Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 51400-MB2-671 | FORK ASSY., R. FR. | ||
| 51400-MB2-672 | FORK ASSY., R. FR. | ||
| 51401-MB2-671 | SPRING, FR. FORK | ||
| 51402-MB2-671 | COLLAR, SPRING | ||
| 51403-MB2-003 | VALVE, OIL LOCK | ||
| 51403-ME5-003 | PLATE, SPRING JOINT | ||
| 51404-MA6-003 | SPRING, OIL LOCK VALVE | ||
| 51405-MA6-003 | SEAT, SPRING | ||
| 2 | 51405-MC7-003 | RING, STOPPER | 2 |
| 51406-MB1-771 | RING, STOPPER | ||
| 51410-MB2-671 | PIPE, R. FR. FORK | ||
| 51411-ME5-003 | SPRING, REBOUND | ||
| 2 | 51412-463-003 | RING, BACK-UP | 2 |
| 2 | 51412-463-305 | RING, BACK-UP | 2 |
| 2 | 51414-463-003 | BUSH, FORK PIPE | 2 |
| 1 | 51415-MB9-781 | BUSH, SLIDER | 1 |
| 1 | 51415-463-003 | SLEEVE, FORK PIPE | 1 |
| 51417-ME1-671 | GASKET, PISTON CASE | ||
| 51417-MJ0-013 | GASKET | ||
| 51418-ME1-671 | SPRING, PISTON | ||
| 51421-MB2-003 | CASE, R. (LOWER) | ||
| 51423-MB1-771 | COLLAR, PISTON | ||
| 51432-MB2-003 | PIECE, OIL LOCK | ||
| 51432-MB7-611 | PIECE, OIL LOCK | ||
| 51433-MB1-771 | ROD, ADJUSTER | ||
| 51434-MC7-003 | SPRING, CLICK | ||
| 1 | 51435-MC7-003 | WASHER, SPECIAL (5MM) | 1 |
| 51436-MB1-771 | PISTON | ||
| 51437-ME5-003 | RING, PISTON | ||
| 51438-MB9-781 | HOLDER, GREASE | ||
| 51439-MB9-781 | WASHER, HOLDER | ||
| 51440-MB2-003 | PIPE, SEAT | ||
| 51441-MC7-003 | RUBBER, STOPPER | ||
| 2 | 51442-MC7-003 | BOOT, PISTON CASE | 2 |
| 51444-MB1-771 | WASHER, L. SIDE | ||
| 2 | 51445-MC7-003 | HOLDER, BOOT | 2 |
| 2 | 51447-463-003 | CIRCLIP (INNER) | 2 |
| 51448-MB1-771 | PIN, PARALLEL | ||
| 51450-ME5-003 | BOLT ASSY., FR. FORK | ||
| 51454-MB2-671 | BOLT ASSY., FR. FORK | ||
| 51456-MB2-003 | CAP, AIR VALVE | ||
| 51458-MG5-611 | CAP, ADJUSTING PLATE | ||
| 2 | 51490-MB9-781 | SEAL SET, FR. FORK | 2 |
| 2 | 51490-MB9-782 | SEAL SET, FR. FORK | 2 |
| 2 | 51490-MG2-305 | SEAL SET, FR. FORK | 2 |
| 2 | 51490-463-305 | SEAL SET, FR. FORK | 2 |
| 1 | 51496-MC7-670 | MARK, FR. FORK | 1 |
| 51500-MB2-672 | FORK ASSY., L. FR. | ||
| 51510-MB2-671 | PIPE, L. FR. FORK | ||
| 51521-MB2-003 | CASE, L. (LOWER) | ||
| 51521-MB2-013 | CASE, L. (LOWER) | ||
| 51530-ME7-671 | CASE, L. PISTON | ||
| 51532-MB2-300 | BUSH, PIVOT | ||
| 51540-MB2-003 | PIPE, SEAT | ||
| 51634-410-003 | HOLDER, FR. FORK AXLE | ||
| 53134-MG5-671 | SLEEVE | ||
| 53135-MG5-671 | BOLT, HEX. | ||
| 53137-MB2-003 | EQUALIZER, FR. SHOCK | ||
| 53139-MG5-671 | JOINT, L. AIR | ||
| 53240-MB2-000 | STABILIZER, FR. FORK | ||
| 90116-MC7-003 | BOLT, SOCKET (6MM) | ||
| 90118-MC7-003 | BOLT, SOCKET | ||
| 96700-06018-17 | BOLT, SOCKET (6X18) | ||
| 2 | 90116-283-010 | BOLT, SOCKET (8MM) | 2 |
| 2 | 90116-383-721 | BOLT, SOCKET (8MM) (SHOWA) | 2 |
| 90125-MB2-003 | BOLT, HEX. (6X17) | ||
| 90153-MB0-000 | BOLT, SOCKET (8X17) | ||
| 90153-MB0-405 | BOLT, SOCKET (8X17) | ||
| 2 | 90543-273-000 | GASKET, FR. FORK DRAIN VALVE | 2 |
| 2 | 90544-283-000 | WASHER, SPECIAL (8MM) | 2 |
| 90602-MG5-670 | RING, STOPPER | ||
| 2 | 91254-463-003 | DUST SEAL | 2 |
| 1 | 91302-MA3-661 | O-RING (35.5X2) | 1 |
| 1 | 91308-MC7-003 | O-RING D (13.8X2.4) (SHOWA) | 1 |
| 1 | 91311-PH7-003 | O-RING (13.8X2.4) (NOK) | 1 |
| 1 | 91306-PJ4-000 | O-RING (6.8X1.9) | 1 |
| 1 | 91310-MC7-003 | O-RING B (6.8X1.9) | 1 |
| 4 | 91351-GR1-000 | O-RING (38.5X2) | 4 |
| 4 | 91352-MG5-671 | O-RING (38.5X2) (SHOWA) | 4 |
| 91353-MG5-671 | O-RING | ||
| 2 | 91356-MA3-661 | O-RING (29.2X3.5) | 2 |
| 1 | 91308-MJ0-003 | O-RING (49.4X3.1) | 1 |
| 1 | 91399-MB0-003 | O-RING (49.4X3.1) | 1 |
| 4 | 91455-MB0-010 | CAP, SOCKET BOLT (8MM) | 4 |
| 1 | 92000-06008-0A | BOLT, HEX. (6X8) | 1 |
| 1 | 92101-06008-0A | BOLT, HEX. (6X8) | 1 |
| 4 | 92700-08050-3B | BOLT, STUD (8X50) | 4 |
| 4 | 92900-08028-3B | BOLT, STUD (8X50) | 4 |
| 1 | 93500-05010-0A | SCREW, PAN (5X10) | 1 |
| 1 | 93500-05010-1A | SCREW, PAN (5X10) | 1 |
| 1 | 93510-05010-0A | SCREW, PAN (5X10) | 1 |
| 4 | 94030-08000 | NUT, HEX. (8MM) | 4 |
| 4 | 94101-08000 | WASHER, PLAIN (8MM) | 4 |
| 4 | 94111-08000 | WASHER, SPRING (8MM) | 4 |
| 1 | 96211-05000 | BALL, STEEL (#5) (5/32) | 1 |
