Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 50252-KF0-000 | BAND, SUB-TANK | ||
| 52400-MG3-003 | SHOCK ABSORBER ASSY., RR. | ||
| 52400-MG3-003 | SHOCK ABSORBER ASSY., RR. Use up to Frame SN EM103902 | ||
| 52400-MG3-771 | SHOCK ABSORBER ASSY., RR. Use up to Frame SN EM103902 | ||
| 52400-MG3-772 | SHOCK ABSORBER ASSY., RR. Use up to Frame SN EM103902 | ||
| 52400-MG3-772 | SHOCK ABSORBER ASSY., RR. | ||
| 52401-MG3-003 | SPRING, RR. SHOCK ABSORBER | ||
| 2 | 52406-KB7-003 | CAP, DUST SEAL | 2 |
| 52410-MG3-003 | DAMPER, RR. | ||
| 52410-MG3-003 | DAMPER, RR. Use up to Frame SN EM103902 | ||
| 52410-MG3-771 | DAMPER, RR. Use up to Frame SN EM103902 | ||
| 52410-MG3-772 | DAMPER, RR. Use up to Frame SN EM103902 | ||
| 52410-MG3-772 | DAMPER, RR. | ||
| 52421-MG3-771 | ROD, PISTON Use up to Frame SN EM103902 | ||
| 52421-MG3-772 | ROD, PISTON Use from Frame SN EM103903 | ||
| 52421-MK2-003 | ROD, PISTON Use from Frame SN EM103903 | ||
| 52422-KF0-003 | ADJUSTER, SPRING | ||
| 52423-KF0-003 | NUT, ADJUSTER | ||
| 52424-KF0-003 | STOPPER, SPRING SEAT | ||
| 1 | 52425-381-771 | CAP, AIR VALVE | 1 |
| 52427-MA0-771 | CAP, SUB-TANK | ||
| 52428-KF0-003 | PLATE SET, ADJUST | ||
| 52429-KF0-003 | PLATE, ADJUSTING | ||
| 52430-MG3-771 | TANK ASSY., RESERVOIR | ||
| 52431-KF0-003 | RING, PISTON | ||
| 52432-KF0-003 | O-RING C (2.0X29.5) | ||
| 52434-KF0-003 | O-RING D (3.5X29.7) | ||
| 52435-KF0-003 | RING, STOPPER | ||
| 52438-KF0-771 | PLATE SET, ADJUSTING | ||
| 52440-KF0-003 | HOSE, JOINT | ||
| 52441-MA0-003 | O-RING (9.8X1.9) | ||
| 52445-KF0-003 | SPRING, CLICK | ||
| 52446-KF0-003 | BALL | ||
| 52447-KF0-003 | O-RING (2X23.5) | ||
| 2 | 52448-KF0-003 | SCREW | 2 |
| 52449-KF0-771 | PLATE, ADJUSTING | ||
| 1 | 52451-MA0-000 | BUSH, SHOCK ABSORBER (LOWER) | 1 |
| 1 | 52452-KB7-003 | BUSH, SHOCK ABSORBER (UPPER) | 1 |
| 2 | 52455-KF0-003 | SPRING, CLICK | 2 |
| 2 | 52456-KF0-003 | BALL | 2 |
| 52457-KF0-003 | SEAL, RING | ||
| 1 | 52459-KE1-003 | SEAT C, SPRING (SHOWA) | 1 |
| 52460-KF0-000 | ARM ASSY., SHOCK ABSORBER | ||
| 52462-KF0-003 | BUSH, CUSHION ARM | ||
| 52463-KF0-000 | COLLAR, CUSHION ARM PIVOT | ||
| 52470-KF0-010 | ROD ASSY., RUBBER CONNECTING | ||
| 2 | 52472-MA0-013 | BUSH, RUBBER CONNECTING ROD | 2 |
| 2 | 52473-MA0-010 | COLLAR, CONNECTING ROD PIVOT | 2 |
| 2 | 52473-MA0-020 | COLLAR, CONNECTING ROD PIVOT | 2 |
| 1 | 52486-KB7-003 | COLLAR, SHOCK ABSORBER (UPPER) | 1 |
| 87516-KF0-003 | LABEL, RR. DAMPER CAUTION | ||
| 90128-KF0-000 | BOLT, FLANGE (12X90) | ||
| 1 | 90129-KF0-000 | BOLT, FLANGE (10X77) | 1 |
| 1 | 90151-MG3-000 | BOLT, FLANGE (10X65) | 1 |
| 1 | 90153-KF0-000 | BOLT, FLANGE (10X55) | 1 |
| 4 | 90304-GE8-003 | NUT, U (10MM) | 4 |
| 1 | 90306-KF0-003 | NUT, FLANGE (12MM) | 1 |
| 1 | 90401-KF0-003 | WASHER | 1 |
| 1 | 90501-MT2-000 | WASHER | 1 |
| 91261-KA3-711 | SEAL, RUBBER ARM PIVOT (NOK) | ||
| 91261-KA3-712 | SEAL, RUBBER ARM PIVOT (ARAI) | ||
| 4 | 91262-KA3-711 | SEAL, RUBBER CONNECTING ROD PIVOT (NOK) | 4 |
| 4 | 91262-KA3-712 | SEAL, RUBBER CONNECTING ROD PIVOT (ARAI) | 4 |
| 2 | 91351-KB7-003 | DUST SEAL B | 2 |
| 1 | 94002-12000-0S | NUT, HEX. (12MM) | 1 |
| 2 | 96000-060-2000 | BOLT, FLANGE (6X20) | 2 |
| 2 | 96001-06020-00 | BOLT, FLANGE (6X20) | 2 |
| 3 | 96201-80000 | FITTING, GREASE (B.76S) | 3 |
