
| 2030 | 293650212 | GEMI Clamp | 2 |
| 2050 | 420201630 | Rubber Cap | 2 |
| 2060 | 512061274 | Airbox Support | 1 |
| 2070 | 293150291 | Black, Pop Rivet 3/16 X ,425 | 3 |
| 2080 | 293150292 | Black, Pop Rivet 3/16 X ,550 | 1 |
| 3600 | 512061224 | Throttle Cable | 1 |
| 3690 | 414274500 | Circlip | 1 |
| 3800 | 512060859 | Upper Housing | 1 |
| 3810 | 512060860 | Lower Housing | 1 |
| 3820 | 512061544 | Heated Hand Lever Accelerator | 1 |
| 3840 | 250000991 | Flange Screw M5x12 | 2 |
| 4200 | 512061168 | Ignition Coil Includes 4200 to 4200a | 1 |
| 4210 | 243141630 | Hex. Plastic Screw M4.8 X 16 | 3 |
| 4220 | 512061166 | Ignition Cable | 2 |
| 4240 | 512061238 | Spark Plug Wire Holder | 2 |
| 4270 | 293300059 | O-Ring | 1 |
| 5050 | 512060993 | Clamp | 2 |
| 5300 | 512060136 | Starter Grip | 1 |
| 5610 | 512061513 | LH Acoustic Cover | 1 |
