Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 11100-K04-932 | CRANKCASE, R. | 1 |
| 1 | 11103-K04-930 | BUSH, R. ENGINE HANGER (OUTER) | 1 |
| 1 | 11104-K04-930 | BUSH, L. ENGINE HANGER (OUTER) | 1 |
| 2 | 11105-KTW-900 | BUSH, ENGINE HANGER (INNER) | 2 |
| 1 | 11110-KTW-901 | VALVE, REED | 1 |
| 1 | 11200-K04-931 | CRANKCASE, L. | 1 |
| 1 | 11205-KTW-900 | GASKET, OIL PASSAGE | 1 |
| 2 | 13312-KTW-901 | BEARING A, R. CRANKSHAFT SIDE (BLUE) | 2 |
| 2 | 13313-KTW-901 | BEARING B, R. CRANKSHAFT SIDE (BLACK) | 2 |
| 2 | 13314-KTW-901 | BEARING C, R. CRANKSHAFT SIDE (BROWN) | 2 |
| 2 | 13315-KTW-901 | BEARING D, R. CRANKSHAFT SIDE (GREEN) | 2 |
| 2 | 13316-KTW-901 | BEARING E, R. CRANKSHAFT SIDE (OVER SIZE) (BLUE/BLUE) (Optional). | 2 |
| 2 | 13317-KTW-901 | BEARING F, R. CRANKSHAFT SIDE (OVER SIZE) (BLACK/BLACK) (Optional). | 2 |
| 2 | 13318-KTW-901 | BEARING G, R. CRANKSHAFT SIDE (OVER SIZE) (BROWN/BROWN) (Optional). | 2 |
| 2 | 13319-KTW-901 | BEARING H, R. CRANKSHAFT SIDE (OVER SIZE) (GREEN/GREEN) (Optional). | 2 |
| 2 | 13322-KTW-901 | BEARING A, L. CRANKSHAFT SIDE (BLUE) | 2 |
| 2 | 13323-KTW-901 | BEARING B, L. CRANKSHAFT SIDE (BLACK) | 2 |
| 2 | 13324-KTW-901 | BEARING C, L. CRANKSHAFT SIDE (BROWN) | 2 |
| 2 | 13325-KTW-901 | BEARING D, L. CRANKSHAFT SIDE (GREEN) | 2 |
| 2 | 13326-KTW-901 | BEARING E, L. CRANKSHAFT SIDE (OVER SIZE) (BLUE/BLUE) (Optional). | 2 |
| 2 | 13327-KTW-901 | BEARING F, L. CRANKSHAFT SIDE (OVER SIZE) (BLACK/BLACK) (Optional). | 2 |
| 2 | 13328-KTW-901 | BEARING G, L. CRANKSHAFT SIDE (OVER SIZE) (BROWN/BROWN) (Optional). | 2 |
| 2 | 13329-KTW-901 | BEARING H, L. CRANKSHAFT SIDE (OVER SIZE) (GREEN/GREEN) (Optional). | 2 |
| 1 | 15153-HN7-000 | STRAINER, OIL | 1 |
| 3 | 15155-300-000 | COLLAR, O-RING | 3 |
| 2 | 15155-HP0-A00 | COLLAR, O-RING | 2 |
| 1 | 15220-KTW-900 | VALVE ASSY., RELIEF | 1 |
| 1 | 15231-413-020 | VALVE, RELIEF | 1 |
| 1 | 15410-MFJ-D01 | FILTER, OIL (TOYO ROKI) (Honda Code 8597650) | 1 |
| 1 | 15410-MFJ-D02 | FILTER, OIL (WAKO FILTER) | 1 |
| 1 | 15421-K04-930 | SCREEN, OIL FILTER | 1 |
| 1 | 28810-R90-013 | PICK-UP ASSY. (TOYO) | 1 |
| 1 | 32105-K04-930 | SUB-WIRE, ENGINE | 1 |
| 1 | 35500-MEH-661 | SWITCH ASSY., OIL PRESSURE (DENSO) | 1 |
| 1 | 38515-KTW-900 | GUIDE, OIL PRESSURE SWITCH WIRE | 1 |
| 1 | 52108-KTW-B00 | BUSH, DAMPER | 1 |
| 1 | 90002-KTW-900 | BOLT, DRAIN PLUG (12MM) | 1 |
| 1 | 90002-PA6-003 | BOLT-WASHER (4X8) (DENSO) | 1 |
| 1 | 90019-MGZ-J00 | BOSS, OIL FILTER | 1 |
| 3 | 90474-333-000 | WASHER, SEALING (8MM) | 3 |
| 1 | 90601-K04-930 | CIRCLIP (INNER) (65) | 1 |
| 1 | 91005-KPB-003 | BEARING, RADIAL BALL (6205SPL) | 1 |
| 1 | 91102-GE1-711 | BEARING, RADIAL BALL (6204) (TOYO) | 1 |
| 1 | 91105-KTW-901 | BEARING, NEEDLE (14X22X20) | 1 |
| 1 | 91201-K04-931 | OIL SEAL (33X64X7) | 1 |
| 1 | 91251-KPB-003 | OIL SEAL (25X35X5) | 1 |
| 1 | 91303-K04-930 | O-RING (14.8X2.4) (NOK) | 1 |
| 4 | 91304-K04-930 | O-RING (15.8X2.4) | 4 |
| 2 | 91305-K04-930 | O-RING (16.5X2.5) | 2 |
| 1 | 91307-K04-930 | O-RING (9.8X2.4) | 1 |
| 1 | 91309-PX4-003 | O-RING (16X2.1) (NOK) (Honda Code 3301793) | 1 |
| 1 | 91313-K04-930 | O-RING (14.7X2.2) | 1 |
| 1 | 94101-05800 | WASHER, PLAIN (5MM) | 1 |
| 1 | 94109-12000 | WASHER, DRAIN PLUG (12MM) | 1 |
| 3 | 94301-10160 | PIN, DOWEL (10X16) (Honda Code 0058206) | 3 |
| 1 | 94520-12000 | CIRCLIP (INNER) (12MM) | 1 |
| 1 | 94601-16000 | CLIP, PISTON PIN (16MM) | 1 |
| 1 | 95002-41000-08 | CLAMP, TUBE (D10) | 1 |
| 95005-55003-20M | BULK HOSE, VACUUM (5.5X3000) (95005-55001-20M(95005-55001-2 | ||
| 1 | 95701-06016-00 | BOLT, FLANGE (6X16) (Honda Code 2410892) | 1 |
| 6 | 95701-06055-00 | BOLT, FLANGE (6X55) | 6 |
| 6 | 95701-06080-00 | BOLT, FLANGE (6X80) | 6 |
| 2 | 95701-08012-00 | BOLT, FLANGE (8X12) | 2 |
| 1 | 95701-08025-00 | BOLT, FLANGE (8X25) | 1 |
| 7 | 95701-08060-00 | BOLT, FLANGE (8X60) | 7 |
| 1 | 96220-30178 | ROLLER (3X17.8) | 1 |
